Ubiquiti UniFi Switch Lite 16 PoE (USW-LITE-16-POE)
- 16-Port Managed Network Switch with Power over Ethernet Capabilities.
$210.00
Ubiquiti UniFi Switch Lite 16 PoE (USW-LITE-16-POE)
The UniFi Switch Lite 16 PoE is a small-scale switch ideal for use in small local area networks. This model is equipped with PoE power delivery capabilities and is designed to be conveniently placed on a desktop or wall. It has 16x GbE RJ45 ports (8x PoE ports.) The UniFi Switch Lite 16 PoE is administered and set up through the UniFi Network Controller, with additional support provided by the UniFi mobile app. This switch provides Layer 2 switching protocols and features.
Quick Specs:
- 16x 10/100/1000 MbE RJ45 ports
- 8x PoE/PoE+ Ports
- Total non-blocking line rate: 16 Gbps
- PoE budget: 45W
Please see the related tabs for the USW-LITE-16-POE datasheet and compatible accessories.
| Properties | USW-LITE-16-POE Ubiquiti UniFi Switch Lite 16 PoE |
| Description | The Ubiquiti UniFi USW-Lite-16-PoE is a high-speed switch that can connect up to 16 Ethernet devices. It offers basic Layer 2 protocols and features, 8 ports with 802.3at PoE+ support of up to 45W power for PoE devices. |
| Product Family | Ubiquiti UniFi Switch |
| Networking Interfaces | 16 x 10/100/1000 MbE RJ45 Ports |
| Management Interfaces | Ethernet In-Band |
| Number of PoE Ports | 8 |
| PoE Interfaces | 8 PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Total Available PoE | 45W |
| Max. PoE Wattage per Port by PSE | 30W |
| Power Method | 100-240VAC, Universal Input |
| Power Supply | AC/DC, Internal, 60W |
| Max Power Consumption (Excluding PoE Output) | 15W |
| Dimensions | 191.7 x 185 x 43.7 mm (7.55 x 7.28 x 1.72") |
| Weight | 1.2 kg (2.65 lb) |
| Fan | Fanless |
| Mounting | 1U Wallmountable (hardware included) |
| Specifications | USW-LITE-16-POE |
| Total Non-Blocking Throughput | 16 Gbps |
| Switching Capacity | 32 Gbps |
| Modes | SMB layer 2 PoE GbE switch |
| Application Requirements | UniFi Network version 7.2.94 and later |
| Operating Temperature | -15 to 40° C (5 to 104° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
