[specifications]
Type | Wireless access point |
Form Factor | External |
Connectivity Technology | Wireless |
Data Transfer Rate | 1.3 Gbps |
Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Compliant Standards | IEEE 802.11, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at |
Features | 3T3R MIMO technology, Auto-sensing per device, Cisco Flexible Antenna Port technology, CleanAir technology, ClientLink technology, Cyclic shift diversity (CSD), DFS support, MAC address filtering, Maximum Ratio Combining (MRC), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Reset button, VPN passthrough |
Network Transport Protocol | IPSec, L2TP |
Wireless Protocol | 802.11a/b/g/n/ac Wave 2 |
Wi-Fi Bands | 2.4 GHz, 5 GHz |
Qty | 1 |
WAN DMZ | WAN |
Type | Console |
Connector Type | SFP (mini-GBIC) |
Compliant Standards | ANSI / IEEE 587 C62.41, ARIB STD-T66, ARIB STD-T71, AS/NZS 4268.2003, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 300 328, EN 301 489-1, EN 301.893, EN 301489-17, EN 60950, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, FCC OET Bulletin 65c, FCC Part 15.107, FCC Part 15.109, FCC Part 15.247, FCC Part 15.407, ICES-003, IEC 60950-2, RSS-102, RSS-210, UL 60950-2 |
Authentication Method | Extensible Authentication Protocol (EAP), X.509 certificates |
Encryption Algorithm | AES, LEAP, PEAP, TLS, TTLS, WPA, WPA2 |
Directivity | Omni-directional |
Antenna Form Factor | Internal |
Min Operating Temperature | -40 F |
Max Operating Temperature | 149 F |
Compatibility | PC |
Manufacturer | Cisco Systems |
Packaged Quantity | 1 |
Product Line | Cisco Aironet |
Model | 1562I |
Brand | Cisco |
Width | 6.7 in |
Depth | 3.9 in |
Height | 9 in |
Weight | 5.51 lbs |
Â
[/specifications]
Cisco AIR-AP1562I-B-K9 Access Point offers the IEEE 802.11ac Wave 2 radio standard in a compact, visually pleasant, easy-to-deploy package for applications to cover rugged outdoor Wi-Fi area. This Cisco switch has flexible deployment options for service providers, enterprise networks, and public safety networks that need the fastest links possible for mobile, outdoor clients (smartphones, tablets, and laptops) and wireless backhaul.
Cisco AIR-AP1562I-B-K9 Access Point provides the flexibility to balance their desired wireless coverage for easy deployment requirements.
Part Number | AIR-AP1562I-B-K9 |
Description | 802.11ac Wave 2 Low-Profile Outdoor AP, Internal Antenna, B Regulatory Domain |
Features | 3 x 3 MIMO with three spatial streamsMulti- and single-user MIMOMaximal ratio combining (MRC)802.11ac beamforming (transmit beamforming)20-, 40-, and 80-MHz channelsPHY data rates up to 1.3 Gbps (80 MHz in 5 GHz)Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)802.11 dynamic frequency selection (DFS)Cyclic-shift-diversity (CSD) support |
Interfaces | WAN port 10/100/1000BASE-TEthernet,autosensing (RJ-45), PoE inSFP port (fiber or electrical)Management console port (RJ-45)Multicolor LEDDC power inputReset button |
Dimensions (L x W x H) | 9.0 x 6.8 x 3.9 in. (22.9 x 17.1 x 9.8 cm) |
Weight | 5.6 lb (2.5 kg) |
Â
Â
[specifications]
Type | Wireless access point |
Form Factor | External |
Connectivity Technology | Wireless |
Data Transfer Rate | 1.3 Gbps |
Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Compliant Standards | IEEE 802.11, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at |
Features | 2T2R MIMO technology, Auto-sensing per device, Beamforming technology, Cisco Flexible Antenna Port technology, CleanAir technology, ClientLink technology, Cyclic shift diversity (CSD), DFS support, High Density Experience (HDX), MAC address filtering, Maximum Ratio Combining (MRC), MU-MIMO technology, Packet aggregation A-MPDU, Packet aggregation A-MSDU, Radio resource management (RRM), Reset button, VPN passthrough |
Network Transport Protocol | IPSec, L2TP |
Wireless Protocol | 802.11a/b/g/n/ac Wave 2 |
Power Over Ethernet (PoE) | PoE+ |
Wi-Fi Bands | 2.4 GHz, 5 GHz |
Qty | 1 |
WAN DMZ | WAN |
Type | Console |
Connector Type | SFP (mini-GBIC) |
Compliant Standards | ANSI / IEEE 587 C62.41, ARIB STD-T66, ARIB STD-T71, AS/NZS 4268.2003, CAN/CSA C22.2 No. 60950 Second Edition, EN 300 328, EN 301 489-1, EN 301 893, EN 301489-17, EN 60068-2-5, EN 60950, EN 60950 Second Edition, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, FCC OET Bulletin 65c, FCC Part 15.107, FCC Part 15.109, FCC Part 15.247, FCC Part 15.407, ICES-003, IEC 60529 IP67, IEC 60950 Second Edition, MIL-STD-810, NEMA 250-2008, NEMA Type 4X, RSS-102, RSS-210, UL 60950 Second Edition, X.509 |
Authentication Method | Extensible Authentication Protocol (EAP), X.509 certificates |
Encryption Algorithm | AES, LEAP, PEAP, TLS, TTLS, WPA, WPA2 |
Antenna Form Factor | Internal |
Min Operating Temperature | -40 F |
Max Operating Temperature | 149 F |
Compatibility | PC |
Manufacturer | Cisco Systems |
Packaged Quantity | 1 |
Product Line | Cisco Aironet |
Model | 1562D |
Brand | Cisco |
Width | 6.7 in |
Depth | 4.3 in |
Height | 9 in |
Weight | 5.73 lb |
[/specifications]
Use Cisco AIR-AP1562D-B-K9 for Wider Area Wi-Fi Coverage in Harsh SettingsÂ
Cisco AIR-AP1562D-B-K9 Access Point is built to deliver optimum results for rugged outdoor Wi-Fi coverage. Available in a compact, visually nice, and easy-to-deploy package, the Cisco Aironet 1560 Series Access Point features IEEE 802.11ac Wave 2 radio standard. The 1560 Series Access Point features flexible deployment options for service providers, enterprise networks, and public safety networks.Â
Key Benefits of Cisco AIR-AP1562D-B-K9
The 1560 Series Access Point renders the fastest possible linking solutions for mobile, outdoor clients (Smartphone, tablets, and laptops) and wireless backhaul. This series access point also ensures flexibility for network operators to balance their need for easy deployment within the desired wireless coverage.
Part Number | AIR-AP1562D-B-K9 |
Description | 802.11ac Wave 2 Low-Profile Outdoor AP, Directional Antenna, B Regulatory Domain |
Features | 2 x 2 MIMO with two spatial streamsMulti- and single-user MIMOMaximal ratio combining (MRC)802.11ac beamforming (transmit beamforming)20-, 40-, and 80-MHz channelsPHY data rates up to 1.3 Gbps (80 MHz in 5 GHz)Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)802.11 dynamic frequency selection (DFS)Cyclic-shift-diversity (CSD) support |
Interfaces | WAN port 10/100/1000BASE-TEthernet,autosensing (RJ-45), PoE inSFP port (fiber or electrical)Management console port (RJ-45)Multicolor LEDDC power inputReset button |
Dimensions | (L x W x H) 9.0 x 6.8 x 4.3 in. (22.9 x 17.1 x 10.9 cm) |
Weight | 5.7 lb (2.6 kg) |
[specifications]
Type | Wireless access point |
Form Factor | External |
Connectivity Technology | Wireless |
Data Transfer Rate | 1.3 Gbps |
Data Link Protocol | IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Compliant Standards | IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at |
Features | 2T2R MIMO technology, Auto-sensing per device, Beamforming technology, CleanAir technology, ClientLink technology, Cyclic shift diversity (CSD), DFS support, Dynamic path selection (DPS), MAC address authentication, MAC address filtering, Maximum Ratio Combining (MRC), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Radio resource management (RRM), Reset button, VPN passthrough |
Network Transport Protocol | IPSec, L2TP |
Wireless Protocol | 802.11a/b/g/n/ac Wave 2 |
Power Over Ethernet (PoE) | UPOE |
Wi-Fi Bands | 2.4 GHz, 5 GHz |
Qty | 4 |
WAN DMZ | WAN |
Type | Management |
Connector Type | SFP (mini-GBIC) |
Compliant Standards | ANSI / IEEE 587 C62.41, ARIB STD-T66, ARIB STD-T71, AS/NZS 4268.2003, EN 300 328, EN 301 489-1, EN 301 893, EN 60068-2-5, EN 60950, EN 60950 Second Edition, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, FCC OET Bulletin 65c, FCC Part 15.107, FCC Part 15.109, FCC Part 15.247, FCC Part 15.407, IEC 60529 IP67, IEC 60950 Second Edition, MIL-STD-810, NEMA 250-2008, NEMA Type 4X, RSS-102, RSS-210, UL 60950 Second Edition |
Authentication Method | Extensible Authentication Protocol (EAP), X.509 certificates |
Encryption Algorithm | AES, LEAP, PEAP, TLS, TTLS, WPA, WPA2 |
Antenna Form Factor | External detachable |
Min Operating Temperature | -40 F |
Max Operating Temperature | 131 F |
Compatibility | PC |
Country Kits | United States |
Manufacturer | Cisco Systems |
Packaged Quantity | 1 |
Product Line | Cisco Aironet |
Model | 1562E |
Brand | Cisco |
Type | Spatial streams |
Value | 2 |
Width | 6.7 in |
Depth | 3.9 in |
Height | 9 in |
Weight | 5.51 lbs |
Ruggedized Design | Outdoor |
Â
Â
Â
[/specifications]
Cisco AIR-AP1562E-B-K9 Access Point can be a perfect choice for enterprise-class and service-class network operators.
Cisco AIR-AP1562E-B-K9 Access Point is high-performing outdoor access point that provides high throughput over a large area with pervasive coverage.
Â
Description | 802.11ac Wave 2 Low-Profile Outdoor AP, External Antenna, B Regulatory Domain |
Features | 2 x 2 MIMO with two spatial streamsMulti- and single-user MIMOMaximal ratio combining (MRC)802.11ac beamforming (transmit beamforming)20-, 40-, and 80-MHz channelsPHY data rates up to 1.3 Gbps (80 MHz in 5 GHz)Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)802.11 dynamic frequency selection (DFS)Cyclic-shift-diversity (CSD) support |
Interfaces | WAN port 10/100/1000BASE-TEthernet,autosensing (RJ-45), PoE inSFP port (fiber or electrical)Management console port (RJ-45)Multicolor LEDDC power inputReset button |
Dimensions (L x W x H) | 9.0 x 6.8 x 3.9 in. (22.9 x 17.1 x 9.8 cm) |
Weight | 5.6 lb (2.5 kg) |
