[shortdesc]

Discreet, budget-friendly, and outdoor-ready thermal detection, Reliable and budget-friendly detection, Thermal technology for the low rate of false alarm, Functional and discreet design, Outdoor-ready

[/shortdesc]

[properties]

Properties	AXIS P1290-E 4 MM 8.3 FPS Thermal Network Camera
Description	The AXIS P1290–E Thermal Network Camera offers reliable and budget-friendly detection with low false alarms. Its discreet fixed dome design, built-in analytics, and support for third-party analytics make it an ideal indoor/outdoor surveillance solution that prioritizes personal integrity.
Product Family	AXIS P1290–E Thermal Network Camera
Product Type	Thermal Camera

[/properties] [specifications]

Specifications	AXIS P1290-E 4 MM 8.3 FPS Thermal Network Camera
Camera
Image sensor	Uncooled Microbolometer 208 x 156 pixels, Pixel size 12 µm,
Image sensor	Spectral range: 8-14 µm
Lens	Athermalized
	4 mm, F1.2
	Horizontal field of view: 35.4°
	Vertical field of view: 28°
	Near focus distance: 1 m
Sensitivity	NETD < 100 mK
Camera angle adjustment	Tilt: 120°, Rotation: 90°
Video
Video compression	H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
Video compression	Motion JPEG
Resolution	Sensor is 208 x 156. Image can be scaled up to 640 x 480
Frame rate	Up to 8.3 fps
Video streaming	Multiple, individually configurable streams in H.264 (Main,
	Baseline and High Profiles) and Motion JPEG
	Axis Zipstream technology in H.264
	Controllable frame rate and bandwidth
	VBR/ABR/MBR H.264
Image settings	Brightness, sharpness, contrast, automatic gain control, gain,
	rotation, palette, compression, mirroring, text and image overlay,
	Axis Corridor Format
Network
Security	Password protection, IP address filtering, HTTPS() encryption, IEEE 802.1X (EAP-TLS)() network access control, digest authentication, user access log, centralized certificate management, brute force delay protection, signed firmware
Security	(*: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/), and cryptographic software written by Eric Young)
Supported protocols	IPv4, IPv6 USGv6, HTTP, HTTPS () , SSL/TLS () , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT v3.1.1
Supported protocols	(*: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/), and cryptographic software written by Eric Young)
System Integration
Application Programming Interface	Open API for software integration, including VAPIX® and
	AXIS Camera Application Platform; specifications at axis.com
	One-click cloud connection
	ONVIF® Profile G and ONVIF® Profile S
Event triggers	Analytics, hardware temperature, edge storage events, time
Event triggers	scheduled, video motion detection, live stream accessed
Event actions	File upload: email, FTP, HTTP, HTTPS, network share
	Notification: email, HTTP, HTTPS and TCP
	Pre- and post-alarm video buffering
	Send SNMP trap
Data streaming	Event data
Built-in installation aids	Pixel counter
Analytics
Applications	Included
	AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard
	AXIS Video Motion Detection, AXIS Guard Suite
	Supported
	AXIS Perimeter Defender
	Support for AXIS Camera Application Platform enabling
	installation of third-party applications
General
Casing	Main unit: Polycarbonate casing
	Color: White NCS S 1002-B
	Thermal sensor unit: Plastic
	Color: White NCS S 1002-B
Memory	512 MB RAM, 256 MB Flash
Power	Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 2
Power	max 4.0 W, typical 2.5 W
Connectors	Female RJ45 for 10BASE-T/100BASE-TX PoE
Connectors	RJ12 for sensor unit
Storage	Support for microSD/microSDHC/microSDXC cards (not included)
	Support for SD card encryption
	Support for recording to network-attached storage (NAS)
	For SD card and NAS recommendations
Operating conditions	Main unit: -20 °C to 50 °C (-4 °F to 122 °F)
	Humidity 10-85% RH (non-condensing)
	Thermal sensor unit: -30 °C to 55 °C (-22 °F to 131 °F)
	Humidity 10-100% RH (condensing)
Storage conditions	(-40 °C to 65 °C ) (-40 °F to 149 °F)
Approvals	EN 55032 Class B, EN 55024, EN 61000-6-1, EN 61000-6-2,
	FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B,
	RCM AS/NZS CISPR 23 Class B, IEC/EN/UL 62368-1, EN 50581,
	EN 50121-4 , IEC 62236-4, EAC, KC KN32 Class B, KC KN35
	Thermal sensor unit: IEC 60068-2-1, IEC 60068-2-2,
	IEC 60068–2–6, IEC 60068-2-14, IEC 60068–2–27,
	IEC 60068-2-30, IEC 60068-2-78, IEC 60529 IP66/IP67,
	IEC/EN/UL 60950-22, NEMA 250 Type 4X
	Network
	NIST SP500-267
Dimensions	Main unit: 16 x 46 x 109 mm (0.6 x 1.8 x 4.3 in)
	Thermal sensor unit: Depth: 38 mm (1.5 in)
	ø 112 mm (4.4 in)
	Cable: 12 m (39 ft)
Weight	Main unit: 72 g (0.16 lb)
Weight	Thermal sensor unit with cable: 530 g (1.2 lb)
Included accessories	Installation Guide, Windows decoder 1-user license, AVHS
	Authentication key
	Rotation tool
Video management software	AXIS Companion, AXIS Camera Station, video management
	software from Axis Application Development Partners available
	at axis.com/vms

[/specifications] [accesories]

Optional accessories

• AXIS T8415 Wireless Installation Tool
• AXIS Surveillance Cards
• AXIS T8120 15 W Midspan 1-port
• AXIS RJ12 Plug
• AXIS T8129 PoE Extender

[/accesories]

AXIS P1290-E 4 MM 8.3 FPS Thermal Network Camera (01168-001)

The AXIS P1290-E is a cost-effective thermal camera for indoor and outdoor use. It offers dependable detection capabilities with minimal false alarms. It is encased in a fixed dome housing. This product is a privacy-conscious sensor, especially useful in environments like schools and care facilities. Thermal imaging can identify incidents without revealing the personal information of individuals in the captured images, making it particularly beneficial for maintaining privacy. When integrated with Axis analytics, the thermal camera can trigger alerts or alarms in the event of patient or resident falls, enabling prompt intervention by staff members.

Quick Specs:

Reliable and budget-friendly detection
Thermal technology for low rate of false alarm
Functional and discreet design
Outdoor ready

Please see the related tabs for the 01168-001 datasheet and compatible accessories.

Feature	AXIS P1245 Mk II	AXIS P1265 Mk II	AXIS P1275 Mk II	AXIS P1280-E	AXIS P1290-E
Max video resolution	1920x1080	1920x1080	1920x1080	640x480	640x480
Thermal sensor resolution	-	-	-	208x156	208x156
Horizontal field of view	111	91	99 - 53	35.4 / 63	35.4
Alarm inputs/outputs	-	-	-	-	-
Zipstream	✔	✔	✔	✔	✔
Image sensor	CMOS	CMOS	CMOS	Uncooled microbolometer	Uncooled microbolometer
Thermal sensitivity (NETD)	-	-	-	<100 mK	<100 mK
