32 x 10/100/1000 RJ45 (16 bypass pairs) ports, 1 x MGMT, 1 x HA, dual AC power supplies
| Product Name | Fortinet FG-400E-BYPASS Firewall |
| Product Description | High-performance NGFW with extensive connectivity options |
| Type | Network Security Appliance |
| Connectivity | 32 x 10/100/1000 RJ45 ports (16 bypass pairs), 1 x MGMT port, 1 x HA port |
| Power Supply | Dual AC power supplies |
| Hardware Acceleration | SPU NP6Lite and CP9 |
| Firewall Throughput | 32 Gbps |
| IPS Throughput | 6.5 Gbps |
| NGFW Throughput | 5.5 Gbps |
| Threat Protection Throughput | 4 Gbps |
| Concurrent Sessions | 3.5 million |
| New Sessions per Second | 310 |
| IPsec VPN Throughput | 20 Gbps |
| SSL VPN Throughput | 4.5 Gbps |
| Dimensions (H x W x D) | 1.75 x 17 x 15.4 inches (44.45 x 431.8 x 391.16 mm) |
| Weight | 17.64 lbs (8 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity Range | 20% to 90% non-condensing |
| Compliance | CE, FCC, RoHS |
