Cisco ASR1000 Series Aggregation Services Routers



Physical specifications Note: Depth applies to chassis edge-to-edge dimension and does not include protrusions such as card handles, power-supply handles, and cable management brackets. Refer to the applicable hardware installation guide for additional details.	Height: 1.71 in. (43.43 mm) Width: 17.3 in. (439.42 mm) Depth: 18.17 in. (461.5 mm) Weight: 25 lb (11.35 kg) fully loaded Note: The Cisco ASR 1001-X Router has the route processor, ESP, and SIP integrated.
Default memory	8-GB DRAM shared across route processor, ESP, and SIP
Number of SIPs or Ethernet line cards supported	Integrated in chassis
Shared port adapters	1 single-height SPA slot
Ethernet port adapters	N/A
Cisco ASR 1000 Series ESP	Integrated in chassis
Route processor	Integrated in the chassis: Cisco ASR 1001-X Series Route Processor with Quad-Core Processor
Redundancy	Software: Yes
Built-in Gigabit Ethernet ports	Yes: 6 Gigabit Ethernet Small Form-Factor Pluggable (SFP) ports
Built-in 10 Gigabit Ethernet port	Yes: Two 10 Gigabit Ethernet Small Form-Factor Plus Pluggable (SFP+) ports Note: Built-in 10-GB ports cannot be reduced to 1-GB speed.
Network interface module	Yes
Cisco ASR 1000 Series	Cisco ASR 1001-X
ESP support	Cisco ASR 1000 Series 2.5-Gbps ESP (default) Upgradable through a software-activated feature license to 5, 10, or 20 Gbps
ESP bandwidth	2.5 to 20 Gbps
ESP memory	Share the same control memory on the route processor
SIPs and Ethernet line cards	Integrated in chassis; not upgradable
Embedded hardware-based encryption	Yes: Up to 8-Gbps crypto support throughput
Minimum Cisco IOS XE Software release	Cisco IOS XE Software Release 3.12.0
Rack-mounting	Yes: 19-inch
Wall-mounting	No
External USB flash memory	1-GB USB flash-memory support
Redundant power supply	Yes: Dual power supplies by default; option of either AC or DC power supply Note: A mix of one AC and one DC power supply is not supported.
Power input	Worldwide ranging AC input range (85 to 264 VAC) Worldwide ranging DC (-40 to -72V; 48V nominal)
Power consumption	Maximum (DC): 242W    Maximum (AC): 250W    Maximum (out): 250W
Airflow	Front-to-back
Operating temperature (nominal)	32 to 104 F (0 to 40 C)
Operating temperature (short-term)	32 to 122 F (0 to 50 C)
Operating humidity (nominal) (relative humidity)	10 to 85%
Operating humidity (short-term)	5 to 90%
Storage temperature	-40 to 150 F (-40 to 70 C)
Operating altitude	-500 to 10,000 feet (152 to 3048 meters)
EMC standards	FCC 47 CFR Part 15 Class A    VCCI Class A    AS/NSZ Class A    ICES-003 Class A    EN55022/CISPR 22 Information Technology Equipment (Emissions)    EN55024/CISPR 24 Information Technology Equipment (Immunity)    EN300 386 Telecommunications Network Equipment    (EMC)    EN50082-1/EN61000-6-1 Generic Immunity Standard
Safety Standard	UL60950-1 CSA C22.2 No. 60950-1-03 EN 60950-1 IEC 60950-1 AS/NZS 60950.1





The Cisco ASR 1000 series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), Application Visibility and Control, Performance Routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature-rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets.



Cisco ASR 1000 Series aggregation services routers aggregate multiple WAN connections and network services including encryption and traffic management, and forward them across WAN connections at line speeds from 2.5 to 200 Gbps. The routers contain both hardware and software redundancy in an industry-leading high-availability design.

The Cisco ASR 1000 series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), Application Visibility and Control, Performance Routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets.

The Cisco ASR 1000 series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), Application Visibility and Control, Performance Routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets.

The Cisco ASR 1000 series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), Application Visibility and Control, Performance Routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets.

The Cisco ASR 1000 Series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), application visibility and control, performance routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets. The Cisco ASR 1000 Series is highly reliable and demonstrates a consistently high throughput, even when new services are added.

The Cisco ASR 1000 series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), Application Visibility and Control, Performance Routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets.

The Cisco ASR 1000 series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), Application Visibility and Control, Performance Routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets.

The Cisco ASR 1000 series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), Application Visibility and Control, Performance Routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets.

The Cisco ASR 1000 series delivers multiple services embedded in the Cisco QuantumFlow Processor (QFP) at wire speeds from 2.5 to 200 Gbps. The services supported on the Cisco QFP include security services (for example, up to 78G encryption throughput and up to 6M firewall sessions), quality of service (QoS), Application Visibility and Control, Performance Routing, broadband aggregation, Cisco Unified Border Element (SP Edition), and Cisco Unified Border Element (Enterprise Edition). Additionally, Cisco ASR 1000 offers feature rich scalable Data Center Interconnect (DCI) solutions that include Overlay Transport Virtualization (OTV) and Virtual Private Label Switching (VPL) to connect geographically dispersed data centers. Advanced routing techniques like Locator Identity Separation Protocol (LISP) allow host mobility within and across subnets.

The latest additions to the Cisco ASR 1000 Series are the Cisco ASR 1002-HX Router and the Cisco ASR 1001-HX Router. Both new routers support up to 100 Gbps in a 2-rack-unit (2RU) and 60 Gbps in a 1-rack-unit (1RU) form factor, respectively. The ASR 1002-HX has 8 built-in 10-Gigabit Ethernet (GE) ports and 8 1-GE ports, with the Ethernet port adapter (EPA) slot for expansion. The ASR 1001-HX has 4 built-in 10-GE ports, 8 1-GE ports, and 4 configurable 10-GE or 1-GE ports.



Physical specifications Note: Depth applies to chassis edge-to-edge dimension and does not include protrusions such as card handles, power-supply handles, and cable management brackets. Refer to the applicable hardware installation guide for additional details.	Height: 3.5 in. (88.9 mm) Width: 17.2 in. (437.4 mm) Depth: 18.15 in. (461.0 mm) Weight:    38.25 lb (17.36 kg) (with dual AC power supply and SPA blank covers)    39.05 lb (17.72 kg) (with dual DC power supply and blank covers)    No SPAs included Note: The Cisco ASR 1002-X has the route processor, ESP, and SIP integrated.
Default memory	4-GB DRAM shared across route processor, ESP, and SIP
Number of SIPs or Ethernet line cards supported	Integrated in chassis
Shared port adapters	3 SPA slots
Ethernet port adapters	N/A
Cisco ASR 1000 Series ESP	Integrated in chassis
Route processor	Integrated in the chassis: Cisco ASR 1002-X Series Route Processor with Quad Core Processor
Redundancy	Software: Yes
Built-in Gigabit Ethernet ports	Yes: 6 Gigabit Ethernet SFP ports
Built-in 10 Gigabit Ethernet port	No
Network interface module	No
Cisco ASR 1000 Series	Cisco ASR 1002-X
ESP support	Cisco ASR 1002-X ESP with 5-Gbps (default) Upgradable through software-activated feature license to 10, 20, or 36 Gbps
ESP bandwidth	5 to 36 Gbps
ESP memory	Share the same control memory on the route processor
SIPs and Ethernet line cards	Integrated in chassis: not upgradable
Embedded hardware-based encryption	Yes: Up to 4-Gbps crypto support throughput
Minimum Cisco IOS XE Software release	Cisco IOS XE Software Release 3.7.0S
Rack-mounting	Yes: 19-inch
Wall-mounting	No
External USB flash memory	1-GB USB flash-memory support
Redundant power supply	Same as for Cisco ASR 1002
Power input	Same as for Cisco ASR 1002
Power consumption	Maximum (DC): 590W    Maximum (AC): 560W    Maximum (out): 470W
Airflow	Front-to-back
Operating temperature (nominal)	32 to 104 F (0 to 40 C)
Operating temperature (short-term)	32 to 122 F (0 to 50 C)
Operating humidity (nominal) (relative humidity)	10 to 85%
Operating humidity (short-term)	5 to 90%
Storage temperature	-40 to 150 F (-40 to 70 C)
Storage humidity (relative humidity)	5 to 95%
Operating altitude	-500 to 10,000 feet (152 to 3048 meters)
Network Equipment Building Standards (NEBS)	GR-1089 and GR-63
EMC standards	Same as for Cisco ASR 1001-X
Safety Standard	UL60950-1 CSA C22.2 No. 60950-1-03 EN 60950-1 IEC 60950-1 AS/NZS 60950.1







The Cisco ASR 1002-X router offers embedded services for enterprise and service provider networks in a 2-rack unit small form factor. It is integrated with a route processor, embedded services processor, and SPA interface processor. Running on Cisco IOS XE software, the Cisco ASR 1002-X supports software redundancy without redundant hardware. The ASR 1002-X is ideal for high-end enterprise branch offices, and as a high-performing edge solution for a private WAN.

The Cisco ASR 1002-X router offers embedded services for enterprise and service provider networks in a 2-rack unit small form factor. It is integrated with a route processor, embedded services processor, and SPA interface processor. The ASR 1002-X is ideal for high-end enterprise branch offices, and as a high-performing edge solution for a private WAN.

The Cisco ASR 1002-X router offers embedded services for enterprise and service provider networks in a 2-rack unit small form factor. It is integrated with a route processor, embedded services processor, and SPA interface processor. Running on Cisco IOS XE software, the Cisco ASR 1002-X supports software redundancy without redundant hardware. The ASR 1002-X is ideal for high-end enterprise branch offices, and as a high-performing edge solution for a private WAN.

The Cisco ASR 1002-X router offers embedded services for enterprise and service provider networks in a 2-rack unit small form factor. It is integrated with a route processor, embedded services processor, and SPA interface processor. The ASR 1002-X is ideal for high-end enterprise branch offices, and as a high-performing edge solution for a private WAN.
