Description

TP-Link TL-SG3452P JetStream Managed Switch 48xGE PoE+

The TP-Link TL-SG3452P is a robust and scalable 52-port L2+ managed switch tailored for enterprise-grade deployments. Equipped with 48 Gigabit PoE+ ports delivering up to 30W per port and a total PoE power budget of 384W, it’s perfect for powering a dense array of IP cameras, VoIP phones, and access points. Its full 104 Gbps switching capacity and 77.4 Mpps forwarding rate ensure high performance, even in heavy-traffic environments. The switch is Omada SDN compatible, enabling zero-touch provisioning and centralized cloud management. A rich suite of Layer 2/3 features, QoS, VLAN, ACLs, and IP-MAC-Port Binding ensures security, reliability, and streamlined network operations.

Key Features:

• 48 PoE+ Gigabit Ports: Supports 802.3af/at with up to 30W per port, ideal for high-power devices.
• Power Budget: 384W total PoE budget for powering access points, cameras, and more.
• High-Speed Performance: 104 Gbps switching capacity and 77.4 Mpps packet forwarding rate.
• Cloud-Based Management: Integrated with Omada SDN for centralized control and monitoring.
• Advanced Layer 2+ Features: VLAN, IGMP Snooping, Static Routing, Link Aggregation, and STP/RSTP/MSTP.
• Enterprise-Class Security: Includes 802.1X, DoS Defense, IP-MAC-Port Binding, DHCP Snooping, and ACLs.
• Flexible Management: Web GUI, CLI, SNMP, RMON, Dual Image support, and console ports.
• Rack-Mountable Design: Durable metal chassis with 3 integrated cooling fans.

Technical Specifications:

• Ports: 48× Gigabit PoE+ RJ45, 4× Gigabit SFP, 1× RJ45 Console, 1× Micro-USB Console
• PoE Standard: IEEE 802.3af/at
• Total PoE Budget: 384W
• Switching Capacity: 104 Gbps
• Forwarding Rate: 77.4 Mpps
• MAC Address Table: 16K entries
• Packet Buffer: 12 Mbit
• Jumbo Frame: 9 KB
• Power Supply: 100–240V AC, 50/60 Hz
• Max Power Consumption: 485.4W (with full PoE load)
• Dimensions: 440 × 330 × 44 mm (17.3 × 13.0 × 1.7 in)
• Cooling: 3 internal fans
• Mounting: Rack-mountable
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Certifications: CE, FCC, RoHS
