Ethernet Ports | 12 x 10/100/1000 Gigabit Ethernet |
PoE Output Ports |
12 PoE+ |
Uplinks | 2 x 1G copper plus 2 x 10G SFP+ |
Default Software | IP Base (IP Services with RTU License) |
Powering Option | Internal power supply |
Available PoE Power (W) | 240W |
Can Switch Be Powered with Uplinks? | No |
Forwarding Bandwidth | 34 Gbps |
Switching Bandwidth (full-duplex capacity) | 68 Gbps |
Flash memory | 128 MB |
Memory DRAM | 512 MB |
Max VLANs | 1023 |
VLAN IDs | 4000 |
Maximum transmission unit (MTU) | Up to 9000 bytes |
Jumbo frames | 9198 bytes |
Forwarding rate 64 Byte Packet | 50.6 mpps |
Dimensions (H x W x D) |
1.75 x 10.6 x 9.4 in (4.44 x 26.9 x 23.8 cm) |
Operating* temperature up to 5000 ft (1524 m) | -5C to +45C (+23F to +113F) |
Operating* temperature up to 10,000 ft (3048 m) | -5C to +45C (+23F to +113F) |
Storage temperature up to 15,000 ft (4572 m) | -25C to +70C (-13F to +158F) |
Operating altitude | Up to 3048 m (Up to 10,000 ft) |
Storage altitude | Up to 4000 m (Up to 15,000 ft) |
Operating relative humidity | 5% to 95% noncondensing |
Storage relative humidity | 5% to 95% noncondensing |
MTBF | 528,480 |
Management | BRIDGE-MIB CISCO-CABLE-DIAG-MIB CISCO-CDP-MIB CISCO-CLUSTER-MIB CISCO-CONFIG-COPY-MIB CISCO-CONFIG-MAN-MIB CISCO-DHCP-SNOOPING-MIB CISCO-ENTITY-VENDORTYPE-OID-MIB CISCO-ENVMON-MIB CISCO-ERR-DISABLE-MIB CISCO-FLASH-MIB CISCO-FTP-CLIENT-MIB CISCO-IGMP-FILTER-MIB CISCO-IMAGE-MIB CISCO-IP-STAT-MIB CISCO-LAG-MIB CISCO-MAC-NOTIFICATION-MIB CISCO-MEMORY-POOL-MIB CISCO-PAGP-MIB CISCO-PING-MIB CISCO-POE-EXTENSIONS-MIB CISCO-PORT-QOS-MIB CISCO-PORT-SECURITY-MIB CISCO-PORT-STORM-CONTROL-MIB CISCO-PRODUCTS-MIB CISCO-PROCESS-MIB CISCO-RTTMON-MIB CISCO-SMI-MIB CISCO-STP-EXTENSIONS-MIB CISCO-SYSLOG-MIB CISCO-TC-MIB CISCO-TCP-MIB CISCO-UDLDP-MIB CISCO-VLAN-IFTABLE RELATIONSHIP-MIB CISCO-VLAN-MEMBERSHIP-MIB CISCO-VTP-MIB ENTITY-MIB ETHERLIKE-MIB IEEE8021-PAE-MIB IEEE8023-LAG-MIB IF-MIB INET-ADDRESS-MIB OLD-CISCO-CHASSIS-MIB OLD-CISCO-FLASH-MIB OLD-CISCO-INTERFACES-MIB OLD-CISCO-IP-MIB OLD-CISCO-SYS-MIB OLD-CISCO-TCP-MIB OLD-CISCO-TS-MIB RFC1213-MIB RMON-MIB RMON2-MIB SNMP-FRAMEWORK-MIB SNMP-MPD-MIB SNMP-NOTIFICATION-MIB SNMP-TARGET-MIB SNMPv2-MIB TCP-MIB UDP-MIB ePM MIB |
Standards | IEEE 802.1D Spanning Tree Protocol IEEE 802.1p CoS Prioritization IEEE 802.1Q VLAN IEEE 802.1s IEEE 802.1w IEEE 802.1x IEEE 802.1AB (LLDP) IEEE 802.3ad IEEE 802.3af IEEE 802.3ah (100BASE-X single/multimode fiber only) IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports IEEE 802.3 10BASE-T specification IEEE 802.3u 100BASE-TX specification IEEE 802.3ab 1000BASE-T specification IEEE 802.3z 1000BASE-X specification 100BASE-BX (SFP) 100BASE-FX (SFP) 100BASE-LX (SFP) 1000BASE-BX (SFP) 1000BASE-SX (SFP) 1000BASE-LX/LH (SFP) 1000BASE-ZX (SFP) 1000BASE-CWDM SFP 1470 nm 1000BASE-CWDM SFP 1490 nm 1000BASE-CWDM SFP 1510 nm 1000BASE-CWDM SFP 1530 nm 1000BASE-CWDM SFP 1550 nm 1000BASE-CWDM SFP 1570 nm 1000BASE-CWDM SFP 1590 nm 1000BASE-CWDM SFP 1610 nm RMON I and II standards SNMPv1, SNMPv2c, and SNMPv3 |
RFC compliance | RFC 768: UDP RFC 783: TFTP RFC 791: IP RFC 792: ICMP RFC 793: TCP RFC 826: ARP RFC 854: Telnet RFC 951: Bootstrap Protocol RFC 1542: BOOTP Extensions RFC 959: FTP RFC 1058: RIP Routing RFC 1112: IP Multicast and IGMP RFC 1157: SNMPv1 RFC 1166: IP Addresses RFC 1253: OSPF Routing RFC 1256: ICMP Router Discovery RFC 1305: NTP RFC 1492: TACACS+ RFC 1493: Bridge MIB RFC 1542: Bootstrap Protocol RFC 1583: OSPFv2 RFC 1643: Ethernet Interface MIB RFC 1723: RIPv2 Routing RFC 1757: RMON RFC 1812: IP Routing RFC 1901: SNMPv2C RFC 1902-1907: SNMPv2 RFC 1981: MTU Path Discovery IPv6 FRC 2068: HTTP RFC 2080: RIP for IPv6 RFC 2131: DHCP RFC 2138: RADIUS RFC 2233: IF MIB RFC 2236: IP Multicast RFC 2328: OSPFv2 RFC 2273-2275: SNMPv3 RFC 2373: IPv6 Aggregatable Addrs RFC 2453: RIPv2 Routing RFC 2460: IPv6 protocol RFC 2461: IPv6 Neighbor Discovery RFC 2462: IPv6 Autoconfiguration RFC 2463: ICMP IPv6 RFC 2474: DiffServ Precedence RFC 2597: Assured Forwarding RFC 2598: Expedited Forwarding RFC 2571: SNMP Management RFC 2740: OSPF for IPv6 RFC 3046: DHCP Relay Agent Information Option RFC 3101, 1587: NSSAs RFC 3376: IGMPv3 RFC 3580: 802.1x RADIUS |
Safety standards | UL 60950-1 CAN/CSA 22.2 No. 60950-1 EN 60950-1 IEC 60950-1 CE Marking GB 4943 IEC 60825 |
Electromagnetic emissions certifications | FCC Part 15, CFR 47, Class A, North America EN/IEC 61000-4-5 EN 55022 (CISPR22) and EN 55024 (CISPR24), CE marking, European Union AS/NZS, Class A, CISPR22:2004 or EN55022, Australia and New Zealand VCCI Class A, V-3/2007.04, Japan KCC (Formerly MIC, GB17625.1-1998) Class A, KN24/KN22, Korea ANATEL, Brazil CCC, China GOST, Russia |
Environmental | Reduction of Hazardous Substances (ROHS) 6 |
Telco | Common Language Equipment Identifier (CLEI) code |
Cisco WS-C3560CX-12PD-S Switch is perfect for building an effective work environment and creating open workspaces without having to tear down office walls. This Cisco switch features quiet, fan-less design and can create many possibilities to design workspaces. Install them anywhere outside wiring closet, in carpeted areas such as offices, conference rooms, classrooms, and retail stores for quick and flexible connections.
Cisco WS-C3560CX-12PD-S Switch lets you rearrange rooms and floors without having to change your cabling infrastructure. It also allows you to consolidate cabling for big savings, which is why Cisco WS-C3560CX-12PD-S Switch is a perfect choice for running multiple Ethernet cables from endpoints like IP phones and Wi-Fi access points to a wiring closet. You just connect devices over a few feet of cabling to a nearby 3560-CX switch and then connect the compact switch to the wiring closet with a single Ethernet or fiber cable. This compact switch setup can save cost incredibly.
Feature Set | IP Base |
Uplink Interfaces | 2 x 1G copper plus 2 x 10G SFP+ |
Ports | 12 x 10/100/1000 Gigabit Ethernet |
PoE Output Ports | 12 PoE+ |
Available PoE Power | 240W |
Switching Bandwidth (full-duplex capacity) | 68 Gbps |
RAM | 512 MB |
Flash Memory | 128 MB |
Dimensions | 4.44 x 26.9 x 23.8 cm |
Package Weight | 4.65 Kg |
Ethernet Ports | 12 x 10/100/1000 Gigabit Ethernet |
PoE Output Ports |
NA |
Available PoE Power |
NA |
Default Software | IP Base (IP Services with RTU License) |
Powering Option | Internal power supply |
Available PoE Power (W) | 0W |
Can Switch Be Powered with Uplinks? | No |
Forwarding Bandwidth | 16 Gbps |
Switching Bandwidth (full-duplex capacity) | 32 Gbps |
Flash memory | 128 MB |
Memory DRAM | 512 MB |
Max VLANs | 1023 |
VLAN IDs | 4000 |
Maximum transmission unit (MTU) | Up to 9000 bytes |
Jumbo frames | 9198 bytes |
Forwarding rate 64 Byte Packet | 23.8 mpps |
Dimensions (H x W x D) |
1.75 x 10.6 x 8.4 in (4.44 x 26.9 x 21.3 cm) |
Weight | 3.9 lb (1.77 Kg) |
Operating* temperature up to 5000 ft (1524 m) | -5C to +45C (+23F to +113F) |
Operating* temperature up to 10,000 ft (3048 m) | -5C to +45C (+23F to +113F) |
Storage temperature up to 15,000 ft (4572 m) | -25C to +70C (-13F to +158F) |
Operating altitude | Up to 3048 m (Up to 10,000 ft) |
Storage altitude | Up to 4000 m (Up to 15,000 ft) |
Operating relative humidity | 5% to 95% noncondensing |
Storage relative humidity | 5% to 95% noncondensing |
MTBF | 755,270 |
Management | BRIDGE-MIB CISCO-CABLE-DIAG-MIB CISCO-CDP-MIB CISCO-CLUSTER-MIB CISCO-CONFIG-COPY-MIB CISCO-CONFIG-MAN-MIB CISCO-DHCP-SNOOPING-MIB CISCO-ENTITY-VENDORTYPE-OID-MIB CISCO-ENVMON-MIB CISCO-ERR-DISABLE-MIB CISCO-FLASH-MIB CISCO-FTP-CLIENT-MIB CISCO-IGMP-FILTER-MIB CISCO-IMAGE-MIB CISCO-IP-STAT-MIB CISCO-LAG-MIB CISCO-MAC-NOTIFICATION-MIB CISCO-MEMORY-POOL-MIB CISCO-PAGP-MIB CISCO-PING-MIB CISCO-POE-EXTENSIONS-MIB CISCO-PORT-QOS-MIB CISCO-PORT-SECURITY-MIB CISCO-PORT-STORM-CONTROL-MIB CISCO-PRODUCTS-MIB CISCO-PROCESS-MIB CISCO-RTTMON-MIB CISCO-SMI-MIB CISCO-STP-EXTENSIONS-MIB CISCO-SYSLOG-MIB CISCO-TC-MIB CISCO-TCP-MIB CISCO-UDLDP-MIB CISCO-VLAN-IFTABLE RELATIONSHIP-MIB CISCO-VLAN-MEMBERSHIP-MIB CISCO-VTP-MIB ENTITY-MIB ETHERLIKE-MIB IEEE8021-PAE-MIB IEEE8023-LAG-MIB IF-MIB INET-ADDRESS-MIB OLD-CISCO-CHASSIS-MIB OLD-CISCO-FLASH-MIB OLD-CISCO-INTERFACES-MIB OLD-CISCO-IP-MIB OLD-CISCO-SYS-MIB OLD-CISCO-TCP-MIB OLD-CISCO-TS-MIB RFC1213-MIB RMON-MIB RMON2-MIB SNMP-FRAMEWORK-MIB SNMP-MPD-MIB SNMP-NOTIFICATION-MIB SNMP-TARGET-MIB SNMPv2-MIB TCP-MIB UDP-MIB ePM MIB |
Standards | IEEE 802.1D Spanning Tree Protocol IEEE 802.1p CoS Prioritization IEEE 802.1Q VLAN IEEE 802.1s IEEE 802.1w IEEE 802.1x IEEE 802.1AB (LLDP) IEEE 802.3ad IEEE 802.3af IEEE 802.3ah (100BASE-X single/multimode fiber only) IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports IEEE 802.3 10BASE-T specification IEEE 802.3u 100BASE-TX specification IEEE 802.3ab 1000BASE-T specification IEEE 802.3z 1000BASE-X specification 100BASE-BX (SFP) 100BASE-FX (SFP) 100BASE-LX (SFP) 1000BASE-BX (SFP) 1000BASE-SX (SFP) 1000BASE-LX/LH (SFP) 1000BASE-ZX (SFP) 1000BASE-CWDM SFP 1470 nm 1000BASE-CWDM SFP 1490 nm 1000BASE-CWDM SFP 1510 nm 1000BASE-CWDM SFP 1530 nm 1000BASE-CWDM SFP 1550 nm 1000BASE-CWDM SFP 1570 nm 1000BASE-CWDM SFP 1590 nm 1000BASE-CWDM SFP 1610 nm RMON I and II standards SNMPv1, SNMPv2c, and SNMPv3 |
RFC compliance | RFC 768: UDP RFC 783: TFTP RFC 791: IP RFC 792: ICMP RFC 793: TCP RFC 826: ARP RFC 854: Telnet RFC 951: Bootstrap Protocol RFC 1542: BOOTP Extensions RFC 959: FTP RFC 1058: RIP Routing RFC 1112: IP Multicast and IGMP RFC 1157: SNMPv1 RFC 1166: IP Addresses RFC 1253: OSPF Routing RFC 1256: ICMP Router Discovery RFC 1305: NTP RFC 1492: TACACS+ RFC 1493: Bridge MIB RFC 1542: Bootstrap Protocol RFC 1583: OSPFv2 RFC 1643: Ethernet Interface MIB RFC 1723: RIPv2 Routing RFC 1757: RMON RFC 1812: IP Routing RFC 1901: SNMPv2C RFC 1902-1907: SNMPv2 RFC 1981: MTU Path Discovery IPv6 FRC 2068: HTTP RFC 2080: RIP for IPv6 RFC 2131: DHCP RFC 2138: RADIUS RFC 2233: IF MIB RFC 2236: IP Multicast RFC 2328: OSPFv2 RFC 2273-2275: SNMPv3 RFC 2373: IPv6 Aggregatable Addrs RFC 2453: RIPv2 Routing RFC 2460: IPv6 protocol RFC 2461: IPv6 Neighbor Discovery RFC 2462: IPv6 Autoconfiguration RFC 2463: ICMP IPv6 RFC 2474: DiffServ Precedence RFC 2597: Assured Forwarding RFC 2598: Expedited Forwarding RFC 2571: SNMP Management RFC 2740: OSPF for IPv6 RFC 3046: DHCP Relay Agent Information Option RFC 3101, 1587: NSSAs RFC 3376: IGMPv3 RFC 3580: 802.1x RADIUS |
Safety standards | UL 60950-1 CAN/CSA 22.2 No. 60950-1 EN 60950-1 IEC 60950-1 CE Marking GB 4943 IEC 60825 |
Electromagnetic emissions certifications | FCC Part 15, CFR 47, Class A, North America EN/IEC 61000-4-5 EN 55022 (CISPR22) and EN 55024 (CISPR24), CE marking, European Union AS/NZS, Class A, CISPR22:2004 or EN55022, Australia and New Zealand VCCI Class A, V-3/2007.04, Japan KCC (Formerly MIC, GB17625.1-1998) Class A, KN24/KN22, Korea ANATEL, Brazil CCC, China GOST, Russia |
Environmental | Reduction of Hazardous Substances (ROHS) 6 |
Telco | Common Language Equipment Identifier (CLEI) code |
Cisco WS-C3560CX-12TC-S Switch is a small form-factor Gigabit Ethernet and Fast Ethernet switch. It is designed for deployments outside the wiring closet. Cisco WS-C3560CX-12TC-S Switch allows enterprise and commercial customers to deliver advanced security services, unified communications, wireless, IP video cameras, and other applications for the office workspace, branch office, classroom, cruise ship, and other wiring-constrained environments.
Cisco WS-C3560CX-12TC-S Switch is designed for effective work environment to encourage collaboration. It can create many possibilities for designing workspaces, with their quiet, fanless solution. Cisco WS-C3560CX-12TC-S Switch can reside nearly anywhere outside a wiring closet. Cisco WS-C3560CX-12TC-S Switch is built to enable users to bring sensors, LED lights, building controllers, and other IoT devices onto the network using Power over Ethernet (PoE). This switch can provide up to 240 watts of power for PoE devices - twice the capacity of current switches.
Feature Set | IP Base |
Uplink Interfaces | 2 x 1G copper plus 2 x 1G SFP |
Ports | 12 x 10/100/1000 Gigabit Ethernet |
Forwarding Bandwidth | 16 Gbps |
Switching Bandwidth (full-duplex capacity) | 32 Gbps |
RAM | 512 MB |
Flash Memory | 128 MB |
Dimensions | 4.44 x 26.9 x 21.3 cm |
Package Weight | 4.65 Kg |
PoE Output Ports |
12 PoE+ |
Default Software | IP Base (IP Services with RTU License) |
Powering Option | Internal power supply |
Can Switch Be Powered with Uplinks? | No |
Memory DRAM | 512 MB |
Max VLANs | 1023 |
VLAN IDs | 4000 |
Maximum transmission unit (MTU) | Up to 9000 bytes |
Jumbo frames | 9198 bytes |
Forwarding rate 64 Byte Packet | 23.8 mpps |
Weight | 5.1 lb (2.31 Kg) |
Operating* temperature up to 5000 ft (1524 m) | -5C to +45C (+23F to +113F) |
Operating* temperature up to 10,000 ft (3048 m) | -5C to +45C (+23F to +113F) |
Storage temperature up to 15,000 ft (4572 m) | -25C to +70C (-13F to +158F) |
Operating altitude | Up to 3048 m (Up to 10,000 ft) |
Storage altitude | Up to 4000 m (Up to 15,000 ft) |
Operating relative humidity | 5% to 95% noncondensing |
Storage relative humidity | 5% to 95% noncondensing |
Cisco WS-C3560CX-12PC-S Catalyst Switch helps develop an effective work environment without having to tear down office walls for open workspace creation. Use this switching system to design a quiet, fan-less workspace with several other possibilities. These switches can reside nearly anywhere outside a wiring closet.
Cisco WS-C3560CX-12PC-S Catalyst Switch is installable in carpeted areas such as offices, conference rooms, classrooms, and retail stores for quick, flexible connections. Users can rearrange their rooms and floors without changing their cabling infrastructure.
Cisco WS-C3560CX-12PC-S Catalyst Switch is useful for running multiple Ethernet cables from endpoints like IP phones and Wi-Fi access points to a wiring closet. To build such a work environment, connect the compact switch to the wiring closet with a single Ethernet or fiber cable.
Feature Set | IP Base |
Uplink Interfaces | 2 x 1G copper plus 2 x 1G SFP |
Ports | 12 x 10/100/1000 Gigabit Ethernet |
PoE+ Power | 240W |
Forwarding Bandwidth | 16 Gbps |
Switching Bandwidth (full-duplex capacity) | 32 Gbps |
RAM | 512 MB |
Flash Memory | 128 MB |
Dimensions | 4.44 x 26.9 x 23.8 cm |
Package Weight | 4.65 Kg |
PoE Output Ports |
8 PoE+ |
Available PoE Power |
240W |
Uplinks | 2 x 1G copper plus 2 x 1G SFP |
Default Software | IP Base (IP Services with RTU License) |
Powering Option | Internal power supply |
Available PoE Power (W) | 240W |
Can Switch Be Powered with Uplinks? | No |
Forwarding Bandwidth | 16 Gbps |
Switching Bandwidth (full-duplex capacity) | 32 Gbps |
Flash memory | 128 MB |
Memory DRAM | 512 MB |
Max VLANs | 1023 |
VLAN IDs | 4000 |
Maximum transmission unit (MTU) | Maximum transmission unit (MTU) |
Jumbo frames | 9198 bytes |
Forwarding rate 64 Byte Packet | 17.9 mpps |
Dimensions (H x W x D) |
1.75 x 10.6 x 8.4 in (4.44 x 26.9 x 21.3cm) |
Weight | 5.0 lb (2.27 Kg) |
Operating* temperature up to 5000 ft (1524 m) | -5C to +45C (+23F to +113F) |
Operating* temperature up to 10,000 ft (3048 m) | -5C to +45C (+23F to +113F) |
Storage temperature up to 15,000 ft (4572 m) | -25C to +70C (-13F to +158F) |
Operating altitude | Up to 3048 m (Up to 10,000 ft) |
Storage altitude | Up to 4000 m (Up to 15,000 ft) |
Operating relative humidity | 5% to 95% noncondensing |
Storage relative humidity | 5% to 95% noncondensing |
MTBF | 569,530 |
Management | BRIDGE-MIB CISCO-CABLE-DIAG-MIB CISCO-CDP-MIB CISCO-CLUSTER-MIB CISCO-CONFIG-COPY-MIB CISCO-CONFIG-MAN-MIB CISCO-DHCP-SNOOPING-MIB CISCO-ENTITY-VENDORTYPE-OID-MIB CISCO-ENVMON-MIB CISCO-ERR-DISABLE-MIB CISCO-FLASH-MIB CISCO-FTP-CLIENT-MIB CISCO-IGMP-FILTER-MIB CISCO-IMAGE-MIB CISCO-IP-STAT-MIB CISCO-LAG-MIB CISCO-MAC-NOTIFICATION-MIB CISCO-MEMORY-POOL-MIB CISCO-PAGP-MIB CISCO-PING-MIB CISCO-POE-EXTENSIONS-MIB CISCO-PORT-QOS-MIB CISCO-PORT-SECURITY-MIB CISCO-PORT-STORM-CONTROL-MIB CISCO-PRODUCTS-MIB CISCO-PROCESS-MIB CISCO-RTTMON-MIB CISCO-SMI-MIB CISCO-STP-EXTENSIONS-MIB CISCO-SYSLOG-MIB CISCO-TC-MIB CISCO-TCP-MIB CISCO-UDLDP-MIB CISCO-VLAN-IFTABLE RELATIONSHIP-MIB CISCO-VLAN-MEMBERSHIP-MIB CISCO-VTP-MIB ENTITY-MIB ETHERLIKE-MIB IEEE8021-PAE-MIB IEEE8023-LAG-MIB IF-MIB INET-ADDRESS-MIB OLD-CISCO-CHASSIS-MIB OLD-CISCO-FLASH-MIB OLD-CISCO-INTERFACES-MIB OLD-CISCO-IP-MIB OLD-CISCO-SYS-MIB OLD-CISCO-TCP-MIB OLD-CISCO-TS-MIB RFC1213-MIB RMON-MIB RMON2-MIB SNMP-FRAMEWORK-MIB SNMP-MPD-MIB SNMP-NOTIFICATION-MIB SNMP-TARGET-MIB SNMPv2-MIB TCP-MIB UDP-MIB ePM MIB |
Standards | IEEE 802.1D Spanning Tree Protocol IEEE 802.1p CoS Prioritization IEEE 802.1Q VLAN IEEE 802.1s IEEE 802.1w IEEE 802.1x IEEE 802.1AB (LLDP) IEEE 802.3ad IEEE 802.3af IEEE 802.3ah (100BASE-X single/multimode fiber only) IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports IEEE 802.3 10BASE-T specification IEEE 802.3u 100BASE-TX specification IEEE 802.3ab 1000BASE-T specification IEEE 802.3z 1000BASE-X specification 100BASE-BX (SFP) 100BASE-FX (SFP) 100BASE-LX (SFP) 1000BASE-BX (SFP) 1000BASE-SX (SFP) 1000BASE-LX/LH (SFP) 1000BASE-ZX (SFP) 1000BASE-CWDM SFP 1470 nm 1000BASE-CWDM SFP 1490 nm 1000BASE-CWDM SFP 1510 nm 1000BASE-CWDM SFP 1530 nm 1000BASE-CWDM SFP 1550 nm 1000BASE-CWDM SFP 1570 nm 1000BASE-CWDM SFP 1590 nm 1000BASE-CWDM SFP 1610 nm RMON I and II standards SNMPv1, SNMPv2c, and SNMPv3 |
RFC compliance | RFC 768: UDP RFC 783: TFTP RFC 791: IP RFC 792: ICMP RFC 793: TCP RFC 826: ARP RFC 854: Telnet RFC 951: Bootstrap Protocol RFC 1542: BOOTP Extensions RFC 959: FTP RFC 1058: RIP Routing RFC 1112: IP Multicast and IGMP RFC 1157: SNMPv1 RFC 1166: IP Addresses RFC 1253: OSPF Routing RFC 1256: ICMP Router Discovery RFC 1305: NTP RFC 1492: TACACS+ RFC 1493: Bridge MIB RFC 1542: Bootstrap Protocol RFC 1583: OSPFv2 RFC 1643: Ethernet Interface MIB RFC 1723: RIPv2 Routing RFC 1757: RMON RFC 1812: IP Routing RFC 1901: SNMPv2C RFC 1902-1907: SNMPv2 RFC 1981: MTU Path Discovery IPv6 FRC 2068: HTTP RFC 2080: RIP for IPv6 RFC 2131: DHCP RFC 2138: RADIUS RFC 2233: IF MIB RFC 2236: IP Multicast RFC 2328: OSPFv2 RFC 2273-2275: SNMPv3 RFC 2373: IPv6 Aggregatable Addrs RFC 2453: RIPv2 Routing RFC 2460: IPv6 protocol RFC 2461: IPv6 Neighbor Discovery RFC 2462: IPv6 Autoconfiguration RFC 2463: ICMP IPv6 RFC 2474: DiffServ Precedence RFC 2597: Assured Forwarding RFC 2598: Expedited Forwarding RFC 2571: SNMP Management RFC 2740: OSPF for IPv6 RFC 3046: DHCP Relay Agent Information Option RFC 3101, 1587: NSSAs RFC 3376: IGMPv3 RFC 3580: 802.1x RADIUS |
Safety standards | UL 60950-1 CAN/CSA 22.2 No. 60950-1 EN 60950-1 IEC 60950-1 CE Marking GB 4943 IEC 60825 |
Electromagnetic emissions certifications | FCC Part 15, CFR 47, Class A, North America EN/IEC 61000-4-5 EN 55022 (CISPR22) and EN 55024 (CISPR24), CE marking, European Union AS/NZS, Class A, CISPR22:2004 or EN55022, Australia and New Zealand VCCI Class A, V-3/2007.04, Japan KCC (Formerly MIC, GB17625.1-1998) Class A, KN24/KN22, Korea ANATEL, Brazil CCC, China GOST, Russia |
Environmental | Reduction of Hazardous Substances (ROHS) 6 |
Telco | Common Language Equipment Identifier (CLEI) code |
Cisco WS-C3560CX-8PC-S Switch is a perfect choice for network deployment optimization. This switch is Gigabit Ethernet (GbE) managed switch and ideal for high-speed data connectivity, Wi-Fi backhaul, and Power over Ethernet (PoE) connectivity in places where space is at a premium. Use them in offices, classrooms, hotels, retail stores, and other enterprise and branch locations. These switches feature quiet, compact footprint and fan-less design.
Cisco WS-C3560CX-8PC-S Switch enables IP connectivity for devices such as IP phones, surveillance cameras, PCs, wireless access points, and video endpoints. These switches also offer flexible mounting options and open up a range of network design and connectivity options.
Feature Set | IP Base |
Uplink Interfaces | 2 Gigabit Ethernet RJ-45 uplinks, 2 SFP upliks |
Ports | 8 x Gigabit Ethernet ports |
Forwarding Bandwidth | 16 Gbps |
Switching Bandwidth (full-duplex capacity) | 32 Gbps |
Available POE Power | 240W |
RAM | 512 MB |
Flash Memory | 128 MB |
Dimensions | 4.44 x 26.9 x 23.8 cm |
Package Weight | 4.65 kg |
Powering Option | Internal power supply |
Available PoE Power (W) | 0W |
Can Switch Be Powered with Uplinks? | No |
Max VLANs | 1023 |
VLAN IDs | 4000 |
Maximum transmission unit (MTU) | Up to 9000 bytes |
Jumbo frames | 9198 bytes |
Forwarding rate 64 Byte Packet | 17.9 mpps |
Dimensions (H x W x D) |
1.75 x 10.6 x 8.4 in (4.44 x 26.9 x 21.3cm) |
Weight | 3.8 lb (1.72 Kg) |
Operating* temperature up to 5000 ft (1524 m) | -5C to +45C (+23F to +113F) |
Operating* temperature up to 10,000 ft (3048 m) | -5C to +45C (+23F to +113F) |
Storage temperature up to 15,000 ft (4572 m) | -25C to +70C (-13F to +158F) |
Operating altitude | Up to 3048 m (Up to 10,000 ft) |
Storage altitude | Up to 4000 m (Up to 15,000 ft) |
Operating relative humidity | 5% to 95% noncondensing |
Storage relative humidity | 5% to 95% noncondensing |
MTBF | 756,260 |
Management | BRIDGE-MIB CISCO-CABLE-DIAG-MIB CISCO-CDP-MIB CISCO-CLUSTER-MIB CISCO-CONFIG-COPY-MIB CISCO-CONFIG-MAN-MIB CISCO-DHCP-SNOOPING-MIB CISCO-ENTITY-VENDORTYPE-OID-MIB CISCO-ENVMON-MIB CISCO-ERR-DISABLE-MIB CISCO-FLASH-MIB CISCO-FTP-CLIENT-MIB CISCO-IGMP-FILTER-MIB CISCO-IMAGE-MIB CISCO-IP-STAT-MIB CISCO-LAG-MIB CISCO-MAC-NOTIFICATION-MIB CISCO-MEMORY-POOL-MIB CISCO-PAGP-MIB CISCO-PING-MIB CISCO-POE-EXTENSIONS-MIB CISCO-PORT-QOS-MIB CISCO-PORT-SECURITY-MIB CISCO-PORT-STORM-CONTROL-MIB CISCO-PRODUCTS-MIB CISCO-PROCESS-MIB CISCO-RTTMON-MIB CISCO-SMI-MIB CISCO-STP-EXTENSIONS-MIB CISCO-SYSLOG-MIB CISCO-TC-MIB CISCO-TCP-MIB CISCO-UDLDP-MIB CISCO-VLAN-IFTABLE RELATIONSHIP-MIB CISCO-VLAN-MEMBERSHIP-MIB CISCO-VTP-MIB ENTITY-MIB ETHERLIKE-MIB IEEE8021-PAE-MIB IEEE8023-LAG-MIB IF-MIB INET-ADDRESS-MIB OLD-CISCO-CHASSIS-MIB OLD-CISCO-FLASH-MIB OLD-CISCO-INTERFACES-MIB OLD-CISCO-IP-MIB OLD-CISCO-SYS-MIB OLD-CISCO-TCP-MIB OLD-CISCO-TS-MIB RFC1213-MIB RMON-MIB RMON2-MIB SNMP-FRAMEWORK-MIB SNMP-MPD-MIB SNMP-NOTIFICATION-MIB SNMP-TARGET-MIB SNMPv2-MIB TCP-MIB UDP-MIB ePM MIB |
Standards | IEEE 802.1D Spanning Tree Protocol IEEE 802.1p CoS Prioritization IEEE 802.1Q VLAN IEEE 802.1s IEEE 802.1w IEEE 802.1x IEEE 802.1AB (LLDP) IEEE 802.3ad IEEE 802.3af IEEE 802.3ah (100BASE-X single/multimode fiber only) IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports IEEE 802.3 10BASE-T specification IEEE 802.3u 100BASE-TX specification IEEE 802.3ab 1000BASE-T specification IEEE 802.3z 1000BASE-X specification 100BASE-BX (SFP) 100BASE-FX (SFP) 100BASE-LX (SFP) 1000BASE-BX (SFP) 1000BASE-SX (SFP) 1000BASE-LX/LH (SFP) 1000BASE-ZX (SFP) 1000BASE-CWDM SFP 1470 nm 1000BASE-CWDM SFP 1490 nm 1000BASE-CWDM SFP 1510 nm 1000BASE-CWDM SFP 1530 nm 1000BASE-CWDM SFP 1550 nm 1000BASE-CWDM SFP 1570 nm 1000BASE-CWDM SFP 1590 nm 1000BASE-CWDM SFP 1610 nm RMON I and II standards SNMPv1, SNMPv2c, and SNMPv3 |
RFC compliance | RFC 768: UDP RFC 783: TFTP RFC 791: IP RFC 792: ICMP RFC 793: TCP RFC 826: ARP RFC 854: Telnet RFC 951: Bootstrap Protocol RFC 1542: BOOTP Extensions RFC 959: FTP RFC 1058: RIP Routing RFC 1112: IP Multicast and IGMP RFC 1157: SNMPv1 RFC 1166: IP Addresses RFC 1253: OSPF Routing RFC 1256: ICMP Router Discovery RFC 1305: NTP RFC 1492: TACACS+ RFC 1493: Bridge MIB RFC 1542: Bootstrap Protocol RFC 1583: OSPFv2 RFC 1643: Ethernet Interface MIB RFC 1723: RIPv2 Routing RFC 1757: RMON RFC 1812: IP Routing RFC 1901: SNMPv2C RFC 1902-1907: SNMPv2 RFC 1981: MTU Path Discovery IPv6 FRC 2068: HTTP RFC 2080: RIP for IPv6 RFC 2131: DHCP RFC 2138: RADIUS RFC 2233: IF MIB RFC 2236: IP Multicast RFC 2328: OSPFv2 RFC 2273-2275: SNMPv3 RFC 2373: IPv6 Aggregatable Addrs RFC 2453: RIPv2 Routing RFC 2460: IPv6 protocol RFC 2461: IPv6 Neighbor Discovery RFC 2462: IPv6 Autoconfiguration RFC 2463: ICMP IPv6 RFC 2474: DiffServ Precedence RFC 2597: Assured Forwarding RFC 2598: Expedited Forwarding RFC 2571: SNMP Management RFC 2740: OSPF for IPv6 RFC 3046: DHCP Relay Agent Information Option RFC 3101, 1587: NSSAs RFC 3376: IGMPv3 RFC 3580: 802.1x RADIUS |
Safety standards | UL 60950-1 CAN/CSA 22.2 No. 60950-1 EN 60950-1 IEC 60950-1 CE Marking GB 4943 IEC 60825 |
Electromagnetic emissions certifications | FCC Part 15, CFR 47, Class A, North America EN/IEC 61000-4-5 EN 55022 (CISPR22) and EN 55024 (CISPR24), CE marking, European Union AS/NZS, Class A, CISPR22:2004 or EN55022, Australia and New Zealand VCCI Class A, V-3/2007.04, Japan KCC (Formerly MIC, GB17625.1-1998) Class A, KN24/KN22, Korea ANATEL, Brazil CCC, China GOST, Russia |
Environmental | Reduction of Hazardous Substances (ROHS) 6 |
Telco | Common Language Equipment Identifier (CLEI) code |
The Cisco Catalyst 3560-C series compact switch is a small form-factor Gigabit Ethernet and Fast Ethernet switch designed for deployments outside the wiring closet. Enterprise and commercial customers can deliver advanced security services, unified communications, wireless, IP video cameras, and other applications for the office workspace, branch office, classroom, cruise ship, and other wiring-constrained environments.
Feature Set | IP Base |
Uplink Interfaces | 2 x 1G copper plus 2 x 1G SFP |
Ports | 8 x 10/100/1000 Gigabit Ethernet |
Forwarding Bandwidth | 16 Gbps |
Switching Bandwidth (full-duplex capacity) | 32 Gbps |
RAM | 512 MB |
Flash Memory | 128 MB |
Dimensions | 4.44 x 26.9 x 21.3 cm |
Type | Virtual interfaces (VLANs) |
Value | 1023 |
Width | 10.6 in |
Depth | 7 in |
Height | 1.7 in |
Weight | 3.48 lbs |
Min Operating Temperature | 23 F |
Max Operating Temperature | 113 F |
Humidity Range Operating | 5 - 95% (non-condensing) |
Min Storage Temperature | -13 F |
Max Storage Temperature | 158 F |
Humidity Range Storage | 5 - 95% (non-condensing) |
Installed Size | 128 MB |
Compatibility | PC |
Manufacturer | Cisco Systems |
Packaged Quantity | 1 |
Product Line | Cisco Catalyst |
Model | 3560CX-8PT-S |
Brand | Cisco |
Qty | 8 |
Comments | PoE+ |
Type | USB |
Connector Type | Type A |
Rack Mounting Kit | Optional |
Compliant Standards | 80 PLUS Silver, ANATEL, AS/NZS CISPR22:2004 Class A, CAN/CSA C22.2 No. 60950-1, CCC, CISPR 22, CISPR 24, EN 60950-1, EN55022, EN55024, GB 4943, GOST, IEC 60825, IEC 60950-1, KCC Class A, KN22, KN24, RoHS, UL 60950-1, VCCI V-3/2007.04 Class A |
Authentication Method | Kerberos, RADIUS, Secure Shell (SSH), TACACS+ |
MTBF | 737,740 hours |
Height (Rack Units) | 1 |
Color Category | Gray |
Type | Forwarding performance (64-byte packet size) |
Value | 14.9 Mpps |
Qty | 10 |
Type | 10/100/1000 (PoE+) |
Power Consumption Operational | 24.3 Watt |
Installed Size | 512 MB |
Type | Cisco IOS IP Base |
Type | Switch |
Remote Management Protocol | CLI, HTTP, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP |
Compliant Standards | IEEE 802.1ab (LLDP), IEEE 802.1ae, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Status Indicators | Link/activity, PoE, Port transmission speed, Status, System |
Ports Qty | 8 |
Features | Access Control List (ACL) support, ARP support, Auto-negotiation, BOOTP support, Class of Service (CoS), DHCP snooping, DHCP support, DiffServ support, Dynamic ARP Inspection (DAI), Energy Efficient Ethernet, Fanless, Full duplex capability, IPv6 support, MAC Address Notification, Multicast VLAN Registration (MVR), Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Spanning Tree Protocol (STP) support, Syslog support, Trivial File Transfer Protocol (TFTP) support, VLAN support, Weighted Tail Drop (WTD) |
Routing Protocol | RIP-1, RIP-2, Static IP routing |
Subcategory | Network hubs and switches |
Power Over Ethernet (PoE) | PoE+ |
Manageable | Yes |
Form Factor | Desktop, DIN rail mountable, Rack-mountable, Wall-mountable |
Jumbo Frame Support | 9198 bytes |
Subtype | 10 Gigabit Ethernet |
PoE Budget | 146 W |
Cisco WS-C3560CX-8PT-S Switch helps optimize network deployments. These Gigabit Ethernet (GbE) managed switches are ideal for high-speed data connectivity, Wi-Fi backhaul, and Power over Ethernet (PoE) connectivity in places where space is at a premium.
Cisco WS-C3560CX-8PT-S Switch is designed to enable IP connectivity for devices such as IP phones, wireless access points, surveillance cameras, PCs, and video endpoints. It offers flexible mounting options and opens up a variety of network design and connectivity options with their quiet, fan-less design and compact footprint. Cisco WS-C3560CX-8PT-S Switch is built to use in offices, classrooms, hotels, retail stores, and other enterprise and branch locations.
