SG220 - SF220



Powerful Cisco SG220-26-K9 Switch for Data, Voice & Security

Cisco SG220-26-K9 Switch is designed for bridging the gap between Managed and smart switches. It is affordably priced like smart switches and offers customers the best of both worlds.

Key Benefits of Cisco SG220-26-K9 Switch

Cisco SG220-26-K9 Switch combines powerful performance with reliability and provides the best level of security, management, and scalability for Managed switches. Cisco SG220-26-K9 Switch provides the management capabilities, enhanced security, and quality of service features required for business-class data support, voice, security, and wireless service support.

Cisco Small Business 220 series smart plus switches bridge the gap between Managed and smart switches to offer customers the best of both worlds. Combining powerful performance with reliability, they provide the higher levels of security, management, and scalability you expect from Managed switches, affordably priced like smart switches. The Cisco 220 series switches provide the management capabilities, enhanced security, and quality of service features needed to support business-class data, voice, security, and wireless services.

Device type	Switch - 26 ports
Enclosure type	Desktop, rack-mountable - 1U
Ports	24 x 10/100/1000 + 2 x combo Gigabit SFP
Power over Ethernet (PoE)	PoE and PoE+
Performance	Switching capacity: 38.69 Mpps ; Forwarding performance (64-byte packet size): 52 Gbps
MAC address table size	8192 entries
Capacity	256 active VLANs
Remote management protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI
Jumbo frame support	9 KB
Authentication method	Secure Shell (SSH), RADIUS, TACACS+
Features	Layer 2 switching, DHCP support, BOOTP support, VLAN support, IGMP snooping, IGMP Querier, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, IPv6 support, SNTP support, STP support, RSTP, MSTP, TFTP support, HTTPS, QoS, acces control list, QinQ VLAN, guest VLAN, auto voice VLAN, GVRP/GARP, BPDU Guard, SSH, SSL, Jumbo Frames support, MLD snooping, SNMP, RMON, SNTP, Cisco Discovery Protocol
Compliant standards	IEEE 802.3, 802.3u, 802.3z, 802.3az Energy Efficient Ethernet, 802.1D, 802.1Q, 802.3ab, 802.1p, 802.3x, 802.3ad (LACP), 802.1x, 802.1w RSTP, IEEE 802.1s MSTP, 802.3af PoE, 802.3at PoE
RAM	128 MB
Flash memory	32 MB
Status indicators	Link activity, port transmission speed, system, PoE
Interfaces	26 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45 ? 2 x SFP (mini-GBIC)
Power device	Power supply - internal
Voltage required	100-240 V, 50-60 Hz, Internal
Width	17.3 in (440 mm)
Depth	9.9 in (250 mm)
Height	1.7 in (44 mm)
Weight	8.16 lb (3.7 kg)
Rack mounting kit	Included
Compliant standards	UL 60950, FCC Part 15 A, CSA 22.2
Localization	English, Chinese (simplified)
Minimum operating temperature	32F (0C)
Maximum operating temperature	122F (50C)
Humidity range operating	10% to 90% (relative, non-condensing)
Minimum storage temperature	-4F (-20C)
Maximum storage temperature	158F (70C)
Humidity range storage	10% to 90% (relative, non-condensing)







Cisco Small Business 220 series smart plus switches bridge the gap between Managed and smart switches to offer customers the best of both worlds. Combining powerful performance with reliability, they provide the higher levels of security, management, and scalability you expect from Managed switches, affordably priced like smart switches. The Cisco 220 series switches provide the management capabilities, enhanced security, and quality of service features needed to support business-class data, voice, security, and wireless services.

Device type	Switch - 24 ports
Enclosure type	Desktop, rack-mountable - 1U
Ports	24 x 10/100 + 2 x combo Gigabit SFP
Power over Ethernet (PoE)	N/A
Performance	Switching capacity: 6.55 Mpps Forwarding performance (64-byte packet size): 8.8 Gbps
MAC address table size	8192 entries
Capacity	256 active VLANs
Remote management protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI
Jumbo frame support	9 KB
Authentication method	Secure Shell (SSH), RADIUS, TACACS+
Features	Layer 2 switching, DHCP support, BOOTP support, VLAN support, IGMP snooping, IGMP Querier, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, IPv6 support, SNTP support, STP support, RSTP, MSTP, TFTP support, HTTPS, QoS, access control list, QinQ VLAN, guest VLAN, auto voice VLAN, GVRP/GARP, BPDU Guard, SSH, SSL, Jumbo Frames support, MLD snooping, SNMP, RMON, SNTP, Cisco Discovery Protocol
Compliant standards	IEEE 802.3, 802.3u, 802.3z, 802.3az Energy Efficient Ethernet, 802.1D, 802.1Q, 802.3ab, 802.1p, 802.3x, 802.3ad (LACP), 802.1x, 802.1w RSTP, IEEE 802.1s MSTP
RAM	128 MB
Flash memory	32 MB
Status indicators	Link activity, port transmission speed, system
Interfaces	24 x 10BASE-T/100BASE-TX - RJ-45  2 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45  2 x SFP (mini-GBIC)
Power device	Power supply - internal
Voltage required	100-240 V, 50-60 Hz, Internal
Width	17.3 in (440 mm)
Depth	7.9 in (201 mm)
Height	1.7 in (44 mm)
Weight	5.73 (2.6 kg)
Rack mounting kit	Included
Compliant standards	UL 60950, FCC Part 15 A, CSA 22.2
Localization	English, Chinese (simplified)
Minimum operating temperature	32F (0c)
Maximum operating temperature	122F (50C)
Humidity range operating	10% to 90% (relative, non-condensing)
Minimum storage temperature	-4F (-20C)
Maximum storage temperature	158F (70C)
Humidity range storage	10% to 90% (relative, non-condensing)







Use Cisco SF220-24 Switch for Enhanced Security & Scalability

Cisco SF220-24 Switch is a smart choice for small businesses to bridge the gap between managed and smart switches and offer the users the best of both worlds.

Key Benefits of Cisco SF220-24 Switch

Cisco SF220-24 Switch combines powerful performance with reliability. It is built to provide higher levels of security, management, and scalability one can expect from managed switches. Affordably priced, this smart Cisco SF220-24 Switch can provide outstanding management capabilities, enhanced security, and quality of service features required for business-class data support, plus voice, security, and wireless services.

Cisco Small Business 220 series smart plus switches bridge the gap between Managed and smart switches to offer customers the best of both worlds. Combining powerful performance with reliability, they provide the higher levels of security, management, and scalability you expect from Managed switches, affordably priced like smart switches. The Cisco 220 series switches provide the management capabilities, enhanced security, and quality of service features needed to support business-class data, voice, security, and wireless services.

Cisco SF220-24P-K9 Switch Specifications



Product code	SF220-24P-K9
Device type	Switch - 24 ports
Enclosure type	Desktop, rack-mountable - 1U
Ports	24 x 10/100 + 2 x combo Gigabit SFP
Power over Ethernet (PoE)	PoE and PoE+
Performance	Switching capacity: 6.55 Mpps  Forwarding performance (64-byte packet size): 8.8 Gbps
MAC address table size	8192 entries
Capacity	256 active VLANs
Remote management protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI
Jumbo frame support	9 KB
Authentication method	Secure Shell (SSH), RADIUS, TACACS+
Features	Layer 2 switching, DHCP support, BOOTP support, VLAN support, IGMP snooping, IGMP Querier, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, IPv6 support, SNTP support, STP support, RSTP, MSTP, TFTP support, HTTPS, QoS, acces control list, QinQ VLAN, guest VLAN, auto voice VLAN, GVRP/GARP, BPDU Guard, SSH, SSL, Jumbo Frames support, MLD snooping, SNMP, RMON, SNTP, Cisco Discovery Protocol
Compliant standards	IEEE 802.3, 802.3u, 802.3z, 802.3az Energy Efficient Ethernet, 802.1D, 802.1Q, 802.3ab, 802.1p, 802.3x, 802.3ad (LACP), 802.1x, 802.1w RSTP, IEEE 802.1s MSTP, 802.3af PoE, 802.3at PoE
RAM	128 MB
Flash memory	32 MB
Status indicators	Link activity, port transmission speed, system, PoE
Interfaces	24 x 10BASE-T/100BASE-TX - RJ-45  2 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45  2 x SFP (mini-GBIC)
Power device	Power supply - internal
Voltage required	100-240 V, 50-60 Hz, Internal
Width	17.3 in (440 mm)
Depth	9.9 in (250 mm)
Height	1.7 in (44 mm)
Weight	8.02 lb (3.64 kg)
Rack mounting kit	Included
Compliant standards	UL 60950, FCC Part 15 A, CSA 22.2
Minimum operating temperature	32F (0C)
Maximum operating temperature	122F (50C)
Humidity range operating	10% to 90% (relative, non-condensing)
Minimum storage temperature	-4F (-20C)
Maximum storage temperature	158F (70C)
Humidity range storage	10% to 90% (relative, non-condensing)



Cisco SF220-24P-K9 Switch for SMBs

Cisco SF220-24P-K9 Switch features 24-port Fast Ethernet switch with Power over Ethernet. It comes in a combination of powerful performance and reliability with a set of features that would be necessary for a solid business network.

Key Benefits of Cisco SF220-24P-K9 Switch

Cisco SF220-24P-K9 Switch offers simple setup and configuration with intuitive and browser-based tools. You will get outstanding value, comprehensive features designed for increasing businesses while maintaining the affordability of smart switches. Cisco SF220-24P-K9 Switch is available at affordable cost and comes equipped with security, performance, and ease of use to help build a solid business network.





Product code	SF220-24P-K9
Device type	Switch - 24 ports
Enclosure type	Desktop, rack-mountable - 1U
Ports	24 x 10/100 + 2 x combo Gigabit SFP
Power over Ethernet (PoE)	PoE and PoE+
Capacity	256 active VLANs
RAM	128 MB



Cisco Small Business 220 series smart plus switches bridge the gap between Managed and smart switches to offer customers the best of both worlds. Combining powerful performance with reliability, they provide the higher levels of security, management, and scalability you expect from Managed switches, affordably priced like smart switches. The Cisco 220 series switches provide the management capabilities, enhanced security, and quality of service features needed to support business-class data, voice, security, and wireless services.

Device type	Switch - 50 ports
Enclosure type	Desktop, rack-mountable - 1U
Ports	48 x 10/100/1000 + 2 x combo Gigabit SFP
Power over Ethernet (PoE)	PoE and PoE+
Performance	Switching capacity: 74.41 Mpps ; Forwarding performance (64-byte packet size): 100 Gbps
MAC address table size	8192 entries
Capacity	256 active VLANs
Remote management protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI
Jumbo frame support	9 KB
Authentication method	Secure Shell (SSH), RADIUS, TACACS+
Features	Layer 2 switching, DHCP support, BOOTP support, VLAN support, IGMP snooping, IGMP Querier, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, IPv6 support, SNTP support, STP support, RSTP, MSTP, TFTP support, HTTPS, QoS, acces control list, QinQ VLAN, guest VLAN, auto voice VLAN, GVRP/GARP, BPDU Guard, SSH, SSL, Jumbo Frames support, MLD snooping, SNMP, RMON, SNTP, Cisco Discovery Protocol
Compliant standards	IEEE 802.3, 802.3u, 802.3z, 802.3az Energy Efficient Ethernet, 802.1D, 802.1Q, 802.3ab, 802.1p, 802.3x, 802.3ad (LACP), 802.1x, 802.1w RSTP, IEEE 802.1s MSTP, 802.3af PoE, 802.3at PoE
RAM	128 MB
Flash memory	32 MB
Status indicators	Link activity, port transmission speed, system, PoE
Interfaces	50 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45 ; 2 x SFP (mini-GBIC)
Power device	Power supply - internal
Voltage required	100-240 V, 50-60 Hz, Internal
Width	17.3 in (440 mm)
Depth	13.8 in (350 mm)
Height	1.7 in (44 mm)
Weight	11.64 lb (5.28 kg)
Rack mounting kit	Included
Compliant standards	UL 60950, FCC Part 15 A, CSA 22.2
Localization	English, Chinese (simplified)
Minimum operating temperature	32F (0C)
Maximum operating temperature	122F (50C)
Humidity range operating	10% to 90% (relative, non-condensing)
Minimum storage temperature	-4F (-20C)
Maximum storage temperature	158F (70C)
Humidity range storage	10% to 90% (relative, non-condensing)







Cisco Small Business 220 series smart plus switches bridge the gap between Managed and smart switches to offer customers the best of both worlds. Combining powerful performance with reliability, they provide the higher levels of security, management, and scalability you expect from Managed switches, affordably priced like smart switches. The Cisco 220 series switches provide the management capabilities, enhanced security, and quality of service features needed to support business-class data, voice, security, and wireless services.

Cisco Small Business 220 series smart plus switches bridge the gap between managed and smart switches to offer customers the best of both worlds. Combining powerful performance with reliability, they provide the higher levels of security, management, and scalability you expect from managed switches, affordably priced like smart switches. The Cisco 220 series switches provide the management capabilities, enhanced security, and quality of service features needed to support business-class data, voice, security, and wireless services.
