The FortiGate 3700F Series enables organizations to build security-driven networks, forming the foundation of a robust Hybrid Mesh Firewall architecture. This approach weaves security deep into datacenters and across hybrid IT environments, protecting any edge at any scale. With its compact 2U form factor, the FG-3700F consolidates networking and security to reduce complexity and footprint while delivering ultra-low latency.
Powered by Fortinet’s custom-built NP7 and CP9 security processing units (SPUs), the FortiGate 3700F delivers high performance, including 589 Gbps firewall throughput and 190 Gbps application control. Powered by a rich set of AI/ML-based FortiGuard Services and an integrated security fabric platform, the FortiGate 3700F Series delivers coordinated, automated, end-to-end threat protection across use cases. It also features integrated Zero Trust Network Access (ZTNA) enforcement within an NGFW solution to automatically control, verify, and facilitate user access to applications.
Hyperscale Security with 400GE Connectivity for the Modern Data Center
- High Performance: Utilizes Fortinet's patented NP7 and CP9 SPUs to deliver 80 Gbps NGFW throughput and up to 589 Gbps firewall throughput.
- High-Speed Connectivity: Features multiple 400 GE QSFP-DD, 200 GE QSFP56, and 100 GE QSFP28 ports to support hyperscale data transfer rates.
- AI/ML-Powered Security: Integrates FortiGuard Labs’ suite of AI-powered security services to help protect against ransomware, malware, zero days, and sophisticated AI-powered cyberattacks.
- Ultra-Low Latency: Purpose-built acceleration supports minimal network delays for demanding environments.
- Integrated ZTNA: Provides built-in Zero Trust Network Access enforcement to verify users and devices before granting application access.
- Energy Efficient Design: SPU-based architecture helps reduce power consumption and footprint while maintaining high performance.
Ideal Use Cases
- Hyperscale Data Centers: Securing high-volume traffic with 400GE interfaces and massive session capacity.
- Internal Segmentation: Using VXLAN segmentation to bridge physical and virtual domains with Layer 4 firewall rules.
- Hybrid Cloud Environments: Delivering consistent security policies and visibility across on-premise and cloud infrastructures.
- Mobile Security (4G/5G): Providing CGNAT and IPv6 migration options, including NAT44, NAT444, NAT64/DNS64, NAT46 for 4G Gi/sGi, and 5G N6 connectivity and security.
Technical Specifications Summary
- NGFW Throughput: 80 Gbps
- IPS Throughput: 86 Gbps
- Threat Protection Throughput: 75 Gbps
- IPv4 Firewall Throughput (1518/512/64 byte UDP): 589 / 589 / 420 Gbps
- IPsec VPN Throughput (512 byte): 160 Gbps
- SSL-VPN Throughput: 16 Gbps
- Interfaces: 4x QSFP-DD (400/200/100/40GE), 20x SFP56 (50GE class; including 2x HA), 4x ULL SFP28, 2x 10GE/GE RJ45 management
- Power Consumption (Average / Maximum): 590 W / 1140 W
- Dimensions (H x W x L): 88.9 x 443 x 607.1 mm
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Compliance / Certifications: FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB; USGv6/IPv6
Upgrade Your Network Security
Secure your hyperscale environment with the FortiGate 3700F.
