The FortiGate 70G-POE series simplifies SD-Branch architecture by integrating advanced security, SD-WAN, and power delivery into a single compact appliance. Built on the Fortinet SP5 ASIC, it delivers high-speed inspection with 10 / 10 / 10 Gbps firewall throughput while providing 60W of total PoE power budget to drive essential devices such as wireless access points and IP phones directly from the firewall.
Designed for flexibility and reduced hardware footprint, the FG-70G-POE features a desktop form factor ideal for space-constrained environments. It includes 4 dedicated PoE+ ports alongside GE RJ45 WAN ports and FortiLink ports, allowing for diverse connectivity options and seamless deployment in retail stores, small offices, and distributed enterprise sites.
Converged Security with Integrated PoE+ Power
Key Benefits
- Integrated Power over Ethernet: Provides 60W total PoE budget across 4 ports to power access points and IP phones, eliminating the need for extra injectors.
- SP5 ASIC Acceleration: Delivers 10 / 10 / 10 Gbps firewall throughput and 2.5 Gbps IPS inspection.
- Enterprise-Grade Protection: Includes FortiCare Premium and FortiGuard Enterprise Protection (1 Year) for enhanced security coverage alongside FortiGuard AI-Powered Security Services.
- Simplified Operations: Centralized management for networking and security with automated workflows and deep analytics.
- Integrated SD-WAN: Delivers faster application identification to avoid delays in accessing applications and accelerates overlay performance regardless of location.
- Silent Operation: Fanless design ensures quiet performance, ideal for desktop deployments.
Ideal Use Cases
- SD-Branch Deployment: Powers and secures branch infrastructure like Wi-Fi access points and VoIP phones with a single consolidated device.
- Retail Point of Sale: Secures transaction and business traffic while simplifying branch connectivity and power delivery.
- Secure Branch: Extends security to WAN, LAN, and WLAN at branch offices for unified protection and reliable connectivity.
- Remote Work: Delivers secure, high-performance VPN access for remote employees.
Technical Specifications Summary
- Firewall Throughput: 10 / 10 / 10 Gbps (1518 / 512 / 64 byte UDP packets)
- Firewall Throughput (Packets Per Second): 15 Mpps
- IPS Throughput: 2.5 Gbps
- NGFW Throughput: 1.5 Gbps
- Threat Protection Throughput: 1.3 Gbps
- IPsec VPN Throughput: 7.1 Gbps (512 byte)
- SSL Inspection Throughput: 1.4 Gbps
- Concurrent Sessions (TCP): 1.4 Million
- New Sessions/Second (TCP): 100,000
- Firewall Latency: 2.46 μs (64 byte UDP packets)
- PoE Power Budget: 60 W total (max 30 W per PoE/+ port, 802.3at)
- Power Consumption: 70.3 W / 72.5 W (Average / Maximum)
Upgrade Your Network Security
Deploy the FortiGate 70G-POE-BDL-809-12 bundle today for a streamlined, powerful, and power-capable security solution backed by FortiCare Premium and FortiGuard Enterprise Protection.
