MikroTik RouterBoard 960PGS(RB960PGS)

Name: MikroTik RouterBoard 960PGS(RB960PGS)
Brand: Mikrotik
Price: 80.00 USD
Availability: OutOfStock

Part Number: RB960PGS

Technical Details

A high performance multi-port network router featuring Power over Ethernet (PoE) support.

$80.00

Ask an Expert

sales@networkdevicesinc.com

1-201-559-1474

Availability: Request ETA

Condition: Brand New Sealed

Free Shipping on Orders $100+Arrives in 1-6 business days within the U.S.

International DeliveryWorldwide shipping in 7–15 business days

30 Days Return

12 Months Warranty Support

sales@networkdevicesinc.com

1-201-559-1474

MikroTik RB960PGS Routerboard

The MikroTik RB960PGS is a sophisticated networking device designed for residential and small office environments. It is specifically engineered for users who prioritize wired connections and do not necessitate wireless connectivity. Equipped with PoE ports, it enables the powering of devices such as access points and cameras through Ethernet. Additionally, it includes an SFP port to facilitate high-speed internet connections using optical cables. The device is powered by an 800MHz CPU and 128MB of RAM, providing robust performance capabilities.

Quick Specs:

5x 10/100/1000 Ethernet Ports
1x SFP uplink port
QCA9557, 1 core, 800 MHz CPU
128MB RAM

Please see the related tabs for the RB960PGS datasheet and compatible accessories.

Properties

Properties	MikroTik hEX PoE - RouterBoard 960PGS
Description	The hEX PoE is a compact and cost-effective router with five Gigabit Ethernet ports, a USB 2.0 port, and an SFP port for optical fiber connectivity. It has an 800MHz CPU, advanced configuration capabilities, and supports passive and 802.3af/at PoE output.
Product Family	hEX Series
Product Type	Ethernet Router
10/100/1000 Ethernet ports	5
SFP ports	1
USB slot	1 x USB 2.0 type A
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	12-57 V
Max power consumption	54 W
Max power consumption without attachments	6 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	12-57 V
PoE-out ports	Ether2-Ether5
PoE out	802.3af/at
Max out per port output (input 18-30 V)	1A
Max out per port output (input 30-57 V)	450 mA
Max total out (A)	2A

Specifications

Specifications	RB960PGS
Architecture	MIPSBE
Memory	128 MB RAM
Flash Storage size	16 MB
CPU	QCA9557 880 MHz
CPU core count	1
Switch chip model	QCA8337
OS	RouterOS level 4 license
MTBF	Approximately 100.000 hours at 25C
Temperature	-40°C to 60°C tested
IPsec hardware acceleration	Yes
Certification	CE, EAC, ROHS
IP	IP20
Bridging	64 byte: 523 Mbps 1518 byte: 1972 Mbps 1400 byte: 1972 Mbps
Routing	64 byte: 530 Mbps 1518 byte: 1972 Mbps 1400 byte: 1972 Mbps
AES-128	64 byte: 21 Mbps 1518 byte: 472 Mbps 1400 byte: 450 Mbps

Accessories

Included Accessories	24V 2.5A power adapter IEC Cord
XS+DA0001	Direct attach cable that supports SFP 1G, SFP+ 10G, and 25G SFP28 standard.
XS+2733LC15D	A kit of two combined 1.25G SFP, 10G SFP+ and 25G SFP28 modules. 15 km, 1270nm + 1330nm.
S+AO0005	SFP+ Active Optics direct attach cable, 5m
S-31DLC20D	SFP (1.25G) module, 20KM, Single Mode
S-55DLC80D	SFP 1.25G module for 80km links with Dual LC-connector
S-RJ01	RJ45 SFP 10/100/1000M copper module
S+85DLC03D	SFP+ (10Gbit), 300m, Multi Mode
48V2A96W	48 V 2 A 96 W power supply with plug
XS+DA0003	Direct attach cable that supports SFP 1G, SFP+ 10G, and 25G SFP28 standard.
S-85DLC05D	SFP (1.25G) module, 550m, Multi Mode
S-3553LC20D	Two SFP (1.25G) module kit, 20Km, single mode
S-4554LC80D	Pair of SFP 1.25G module for 80km links with Single LC-connectors
