NetBox 5 ax L11UG-5HaxD-NB-US

The NetBox 5 ax is a powerful dual-chain outdoor device designed to fill multiple roles in your network setups, including AP, CPE, and point-to-point connections. It features a strong 5 GHz Wi-Fi 6 radio with SMA connectors for versatile omnidirectional access points or long-range point-to-point links. The durable outdoor enclosure, modern Qualcomm Maple ARM CPU, and Gigabit Ethernet with PoE-in make it a reliable and flexible solution for various networking needs.

Product Highlights

• 5 GHz Wi-Fi 6 dual-chain radio
• ARM-based Qualcomm Maple CPU
• 256 MB RAM, 128 MB NAND storage
• Gigabit Ethernet with PoE-in
• Durable weatherproof outdoor enclosure
• SMA connectors for versatile antenna options
• Operating temperature: -40°C to +70°C

Specifications

Category	Specifications
Product Code	L11UG-5HaxD-NB-US
CPU	Dual-Core IPQ-5010 800 MHz, ARM architecture
RAM	256 MB
Storage	128 MB NAND
Ethernet Ports	1 x 1G Ethernet port
USB Port	1 x USB 2.0 Type A
Wireless Band	5 GHz, 802.11a/n/ac/ax dual chain
Connector Type	RP-SMA female (outside thread)
Extras	Beeper, signal and status LEDs, voltage and temperature sensors
Dimensions	245 x 121 x 50 mm
Operating System	RouterOS v7, License level 4
Operating Temperature	-40°C to +70°C

Powering

• PoE-In: Passive PoE, 18-28 V input voltage
• Max Power Consumption: 15 W
• Included Parts: 24V 1.2A power adapter, Gigabit PoE injector, hose clamp, DIN rail mount kit

Product code	L11UG-5HaxD
Architecture	ARM
CPU	IPQ-5010
CPU core count	2
CPU nominal frequency	800 MHz
RouterOS license	4
Operating System	RouterOS v7
Size of RAM	256 MB
Storage size	128 MB
Storage type	NAND
MTBF	Approximately 100'000 hours at 25C
Tested ambient temperature	-40°C to 70°C

Details
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	12-28 V
Max power consumption	15 W
Max power consumption without attachments	6 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	18-28 V
Wireless specifications
Wireless 5 GHz Max data rate	2400 Mbit/s
Wireless 5 GHz number of chains	2
Wireless 5 GHz standards	802.11a/n/ac/ax
Wireless 5 GHz chip model	QCN-6102
Wireless 5 GHz generation	Wi-Fi 6
10/100/1000 Ethernet ports	1
Number of USB ports	1
USB Power Reset	Yes
USB slot type	USB type A
Max USB current (A)	1.5
PCB temperature monitor	Yes
Voltage Monitor	Yes
Beeper	Yes
