Mellanox MCX556A-ECAT Network Adapter





Mellanox MCX556A-ECAT Network Adapter

The Mellanox MC556-A-ECAT is a member of the ConnectX-5 Ethernet Adapter Cards family. This network interface card is a high-performance device designed for Ethernet and InfiniBand networks. It has a single QSFP28 port that supports both copper and optical connections. The Mellanox MC556A-ECAT provides support for a wide range of protocols and data rates, and it is compatible with PCIe Gen3 with 16 lanes. The device has a maximum power consumption of 25W and supports InfiniBand speeds of up to 200 Gb/s.

Quick Specs:

• 2x QSFP28
• 1/10/25/40/50/100 Gb/s data rate
• 16x PCIe Gen 3.0
• Max Speed: EDR and 100GbE

Please see the related tabs for the MCX556A-ECAT datasheet and compatible accessories.

Product Name	Mellanox MCX556A-ECAT Network Adapter
Product Description	The Mellanox MCX556A-ECAT is a high-performance network adapter designed for both Ethernet and InfiniBand networks. It features dual QSFP28 ports supporting data rates up to 100 Gb/s and is compatible with PCIe Gen3 x16 interfaces.
Product Family	Mellanox ConnectX-5 Series
Product Type	Network Adapter Card
Connector	Dual QSFP28 InfiniBand and Ethernet (copper and optical)
Data Rate	Ethernet: 1/10/25/40/50/100 Gb/s, InfiniBand: SDR/DDR/QDR/FDR/EDR
PCI Express Gen 3.0	SERDES @ 8.0 GT/s, 16 lanes (2.0 and 1.1 compatible)
Voltage	12V
Maximum Current	100 mA
Typical Power (Passive Cable)	16.2 W
Maximum Power (Passive Cable)	19.0 W
Maximum Power (Active 1.5W Cable)	22.3 W
Maximum Power (Active 2.5W Cable)	24.6 W

Operating Temperature	Operational: 0°C to 55°C, Non-operational: -40°C to 70°C
Humidity	Operational: 10% to 85% relative humidity, Non-operational: 10% to 90% relative humidity
Altitude (Operational)	3050 m
Regulatory Compliance	Safety: CB / cTUVus / CE, EMC: CE / FCC / VCCI / ICES / RCM, RoHS: RoHS compliant
Size	2.71 in x 5.6 in (68.90 mm x 142.24 mm)
Message Rate	215 Mpps
Sub 0.8 µs Latency	Yes
Supported Architectures	x86, Power, Arm
Airflow (Passive Cable)	350 LFM
Airflow (Active 1.5W Cable)	500 LFM
Airflow (Active 2.5W Cable)	600 LFM
Airflow (Active 3.5W Cable)	650 LFM
Airflow (Active 5W Cable)	1300 LFM
