Ubiquiti UniFi USW-PRO-MAX-16-POE Switch

High-Performance Multi-Gig Switching with Advanced PoE Power

The Ubiquiti UniFi Switch Pro Max 16 PoE (USW-PRO-MAX-16-POE) is a Layer 3 multi-gigabit switch engineered for high-density business networks. With 2.5GbE access ports, 10G SFP+ uplinks, and a 180W PoE budget, it delivers high-speed connectivity and flexible power for access points, cameras, VoIP phones, and Pro AV deployments.

Designed for rack, desktop, or wall installation, this Etherlighting enabled switch combines enterprise routing features with powerful PoE++ output in a compact 1U form factor.

Key Benefits & Features

• Multi-Gig Access with PoE++: 12x 1GbE PoE+ ports and 4x 2.5GbE PoE++ ports support high-performance WiFi 6/7 APs, IP cameras, and high-power edge devices.
• 10G SFP+ Uplinks: Dual 10G SFP+ interfaces provide high-speed aggregation or core uplink connectivity for bandwidth-intensive environments.
• Layer 3 Routing Capability: Supports inter-VLAN routing, static routing, DHCP server and relay for advanced segmentation and traffic control.
• Enterprise-Grade Switching Performance: 84 Gbps switching capacity and 42 Gbps non-blocking throughput ensure wire-speed data handling.
• Advanced Security & Control: 802.1X authentication, ACLs, DHCP snooping, port isolation, IGMP snooping, and Storm Control enhance network protection.

Ideal Use Cases

• SMB and enterprise branch network deployments
• High-density WiFi access layer with multi-gig APs
• IP surveillance systems requiring PoE++ power
• Pro AV and VoIP network environments
• UniFi-managed campus edge switching

Technical Specifications

• Total Ports: 16 RJ45 + 2 SFP+
• 1GbE Ports: 12x 10/100/1000 RJ45 (PoE+)
• 2.5GbE Ports: 4x 2.5G RJ45 (PoE++)
• 10G Uplinks: 2x 10G SFP+
• Total PoE Budget: 180W
• Switching Capacity: 84 Gbps
• Non-Blocking Throughput: 42 Gbps
• Forwarding Rate: 62.496 Mpps
• MAC Address Table: 16,000 entries
• Form Factor: 1U rackmount, desktop, wall-mount
• Dimensions: 325.1 x 160 x 43.7 mm
• Management: UniFi Network (v8.1.127 or later)

Upgrade Your Network Core with Multi-Gig Power

Deploy scalable Layer 3 switching with high-density PoE and 10G uplinks. Order today.

Model	Ubiquiti UniFi USW-PRO-MAX-16-POE
Product Type	Layer 3 Managed Ethernet Switch
Port Configuration	12 x 1 GbE RJ45 (PoE+), 4 x 2.5 GbE RJ45 (PoE++), 2 x 10G SFP+
Total Port Count	16 RJ45 + 2 SFP+
PoE Support	PoE+, PoE++
PoE Ports	12 x PoE+; 4 x PoE++
Total PoE Budget	180 W
Max PoE per Port	PoE: 15.4 W; PoE+: 32 W; PoE++: 64 W
Switching Capacity	84 Gbps
Non-Blocking Throughput	42 Gbps
Forwarding Rate	62.496 Mpps
Supported VLANs	1,000
MAC Address Table	16,000 entries
Layer	Layer 3
Form Factor	Rack mount (1U), desktop, wall
Display	1.3 inch touchscreen
Dimensions (W x D x H)	325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7 in)
Weight	2.1 kg (4.6 lb)
Enclosure Material	SGCC steel
Power Supply	AC/DC external adapter, 210 W
Supported Voltage Range	50 to 54 V DC
Max Power Consumption	25 W (excluding PoE); 210 W (including PoE)
Operating Temperature	-5 to 40 C (23 to 104 F)
Operating Humidity	10 to 90 percent noncondensing
Certifications	CE, FCC, IC, Anatel
NDAA Compliant	Yes

Layer 3 Routing Capacity	ARP entries: 6,000; IPv4 routes: 512; IPv4 static routes: 256
Access Control Lists	IPv4 ACLs: 128; MAC ACLs: 128
Packet Buffer	1.5 MB
Layer 3 Features	DHCP Server; DHCP Relay; Inter-VLAN Routing; Static Routing
Layer 2 Features	LACP; STP; RSTP; QoS (DSCP); IGMP Snooping; Jumbo Frames; LLDP-MED; Voice VLAN; Loop Protection
Security Features	802.1X Control; MAC-Based ACLs; IP-Based ACLs; DHCP Snooping & Guarding; Port Isolation; Port Mirroring; MAC Address Blocking
Traffic Management	Egress Rate Limit; Flow Control; Storm Control; Multicast & Broadcast Rate Limiting
Advanced IGMP	Querier; Fast Leave; Router Port
Pro AV Profiles	Play; Dante; Q-SYS; NDI; SDVoE; Shure; AES67; Crestron
Supported Rack Depth	400 to 1200 mm (15.7 to 47.2 in)
Management Software	UniFi Network Version 8.1.127 and later

Included

Power adapter (210 W); Power cord; Rack mount kit
