The FortiGate 30G series provides a unified security and networking framework designed to transform WAN architecture at any scale. Powered by Fortinet's patented SD-WAN-based ASIC and the converged FortiOS operating system, the FortiGate 31G delivers high performance and efficiency while maintaining a compact, desktop-ready form factor. This firewall integrates SD-WAN and advanced security functions into a single platform, supporting deployment within a Hybrid Mesh Firewall architecture.
With 30 GB of onboard SSD storage and the FG-31G-BDL-809-60 entitlement, this bundle is engineered for long-term operational stability. It supports real-time SSL inspection and FortiGuard AI-Powered Security Services capabilities, helping maintain visibility into users, devices, and applications while reducing the risk of threats becoming a network bottleneck.
Secure SD-WAN and NGFW Convergence with 5-Year Protection
- Unmatched ASIC Performance: Built on a patented SD-WAN-based ASIC to accelerate the convergence of networking and security functions.
- 5-Year Bundle Entitlement: FG-31G-BDL-809-60 includes 5 Year FortiCare Premium and FortiGuard Enterprise Protection.
- Dedicated 30 GB SSD: Onboard storage capacity for the FortiGate 31G model.
- Hardware-Based Trust: Features a Trusted Platform Module (TPM) to help secure cryptographic operations.
- SSL Inspection Performance: Up to 400 Mbps SSL inspection throughput (IPS, avg. HTTPS).
- Unified Management: Supports centralized management options including FortiManager and FortiGate Cloud.
- Efficient Power Profile: 12VDC, 2A external adapter, 8.1 W average / 9.3 W maximum power consumption.
Ideal Use Cases
- Distributed Enterprise Branches: Enables secure branch connectivity with integrated SD-WAN and unified protection for LAN/WAN.
- Secure Remote and Hybrid Work: Enhances connectivity with accelerated IPsec VPN performance for direct internet access.
- Retail and Point of Sale: Helps secure applications and transactions with integrated inspection capabilities and security policy control.
- Secure Branch Expansion: Supports extending security to WAN, LAN, and WLAN environments when integrated with compatible Fortinet solutions.
Technical Specifications Summary
- IPv4 Firewall Throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
- IPS Throughput (Enterprise Mix): 800 Mbps
- NGFW Throughput: 570 Mbps
- Threat Protection Throughput: 500 Mbps
- IPsec VPN Throughput (512 byte): 3.5 Gbps
- SSL Inspection Throughput (IPS, avg. HTTPS): 400 Mbps
- Concurrent Sessions / New Sessions: 600,000 TCP sessions, 30,000 new sessions/second
- Interfaces: 1x GE RJ45 WAN, 2x GE RJ45, 1x GE RJ45 FortiLink, 1x RJ45 console
- Storage / TPM: 30 GB SSD, TPM: Yes
- Power / Environment: 8.1 W avg / 9.3 W max, 0°C to 40°C operating temperature, 20% to 90% non-condensing humidity
- Compliance / Certifications: FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA; USGv6/IPv6
Upgrade Your Network Security
Deploy the FortiGate 31G today for high-performance firewalling and five years of FortiCare Premium and FortiGuard Enterprise Protection entitlement.
