MIKROTIK L009UIGS-2HAXD-IN WIRELESS ROUTER
| Model: | L009UIGS-2HAXD-IN |
| Detail: | |
| Price: | $125.00 |
| Condition: | Brand New Sealed |
| Availability: | Out of Stock |
| Shipping: | FREE SHIPPING for all U.S orders over $100. Please call us at 201-559-1474, fill out the contact form, or chat with a live agent for other shipping methods. |
| Tax: | $0.00 Tax Outside NJ and TX |
| Quantity: |
Description
The MikroTik L009UiGS-2HaxD-IN represents a notable progression in Wi-Fi technology, featuring a robust processor and compatibility with Wi-Fi 6. The router's chassis functions as a substantial heat sink, aiding in maintaining optimal device temperature and mitigating the likelihood of overheating. Efficient heat dispersion is crucial for ensuring sustained reliability and operational efficiency. Additionally, the router's high-capacity CPU provides IPsec hardware encryption, a critical feature for contemporary enterprises dependent on VPNs for secure remote data connectivity.
Quick Specs:
- 8x 10/100/1000 Ethernet Ports
- 1x SFP ports (2.5G supported)
- PoE out: Passive PoE
- 512MB RAM
Please see the related tabs for the L009UiGS-2HaxD-IN datasheet and compatible accessories.
Accessories
Specifications
| Specifications | MikroTik L009UiGS-2HaxD-IN Wireless Router |
| Product code | L009UiGS-2HaxD-IN |
| Architecture | ARM |
| CPU | IPQ-5018 |
| CPU core count | 2 |
| CPU nominal frequency | 800 MHz |
| Switch chip model | 88E6190 |
| RouterOS license | 5 |
| Operating System | RouterOS v7 |
| Size of RAM | 512 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| Wireless capabilities | |
| Wireless 2.4 GHz Max data rate | 574 Mbit/s |
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n/ax |
| Antenna gain dBi for 2.4 GHz | 4 |
| Wireless 2.4 GHz chip model | IPQ-5018 |
| Wireless 2.4 GHz generation | Wi-Fi 6 |
| WiFi speed | AX600 |
| Ethernet | |
| 10/100/1000 Ethernet ports | 8 |
| Number of 1G Ethernet ports with PoE-out | 1 |
| Fiber | |
| SFP ports | 1 (2.5G supported) |
| Peripherals | |
| Serial console port | RJ45 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB 3.0 type A |
| Max USB current (A) | (1.5) |
| Powering | |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 24-56 V |
| Max power consumption | 47 W |
| Max power consumption without attachments | 14 W |
| Cooling type | Passive |
| PoE in | 802.3af/at |
| PoE in input Voltage | 24-56 V |
| PoE-out | |
| PoE-out ports | Ether8 |
| PoE out | Passive PoE |
| Max out per port output (input 18-30 V) | 1:00 AM |
| Max out per port output (input 30-57 V) | 450 mA |
| Max total out (A) | 1.0 A |
| Certification & Approvals | |
| Certification | CE, FCC, IC, EAC, ROHS |
| IP | 20 |
| Other | |
| Mode button | Yes |
| Wireless specifications (2.4 GHz) | |
| 1MBit/s | Transmit (dBm): 27 Receive Sensitivity: -100 |
| 11MBit/s | Transmit (dBm): 27 Receive Sensitivity: -94 |
| 6MBit/s | Transmit (dBm): 30 Receive Sensitivity: -96 |
| 54MBit/s | Transmit (dBm): 28 Receive Sensitivity: -80 |
| MCS0 | Transmit (dBm): 30 Receive Sensitivity: -96 |
| MCS7 | Transmit (dBm): 27 Receive Sensitivity: -75 |
| MCS9 | Transmit (dBm): 25 Receive Sensitivity: -70 |
| MCS11 | Transmit (dBm): 23 Receive Sensitivity: -67 |
Properties
| Properties | MikroTik L009UiGS-2HaxD-IN Wireless Router |
| Description | The MikroTik L009UiGS-2HaxD-IN is a dual-band wireless router with Gigabit Ethernet ports and USB connectivity. Ideal for home and small office use, it offers fast internet speeds, advanced security features, and customizable configuration options through RouterOS software. |
| Product Family | MikroTik Wireless Router |
| Product Type | Wireless Router |
| Key Features | • Dual-band wireless (2.4 GHz and 5 GHz) • Multiple Gigabit Ethernet ports • USB port for additional connectivity • Ideal for home and small office use • Advanced security features • Customizable configuration with RouterOS software |
