HPE OFFICECONNECT 1920S 24G 2SFP SWITCH (JL381A)
| Model: | JL381A |
| Detail: | Switch, L3, managed, 24 x 10/100/1000 + 2 x 100/1000 SFP, desktop, rack-mountable, wall-mountable |
| List Price: | |
| Price: | $349.00 |
| You Save: | $120.00 (26% OFF) |
| Condition: | Brand New Sealed |
| Availability: | Out of Stock |
| Shipping: | FREE SHIPPING for all U.S orders over $100. Please call us at 201-559-1474, fill out the contact form, or chat with a live agent for other shipping methods. |
| Tax: | $0.00 Tax Outside NJ and TX |
| Quantity: |
Description
HPE OfficeConnect 1920S 24G 2SFP Switch (JL381A)
The HPE OfficeConnect 1920S Switch Series offers a range of advanced features for meticulous control and easy network configuration designed for small businesses. Customization options include essential Layer 2 functions such as VLANs and link aggregation, as well as more advanced capabilities like Layer 3 static routing, IPv4 and IPv6 Host mode, ACLs, and Spanning Tree Protocols. HPE OfficeConnect 1920S 24G 2SFP Switch (JL381A) stands out with its fanless design.
Key Features:
- Layer 3 static routing with 32 routes
- Smart managed
- IPv6 host
The tabs above contain the JL381A datasheet with all the specifics you need.
Accessories
| Transceivers | |
| J9054C | HPE X121 1G SFP LC SX Transceiver |
| J8177C | HPE X121 1G SFP LC LX Transceiver |
| J4859C | HPE X121 1G SFP RJ45 T Transceiver |
| J4858C | HPE X111 100M SFP LC FX Transceiver |
| Cables | |
| AJ833A | HPE 0.5 m Multimode OM3 LC/LC Optical Cable |
| AJ834A | HPE 1 m Multimode OM3 LC/LC Optical Cable |
| AJ835A | HPE 2 m Multimode OM3 LC/LC Optical Cable |
| AJ836A | HPE 5 m Multimode OM3 LC/LC Optical Cable |
| AJ837A | HPE 15 m Multimode OM3 LC/LC Optical Cable |
| AJ838A | HPE 30 m Multimode OM3 LC/LC Optical Cable |
| AJ839A | HPE 50 m Multimode OM3 LC/LC Optical Cable |
| QK732A | HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable |
| QK733A | HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable |
| QK734A | HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable |
| QK735A | HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable |
| QK736A | HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable |
| QK737A | HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable |
Specifications
| Specifications | 1920S-JL381A |
| Memory and processor | ARM Cortex-A9 @ 400 MHz, 256 MB SDRAM, 64 MB flash; packet buffer: 1.5 MB |
| Performance | |
| 100 Mb Latency | < 7µs |
| 1000 Mb Latency | < 2µs |
| Throughput | Up to 38.6 Mpps (64-byte packets) |
| Routing/Switching capacity | 52 Gbps |
| Routing table size | 32 entries |
| MAC address table size | 8000 entries |
| Management | Web browser; SNMP Manager |
| Operating temperature | 32°F to 104°F (0°C to 40°C) |
| Operating relative humidity | 15% to 95%, noncondensing @ 104°F (40°C) |
| Nonoperating/Storage temperature | -40°F to 158°F (-40°C to 70°C) |
| Nonoperating/Storage relative humidity | 15% to 95%, noncondensing |
| Altitude | up to 10,000 ft (3 km) |
| Acoustic | Pressure: 0 dB No Fan |
| MTBF (years) | 80.0 |
| Safety | UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1 |
| Emissions | VCCI Class A; CNS 13438; ICES-003 Issue 5 Class A; FCC CFR 47 Part 15, Class A; EN 55032: 2015/CISPR-32 |
| Immunity | EN 55024, CISPR 24 EN 55024, CISPR 24 IEC 61000-4-2 IEC 61000-4-3 IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-6 IEC 61000-4-8 IEC 61000-4-11 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-3, IEC 61000-3-3 |
| General protocols | IEEE 802.1D MAC Bridges IEEE 802.1p Priority IEEE 802.1Q VLANs IEEE 802.1s (MSTP) IEEE 802.1w Rapid Reconfiguration of Spanning Tree IEEE 802.3ad Link Aggregation Control Protocol (LACP) IEEE 802.3x Flow Control IEEE 802.3 Type 10BASE-T IEEE 802.3i 10BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3z 1000BASE-X |
| MIBs | HC-ALARM-MIB SNMP-FRAMEWORK-MIB SNMP-NOTIFICATION-MIB SNMP-USER-BASED-SM-MIB SR-AGENT-INFO-MIB BRIDGE-MIB (IEEE 802.1Q) Q-BRIDGE-MIB (RFC 2674) LLDP-MIB (IEEE 802.3AB) LLDP-EXT-MED-MIB LAG-MIB (IEEE 802.3ad) RADIUS-ACC-CLIENT-MIB EtherLike-MIB IF-MIB (RFC 2863) RFC1213-MIB II Power Ethernet MIB (RFC3621) |
| QoS/CoS | IEEE 802.1P (CoS) |
| Security | IEEE 802.1X Port Based Network Access Control |
Properties
| Properties | HPE OfficeConnect 1920S JL381A |
| Description | Switch, L3, managed, 24 x 10/100/1000 + 2 x 100/1000 SFP, desktop, rack-mountable, wall-mountable |
| Product Family | 1920S Series |
| Product Type | Ethernet Switch |
| I/O ports and slots | 24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only 2 SFP 100/1000 Mbps ports (IEEE 802.3z Type 1000BASE-X, IEEE 802.3u Type 100BASE-FX) |
| Electrical characteristics | |
| Frequency | 50/60 Hz |
| AC voltage | 100 - 127/200 - 240 VAC |
| Current | .5/.3 A |
| Maximum power rating | 15.7 W |
| Idle power | 11.6 W |
| Dimension | 17.42(w) x 9.69(d) x 1.73(h) in (44.25 x 24.61 x 4.39 cm) (1U height) |
| Weight | 6 lb (2.72 kg) |
| Mounting and enclosure | Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included) |
