Dell Pro Dock WD25 Docking Station

Power and Connectivity Built for Modern IT Workspaces

The Dell Pro Dock WD25 is engineered to support today’s AI PC and multi-display environments with reliable power delivery, broad device compatibility, and centralized IT control. Designed for Dell and non-Dell systems, this USB-C docking station simplifies workspace connectivity while delivering enterprise-grade performance and manageability.

Key Benefits and Features

• High Power Delivery: Provides up to 100W of power to Dell commercial notebooks and up to 96W to non-Dell systems using a 130W AC adapter.
• Advanced Multi-Display Support: Supports up to four external displays with configurations reaching up to 6K resolution using Display Stream Compression.
• Enterprise-Grade Networking: Integrated 2.5 Gigabit Ethernet enables faster wired connectivity for data-intensive business environments.
• Centralized Dock Management: Enables firmware updates, port control, and inventory tracking through Dell Device Management Console.
• Thoughtful and Durable Design: Features a reinforced USB-C connector and an ambidextrous cable that routes left or right for clean desk setups.

Ideal Use Cases

• Enterprise office and corporate workstation deployments
• IT-managed laptop fleets with centralized dock control
• Multi-monitor productivity and engineering workstations
• Hybrid and hot-desk environments
• Organizations standardizing USB-C docking across brands

Technical Specifications

• Docking Interface: USB Type-C with DisplayPort Alt Mode
• Power Delivery: Up to 100W for Dell systems, up to 96W for non-Dell systems
• Video Outputs: 2x DisplayPort 1.4, 1x HDMI 2.1, 1x USB-C DisplayPort
• USB Ports: 4x USB-A 3.2 Gen 2 data, 1x USB-C 3.2 Gen 2 data
• Powered USB Ports: All ports deliver power with or without PC connection (up to 15W via USB-C)
• Networking: 2.5 Gigabit Ethernet RJ45
• Dimensions: 205 x 90 x 35.25 mm
• Weight: 550 g without power adapter
• Supported OS: Windows 10, Windows 11, Ubuntu 24.04, Red Hat Enterprise Linux 9.6+, ChromeOS 137

Upgrade Your Workspace with Confidence

Deploy a future-ready docking solution that delivers power, performance, and IT control at scale. Order today.

Model	Dell Pro Dock WD25
Product Type	Docking Station
Docking Interface	USB Type-C with DP Alt Mode Connector
Power Adapter	130 Watt AC
Power Delivery (Dell Notebooks)	Up to 100 Watt
Power Delivery (Non-Dell Systems)	Up to 96 Watts
Networking	2.5 Gigabit Ethernet (RJ45)
Video Outputs	2 x DisplayPort 1.4; 1 x HDMI 2.1; 1 x USB-C Multi-function DisplayPort 1.4
USB Ports (Data Only)	4 x USB-A 3.2 Gen 2 (10 Gbps); 1 x USB-C 3.2 Gen 2 (10 Gbps)
USB Ports (Power)	4 x USB-A 3.2 Gen 2 (4.5W each); 1 x USB-C 3.2 Gen 2 (15W); 1 x USB-C Multi-function DisplayPort (7.5W)
Security Slot Type	1 x Kensington lock slot; 1 x Wedge-shaped lock slot
LED Indicators	Power Button LED; RJ45 LEDs
Dimensions	205mm x 90mm x 35.25mm (8.07in x 3.54in x 1.39in)
Dock Weight (Without Power Adapter)	550 g (1.21 lb)
Cable Length	0.9 m
Supported Operating Systems	Windows 10; Windows 11; Ubuntu 24.04; Red Hat Enterprise Linux 9.6+; ChromeOS 137

Display Support (DP1.4 without DSC)	Up to: 4 x SXGA(1280x1024)@60Hz; 3 x FHD(1920x1080)@60Hz; 2 x QHD(2560x1440)@60Hz; 1 x 4K(3840 x 2160)@60Hz
Display Support (DP1.4 / DP2.1 with DSC)	Up to: 4 x WQHD(3440 x 1440)@60Hz; 3 x WQHD(3440 x 1440)@60Hz; 2 x 5K(5120 x 2160)@60Hz; 1 x 6K(6144 x 3456)@60Hz
USB-A Ports (Data)	4 x USB-A 3.2 Gen 2 (10 Gbps)
USB-C Ports (Data)	1 x USB-C 3.2 Gen 2 (10 Gbps)
USB Power Delivery (Ports)	All deliver power with or without PC
Host PC Management	MAC address pass-through; PXE Boot; Dock Power Button Sync; Wake-On-LAN; WLAN to LAN switch; Kernel Direct Memory Access (DMA) protection
Host Software (Windows)	Dell Firmware Utility; Dell Display and Peripheral Manager; Dell Command Update
Dock Management Features	Host PC based firmware update; Firmware update on disconnect; Port disablement
Cloud Management (via Host PC Software)	Dell Device Management Console enables: Automatic or scheduled firmware updates; Maintain specific firmware version or downgrade; Peripheral inventory and status
Cloud Management Enrollment	Dell Display and Peripheral Manager; Dell Management Agent

Included	Docking station; Power adapter and power cord; Documentation (Quick Start Guide, Safety, Environmental, and Regulatory Information)
Cable Lock	Sold separately
