Palo Alto PA-7500-MPC-A Management Processing Card

Advanced Management for High-Performance PA-7500 Deployments

The Palo Alto PA-7500-MPC-A is built to handle the command, control, and coordination of your PA-7500 chassis. Designed for high-throughput environments, it ensures efficient load distribution and maximizes reliability for mission-critical security operations.

Key Benefits & Features

• Centralized Management Control: Consolidates administrative and orchestration tasks for precise resource allocation and consistent policy enforcement.
• High-Speed Management I/O: Two QSFP28 logging ports (100/40 Gbps) and two QSFP-DD HA ports (400/100 Gbps) for rapid log ingestion and HA synchronization.
• Flexible Management Port Options: Two SFP28 management ports (1/10/25 Gbps), plus combo RJ-45 and micro USB console ports, and a USB Type-A port.
• Redundancy & Scalability: Supports multiple MPC-As in the same chassis for high availability and failover protection.

Ideal Use Cases

• Enterprise data centers requiring robust firewall management
• Service providers with multi-tenant PA-7500 deployments
• High-security environments needing rapid log ingestion
• Organizations with zero-tolerance for downtime

Technical Specifications

• Logging Ports: 2 × QSFP28 (100/40 Gbps)
• High Availability Ports: 2 × QSFP-DD (400/100 Gbps)
• Management Ports: 2 × SFP28 (1/10/25 Gbps)
• Console Access: 1 × RJ-45 combo port, 1 × micro USB console port
• USB Ports: 1 × USB Type-A
• Chassis Compatibility: Palo Alto PA-7500 Series
• Redundancy: Supports multi-card configurations

Power Your PA-7500 with Ultimate Control

Equip your Palo Alto PA-7500 chassis with the MPC-A to achieve seamless management, high-speed logging, and secure high availability. Order today for peak performance.

Brand	Palo Alto Networks
Model	PA-7500-MPC-A
Product Type	Management Processing Card for PA-7500 Chassis
Form Factor	Modular Card (Chassis Component)
Compatible Chassis	PA-7500 Series
Cooling	Integrated with chassis cooling system

Management I/O	2 x QSFP28 logging ports (100 Gbps/40 Gbps), 2 x QSFP-DD HA ports (400 Gbps/100 Gbps), 2 x SFP28 management ports (1 Gbps/10 Gbps/25 Gbps), 1 x Combo RJ-45 console port, 1 x Micro USB console port, 1 x USB
Trusted Platform Module	Integrated TPM for secure boot, hardware root of trust, and securing system secrets
Supported Networking Features	Full Layer 3, tap, and virtual wire modes; IPv4/IPv6; NAT; VPN; VLAN; high availability clustering
Compatible Modules in Chassis	PA-7500-NPC-A, PA-7500-DPC-A, PAN-PA-7500-SFC-A
Certifications	cMETus, CB, FCC Class A, CE Class A, VCCI Class A
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	5% to 90% non-condensing

Installation Guide	Included in the box
Mounting Hardware	Included in the box
Console Cable	Included in the box
