Juniper MIC-MRATE Line Card

Modular Port Concentrators (MPCs) with Modular Interface Cards (MICs) provide packet forwarding services and physical interfaces for MX routers. MICs install into MPCs and function similarly to PICs and FPCs. MPCs install vertically in the MX2020, MX2010, MX2008, and MX960 router chassis, and horizontally in the MX480 and MX240 router chassis. On MX5, MX10, MX40, MX80, and MX104 routers, MICs install directly into the router chassis. There are also fixed-configuration MPCs, with built-in network ports and services functionality



Product Name	Juniper MIC-MRATE Line Card (SKU: MIC-MRATE)
Description	The MIC-MRATE is a Modular Interface Card (MIC) designed for high-performance routing in MX Series routers. It features 12 QSFP+ ports, with 8 of them supporting QSFP28 (10/40/100GbE) for flexible and scalable networking. Optics are sold separately.
Brand	Juniper Networks
Type	Interface Card
Product Category	Networking
Form Factor	Plug-in card for Modular Port Concentrator (MPC)
Compatibility	MX Series routers (MX2020, MX2010, MX2008, MX960, MX480, MX240)
Software Support	Junos OS compatibility
Forwarding Capacity	Supports up to 1.0 Tbps in some configurations
Line-Rate Throughput	Up to 100 Gbps per port
Supported Protocols	IPv4, IPv6, MPLS, QoS, Layer 2 and Layer 3 VPNs, NAT
Form Factor	Plug-in for Modular Port Concentrator (MPC)

Port Configuration	12 QSFP+ ports, 8 ports support QSFP28 (10/40/100GbE)
Power Consumption	60 Watts when installed in MPC8E, 85 Watts when installed in MPC9E
Power Supply	Requires external power supply, separate optics are required (sold separately)
Weight	3.9 lb (1.77 kg)
Dimensions	19 x 1.73 x 22 inches
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	5% to 90% non-condensing
Compliance	CE, FCC, RoHS
Cooling	Front-to-back airflow
