[specifications] [/specifications]Cisco 5508 Wireless Controllers deliver reliable performance, enhanced flexibility, and zero service-loss for mission-critical wireless. 802.11n offers up to nine times the performance of 802.11a/g networks. Interactive multimedia applications, such as voice and video, can now perform flawlessly over the wireless network, and clients can conveniently roam with no service interruption. Flexible licensing allows you to easily add access point support or premium software features.

[specifications]

Cisco AIR-CT2504-5-K9 Wireless Controller Specifications



Access points	5 licenses include (75 licenses max)
Device Type	Wireless controller
Ports	4 x 10/100/1000 ports
Console ports	10/100/1000 RJ-45
Wireless standards	802.11a/b/g/d/e/h/k/n/r/u/w/ac
Access point License	1 AP licese: L-LIC-CT2504-1A 5 AP licese: L-LIC-CT2504-5A 25 AP licese: L-LIC-CT2504-25A
Security standards	Wi-Fi Protected Access (WPA) IEEE 802.11i (WPA2, RSN) RFC 1321 MD5 Message-Digest Algorithm RFC 1851 The ESP Triple DES Transform RFC 2104 HMAC: Keyed Hashing for Message Authentication RFC 2246 TLS Protocol Version 1.0 RFC 2401 Security Architecture for the Internet Protocol RFC 2403 HMAC-MD5-96 within ESP and AH RFC 2404 HMAC-SHA-1-96 within ESP and AH RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV RFC 2406 IP Encapsulating Security Payload (ESP) RFC 2407 Interpretation for ISAKMP RFC 2408 ISAKMP RFC 2409 IKE RFC 2451 ESP CBC-Mode Cipher Algorithms RFC 3280 Internet X.509 PKI Certificate and CRL Profile RFC 3602 The AES-CBC Cipher Algorithm and Its Use with IPsec RFC 3686 Using AES Counter Mode with IPsec ESP RFC 4347 Datagram Transport Layer Security RFC 4346 TLS Protocol Version 1.1
Encryption	WEP and Temporal Key Integrity Protocol-Message Integrity Check (TKIP-MIC): RC4 40, 104 and 128 bits (both static and shared keys) Advanced Encryption Standard (AES): CBC, CCM, Counter Mode with Cipher Block Chaining Message Authentication Code Protocol (CCMP) DES: DES-CBC, 3DES Secure Sockets Layer (SSL) and Transport Layer Security (TLS): RC4 128-bit and RSA 1024- and 2048-bit DTLS: AES-CBC
Authentication, Authorization, and Accounting (AAA)	IEEE 802.1X RFC 2548 Microsoft Vendor-Specific RADIUS Attributes RFC 2716 PPP EAP-TLS RFC 2865 RADIUS Authentication RFC 2866 RADIUS Accounting RFC 2867 RADIUS Tunnel Accounting RFC 3576 Dynamic Authorization Extensions to RADIUS RFC 3579 RADIUS Support for EAP RFC 3580 IEEE 802.1X RADIUS Guidelines RFC 3748 Extensible Authentication Protocol Web-based authentication TACACS support for management users
Limitation	Does not support wired guest access Cannot be configured as an auto anchor controller. However you can configure it as a foreign controller Supports only multicast-multicast mode Does not support bandwidth contract feature Does not support access points in direct connect mode Does not support service port Apple Talk Bridging LAG Wired Guest



[/specifications]

Cisco Air-Ct2504-5-K9 Wireless Controller for System wide Wireless Connectivity

Cisco Air-Ct2504-5-K9 Wireless Controller is a component of Cisco unified wireless network. A perfect choice for small to medium-sized enterprises and branch environments, Cisco Air-Ct2504-5-K9 Wireless Controller supports 802.11n standard and real-time communication between Cisco Aironet access points.

Key Benefits of Cisco Air-Ct2504-5-K9 Wireless Controller

Cisco Air-Ct2504-5-K9 Wireless Controller is built to simplify the deployment and operation of wireless networks. This controller delivers centralized security policies, wireless intrusion prevention system capabilities, RF management and quality of service for voice and video. Configured to deliver 802.11n performance and scalability, this Cisco Air-Ct2504-5-K9 Wireless Controller provides low total cost of ownership and flexibility to scale as network requirements increase.



Product Code	AIR-CT2504-5-K9
Target deployments	Small or midsize
Form Factor	Desktop
Access points	5 licenses include
Max Access Points	75 licenses max
Max Client Support	1000
Ports	4 x 10/100/1000 ports
Console ports	10/100/1000 RJ-45
Wireless standards	802.11a/b/g/d/e/h/k/n/r/u/w/ac
Max throughput	1 Gbps
Max WLANs	16
Max VLANs	16
Redundant power	No
Redundant fans	Built-in fan
Max Power consumption	80W



• Network management device
• 4 ports
• PPP
• 10 GigE
• 802.11ac Wave 2
• 802.11ac Wave 1
• Wi-Fi

[specifications]

Chassis Height	One rack-unit (1RU)
Throughput	4 Gbps
Number of APs supported	150
Number of clients supported	3000
Processor	Cavium Network Processor-CN7240-AAP 8-core, 1.5 GHz
Memory Options	Control/Data Plane Memory-8GB DDR4 Boot Flash-8MB SPI NOR Serial Boot Bulk Flash-32GB eMMC
Redundancy, Service Ports	2x 1G Cu
Data Ports	1x 5G/mGig Cu, 4x 1G Cu (2 ports 802.3at PSE)
Storage Temperature	-4 F to 158 F (-20 C to 70 C)
Operating Temperature	32 F to 104 F (0 C to 40 C)
Storage Humidity	0% to 95% RH non-condensing
Operating Humidity	5% to 95% RH non-condensing
Power Adapter	54VDC/1.05A, 12VDC/3.75A
Wireless	IEEE 802.11a, 802.11b, 802.11g, 802.11d, WMM/802.11e, 802.11h, 802.11n, 802.11k, 802.11r, 802.11u, 802.11w, 802.11ac Wave 1 and Wave 2
Wired, switching, and routing	IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX specification, 1000BASE-T. 1000BASE-SX, 1000-BASE-LH, IEEE 802.1Q VLAN tagging, IEEE 802.1AX Link Aggregation
Data Request For Comments (RFC)	RFC 768 UDP  RFC 791 IP  RFC 2460 IPv6  RFC 792 Internet Control Message Protocol (ICMP)  RFC 793 TCP  RFC 826 Address Resolution Protocol (ARP)  RFC 1122 Requirements for Internet Hosts  RFC 1519 Classless Interdomain Routing (CIDR)  RFC 1542 BOOTP  RFC 2131 Dynamic Host Configuration Protocol (DHCP)  RFC 5415 CAPWAP Protocol  RFC 5416 CAPWAP Binding for 802.11
Security standards	Wi-Fi Protected Access (WPA)  IEEE 802.11i (WPA2, RSN)  RFC 1321 MD5 Message-Digest Algorithm  RFC 1851 Encapsulating Security Payload (ESP) Triple Data Encryption Standard (3DES) Transform  RFC 2104 HMAC: Keyed Hashing for Message Authentication  RFC 2246 Transport Layer Security (TLS) Protocol Version 1.0  RFC 2401 Security Architecture for the Internet Protocol  RFC 2403 HMAC-MD5-96 within ESP and Authentication Header (AH)  RFC 2404 HMAC-SHA-1-96 within ESP and AH  RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV  RFC 2407 Interpretation for Internet Security Association and Key Management Protocol (ISAKMP)  RFC 2408 ISAKMP  RFC 2409 Internet Key Exchange (IKE)  RFC 2451 ESP Cipher Block Chaining (CBC)-Mode Cipher Algorithms  RFC 3280 Internet X.509 Public Key Infrastructure (PKI) Certificate and Certificate Revocation List (CRL) Profile  RFC 4347 Datagram Transport Layer Security  RFC 5426 TLS Protocol Version 1.2
Encryption	Wired Equivalent Privacy (WEP) and Temporal Key Integrity Protocol-Message Integrity Check (TKIP-MIC):  RC4 40, 104 and 128 bits (both static and shared keys)  Advanced Encryption Standard (AES): CBC, Counter with CBC-MAC (CCM), Counter with CBC Message Authentication Code Protocol (CCMP)  Data Encryption Standard (DES): DES-CBC, 3DES  Secure Sockets Layer (SSL) and TLS: RC4 128-bit and RSA 1024- and 2048-bit  DTLS: AES-CBC  IPsec: DES-CBC, 3DES, AES-CBC  802.1AE MACsec encryption
Authentication, Authorization, and Accounting (AAA)	IEEE 802.1X  RFC 2548 Microsoft Vendor-Specific RADIUS Attributes  RFC 2716 Point-to-Point Protocol (PPP) Extensible Authentication Protocol (EAP)-TLS  RFC 2865 RADIUS Authentication  RFC 2866 RADIUS Accounting  RFC 2867 RADIUS Tunnel Accounting  RFC 2869 RADIUS Extensions  RFC 3576 Dynamic Authorization Extensions to RADIUS  RFC 5176 Dynamic Authorization Extensions to RADIUS  RFC 3579 RADIUS Support for EAP  RFC 3580 IEEE 802.1X RADIUS Guidelines  RFC 3748 EAP  Web-based authentication  TACACS support for management users
Management	Simple Network Management Protocol (SNMP) v1, v2c, v3  RFC 854 Telnet  RFC 1155 Management Information for TCP/IP-Based Internets  RFC 1156 MIB  RFC 1157 SNMP  RFC 1213 SNMP MIB II  RFC 1350 Trivial File Transfer Protocol (TFTP)  RFC 1643 Ethernet MIB  RFC 2030 Simple Network Time Protocol (SNTP)  RFC 2616 HTTP  RFC 2665 Ethernet-Like Interface Types MIB  RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual Extensions  RFC 2819 Remote Monitoring RMON MIB  RFC 2863 Interfaces Group MIB  RFC 3164 Syslog  RFC 3414 User-Based Security Model (USM) for SNMPv3  RFC 3418 MIB for SNMP  RFC 3636 Definitions of Managed Objects for IEEE 802.3 MAUs  Cisco private MIBs
Management interfaces	Web-based: HTTP/HTTPS  Command-line interface: Telnet, Secure Shell (SSH) Protocol, serial port  Cisco Prime Infrastructure
Interfaces and indicators	1x Multigigabit Ethernet interface (up to 5 Gigabit Ethernet) + 4x 1 Gigabit Ethernet interfaces (RJ-45)  1x service port: 1 Gigabit Ethernet port (RJ-45)  1x redundancy port: 1 Gigabit Ethernet port (RJ-45)  1x console port: Serial port (RJ-45)  1x console port: Serial port (mini-B USB)  1x USB 3.0 port  LED indicators: Network link, diagnostics
Physical and environmental	Dimensions: 1.73 x 9.5 x 8.5 in. (43.94 x 214.3 x 215.9 mm) Weight: 4.4lbs Temperature: Operating: 32 to 104 F (0 to 40C) Storage: -4 to 158 F (-20 to 70C) Humidity: Operating Humidity: 5% to 95% RH non-condensing Storage Humidity: 0% to 95% RH non-condensing Power adapter: Input power: 100 to 240 VAC; 50/60 Hz Heat dissipation (without PoE): 47W, 160BTU/hr Heat dissipation (with PoE): 98W, 335BTU/hr
Regulatory compliance	CE Markings per directives 2004/108/EC and 2006/95/EC Safety:  UL 60950-1 Second Edition  CAN/CSA-C22.2 No. 60950-1 Second Edition  EN 60950-1 Second Edition  IEC 60950-1 Second Edition  AS/NZS 60950-1  GB4943 2011 EMC - Emissions:  47CFR Part 15 (CFR 47) Class B  AS/NZS CISPR22 Class B  EN 55032 Class B  ICES003 Class A VCCI Class B  EN 61000-3-2 EN 61000-3-3 KN22 Class B  CNS13438 Class B EMC - Immunity:  EN 55024  CISPR24  EN 300386  KN24





[/specifications]

Cisco Air-Ct3504-K9 Wireless Controller for Unified Wireless Network

Cisco Air-Ct3504-K9 Wireless Controller is built to deliver solutions for centralized control, management, and troubleshooting for all business environments. It supports multiple deployment modes in the same controller, ranging from centralized mode for campus environments, Cisco FlexConnect mode for lean branches managed over the WAN. Cisco Air-Ct3504-K9 Wireless Controller provides support for a mesh (bridge) mode for deployments where users won’t get full Ethernet cabling solution.

Key Benefits of Cisco Air-Ct3504-K9 Wireless Controller

Cisco Air-Ct3504-K9 Wireless Controller is a component of the Cisco Unified Wireless Network.  It provides real-time communications between Cisco Aironet Access Points, Cisco Prime Infrastructure, and the Cisco Mobility Services Engine. It supports interoperable needs with the Cisco 5520 and 8540 Wireless Controllers.



Chassis Height	One rack-unit (1RU)
Throughput	4 Gbps
Number of APs supported	150
Number of clients supported	3000
Processor	Cavium Network Processor-CN7240-AAP 8-core, 1.5 GHz
Memory Options	Control/Data Plane Memory-8GB DDR4 Boot Flash-8MB SPI NOR Serial Boot Bulk Flash-32GB eMMC
Redundancy, Service Ports	2x 1G Cu
Data Ports	1x 5G/mGig Cu, 4x 1G Cu (2 ports 802.3at PSE)



[specifications]



Device Type	Wireless controller
Ports	Dual 1-Gb or 10-Gb ports with Link Aggregation Group
Console ports	10/100/1000 RJ-45
Wireless standards	802.11a/b/g/d/e/h/k/n/r/u/w/ac
License	5 AP licese: L-LIC-CT5520-5A   25 AP licese: L-LIC-CT5520-25A   50 AP licese: L-LIC-CT5520-50A   100 AP licese: L-LIC-CT5520-100A   250 AP licese: L-LIC-CT5520-250A   DTLS License: L-LIC-CT5520-DTLS-K9
Security standards	Wi-Fi Protected Access (WPA)    IEEE 802.11i (WPA2, RSN)    RFC 1321 MD5 Message-Digest Algorithm    RFC 1851 The ESP Triple DES Transform    RFC 2104 HMAC: Keyed-Hashing for Message Authentication    RFC 2246 TLS Protocol Version 1.0    RFC 2401 Security Architecture for the Internet Protocol    RFC 2403 HMAC-MD5-96 within ESP and AH    RFC 2404 HMAC-SHA-1-96 within ESP and AH    RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV    RFC 2406 IP Encapsulating Security Payload (ESP)    RFC 2407 Interpretation for ISAKMP    RFC 2408 ISAKMP    RFC 2409 IKE    RFC 2451 ESP CBC-Mode Cipher Algorithms    RFC 3280 Internet X.509 PKI Certificate and CRL Profile    RFC 3602 The AES-CBC Cipher Algorithm and Its Use with IPsec    RFC 3686 Using AES Counter Mode with IPsec ESP    RFC 4347 Datagram Transport Layer Security    RFC 4346 TLS Protocol Version 1.1
Encryption	WEP and Temporal Key Integrity Protocol-Message Integrity Check (TKIP-MIC): RC4 40, 104 and 128 bits (both static and shared keys)    Advanced Encryption Standard (AES): CBC, CCM, Counter Mode with Cipher Block Chaining Message Authentication Code Protocol (CCMP)    DES: DES-CBC, 3DES    Secure Sockets Layer (SSL) and Transport Layer Security (TLS): RC4 128-bit and RSA 1024- and 2048-bit    DTLS: AES-CBC    IPSec: DES-CBC, 3DES, AES-CBC
Authentication, Authorization, and Accounting (AAA)	IEEE 802.1X    RFC 2548 Microsoft Vendor-Specific RADIUS Attributes    RFC 2716 PPP EAP-TLS    RFC 2865 RADIUS Authentication    RFC 2866 RADIUS Accounting    RFC 2867 RADIUS Tunnel Accounting    RFC 3576 Dynamic Authorization Extensions to RADIUS    RFC 3579 RADIUS Support for EAP    RFC 3580 IEEE 802.1X RADIUS Guidelines    RFC 3748 Extensible Authentication Protocol    Web-based authentication    TACACS support for management users





[/specifications]The Cisco 5520 Series wireless LAN controller is a highly scalable, service-rich, resilient, and flexible platform that is ideal for medium-sized to large enterprise and campus deployments. As part of the Cisco Unified Access Solution, the 5520 is optimized for the next generation of wireless networks, 802.11ac Wave 2.

[specifications] [/specifications]

Resilient Cisco AIR-CT5520-50-K9 Wireless Controller

Cisco AIR-CT5520-50-K9 Wireless Controller provides a highly scalable, service-rich, resilient, and flexible platform. Idea for medium-sized to large enterprise and campus deployments, Cisco AIR-CT5520-50-K9 Wireless Controller is affordable too.

Key Benefits of Cisco AIR-CT5520-50-K9 Wireless Controller

Cisco AIR-CT5520-50-K9 Wireless Controller is optimized for the next generation of wireless networks, 802.11ac Wave 2.

[specifications] [/specifications]The Cisco 3504 Wireless Controller provides centralized control, management, and troubleshooting for small to medium-sized enterprises and branch offices. It offers flexibility to support multiple deployment modes in the same controller - a centralized mode for campus environments, Cisco FlexConnect mode for lean branches Managed over the WAN, and a mesh (bridge) mode for deployments in which full Ethernet cabling is unavailable. As a component of the Cisco Unified Wireless Network, the 3504 controller provides real-time communications between Cisco Aironet Access Points, Cisco Prime Infrastructure, and the Cisco Mobility Services Engine, and is interoperable with the Cisco 5520 and 8540 Wireless Controllers.

[specifications] [/specifications]The Cisco 2500 series wireless controller enables system wide wireless functions in small to medium-sized enterprises and branch offices. Designed for 802.11n performance, Cisco 2500 series wireless controller is an entry-level controller that provides real-time communication between Cisco Aironet access points to simplify the deployment and operation of wireless networks. As a component of the Cisco unified wireless network, this controller delivers centralized security policies, wireless intrusion prevention system (wIPS) capabilities, RF management and quality of service (QoS) for voice and video. Delivering 802.11n performance and scalability the 2500 series provides low total cost of ownership and flexibility to scale as network requirements grow.
