APC SMTL750RM2UC - Smart-UPS 750VA Lithium-Ion Rackmount 2U

Overview

The APC Smart-UPS SMTL750RM2UC delivers 750VA / 600W of dependable power protection in a compact 2U rackmount form factor. Designed with lithium-ion battery technology, it ensures longer lifecycle performance, faster recharge times, and reduced maintenance compared to traditional UPS solutions. Featuring Automatic Voltage Regulation (AVR), pure sine wave output, and an intuitive LCD display, it safeguards mission-critical IT and network devices. Integrated SmartConnect Ethernet allows for secure, cloud-enabled monitoring, making it an ideal choice for modern distributed IT environments.

Key Features & Benefits

• Lithium-Ion Battery: Extended 8–10 year design life reduces replacement frequency and lowers total cost of ownership.
• Automatic Voltage Regulation (AVR): Corrects voltage fluctuations without switching to battery, preserving runtime capacity.
• Pure Sine Wave Output: Delivers clean, stable power for sensitive servers and network hardware.
• SmartConnect Port: Enables remote, cloud-based power monitoring for proactive management.
• 2U Rackmount Design: Space-efficient form factor suitable for network racks and data centers.
• Multi-Function LCD: Provides at-a-glance status updates and local UPS management.

Technical Deep Dive

The SMTL750RM2UC uses a line-interactive topology combined with AVR to stabilize input voltages between 75–154V without engaging the battery. This ensures consistent uptime, reducing strain on the lithium-ion cells and extending operational lifespan.

Unlike traditional VRLA-based UPS systems, its lithium-ion battery offers a design life of 8–10 years, faster 3-hour recharge time, and superior energy efficiency. This minimizes maintenance cycles and maximizes availability, which is critical for always-on IT environments.

With SmartConnect Ethernet integration, users gain direct access to APC’s cloud-based remote monitoring platform. This simplifies deployment and management, providing actionable insights into UPS status, runtime data, and energy efficiency trends. Additionally, the multi-function LCD interface allows for granular, on-site control and diagnostics.

Ideal Applications

• Rack-mounted servers and storage arrays
• Network closets and branch office equipment
• Edge computing and IoT deployments
• Retail, healthcare, and finance IT infrastructure

Frequently Asked Questions (FAQs)

Q1: How is the SMTL750RM2UC installed?
A: It is a 2U rackmount UPS and comes with mounting brackets, support rails, screws, and necessary cables for straightforward integration.

Q2: What performance can I expect?
A: The UPS delivers 750VA / 600W of power with pure sine wave output. Runtime depends on the load, environment, and battery age; refer to APC’s runtime chart for detailed values. Actual runtimes may vary.

Q3: How can the UPS be managed?
A: Management is available via the front-panel LCD console and the SmartConnect Ethernet port for cloud-enabled remote monitoring.

Brand	APC
Model	SMTL750RM2UC
Product Type	Smart-UPS Rackmount
Form Factor	Rackmount 2U
Color	Black with silver front bezel
Dimensions (H x W x D)	3.39 x 17.24 x 12.52 in (8.6 x 43.8 x 31.8 cm)
Weight	34.00 lb (15.42 kg)
Mounting Type	Rack-mounted

Input Voltage	120 V
Input Frequency	50/60 Hz ±3 Hz auto-sensing
Plug Type	NEMA 5-15P
Output Voltage	120 V
Power Capacity	750 VA / 600 W
Output Connections	6 x NEMA 5-15R
Topology	Line Interactive
Waveform	Sine wave
Transfer Time	6 ms typical, 10 ms maximum
Battery Type	Lithium-Ion
Recharge Time	3 hours typical
Battery Design Life	8–10 years
Surge Protection	680 J
Operating Temperature	0…40°C
Operating Humidity	0…95% non-condensing
Warranty	5 year repair or replace

Rack Mounting Brackets	Included in the box
Rack Mounting Support Rails	Included in the box
Screws and Washers	Included in the box
USB Cable	Included in the box
Ethernet Patch Cable	Included in the box
