Cisco PWR-RGD-AC-DC-H Power Supply
- 150W hot-plug power supply module (plug-in module)
- Dual input: nominal AC 100-240V / DC 100-250V
- Hazloc certified for Cisco Industrial Ethernet 4010, 5000, and Catalyst 9300 Series switches
Cisco PWR-RGD-AC-DC-H Rugged Power Supply
The Cisco PWR-RGD-AC-DC-H is a high-reliability, 150W hot-plug power supply module engineered for demanding B2B industrial environments. Designed with a dual-input architecture, it supports nominal ranges of 100-240VAC and 100-250VDC to keep critical infrastructure running continuously. This modular power supply is certified for Hazardous Locations (Hazloc), ensuring safe, robust performance in volatile conditions when deployed in Cisco Industrial Ethernet 4010, 5000, and Catalyst IE 9300 Series switches.
Equipped with an robust hot-swappable design, the PWR-RGD-AC-DC-H enables quick field replacements without requiring network shutdown. This ensures minimal downtime and supports resilient, redundant power designs across your manufacturing facility, control room, or outdoor industrial network deployment.
| Brand | Cisco |
| Model | PWR-RGD-AC-DC-H |
| SKU | PWR-RGD-AC-DC-H |
| Product Type | Power-supply module |
| Weight | 2.55 lb (1.15 kg) |
| Dimensions | 1.58 x 7 x 5 in. (4 x 17.8 x 12.7 cm) without mounting flanges |
| Power Capacity | 150 Watts |
| Nominal Input Voltage | 100 to 240 VAC, 50 to 60 Hz; 100 to 250 VDC |
| Absolute Maximum Input Voltage | 85 to 264 VAC, 47 to 63 Hz; 88 to 300 VDC |
| Dimensions with Mounting Flanges | 1.58 x 8.15 x 5 in. (4 x 20.7 x 12.7 cm) |
| Supported Switch Series | Cisco Industrial Ethernet 4010, 5000, and Catalyst IE 9300 Series |
| Environment Certification | Hazardous Locations (Hazloc Class 1, Div 2) |
