The FortiGate 1000F Series is engineered for hyperscale security, offering deep visibility and protection for data centers and hybrid IT architectures. Utilizing Fortinet’s custom SPU NP7 network processors, the 1000F delivers offloaded performance for VXLAN, IPsec, and firewall functions, ensuring that security never becomes a network bottleneck. The appliance supports native 100 GE connectivity to simplify network designs without relying on additional bridges or switches.
Integrated with AI/ML-powered FortiGuard Services, the FG-1000F detects and prevents known and unknown attacks, including ransomware and zero-day threats. It features the industry’s first integrated Zero Trust Network Access (ZTNA) enforcement within an NGFW solution, automatically controlling, verifying, and facilitating user access to applications for a seamless and secure user experience.
Technical Specifications Summary
- IPv4 firewall throughput (1518/512/64 byte UDP): 198 / 196 / 134 Gbps
- IPv6 firewall throughput (1518/512/86 byte UDP): 198 / 196 / 134 Gbps
- IPS throughput (enterprise traffic mix): 19 Gbps
- NGFW throughput (enterprise traffic mix): 15 Gbps
- Threat protection throughput (enterprise traffic mix): 13 Gbps
- IPsec VPN throughput (512 byte): 55 Gbps
- SSL-VPN throughput: 5.3 Gbps
- Concurrent sessions (TCP): 7.5 Million
- New sessions/second (TCP): 650,000
- Interfaces: 2x 100 GE QSFP28, 8x 25 GE SFP28, 16x 10 GE SFP+, 8x multi-rate RJ45 slots (10 GE/5 GE/2.5 GE/GE/100M)
- Form factor and power: 2RU rack mount, dual hot-swappable AC power supplies, 210 W avg / 408 W max
- Next-Generation Firewall (NGFW): Protects against sophisticated cyberattacks with natively integrated security services.
- Segmentation: Bridges physical and virtual domains with ultra-scalable, low-latency VXLAN segmentation.
- Secure SD-WAN: Transforms WANs with a unified security and management framework for superior quality of experience (QoE).
- Mobile Security: Offers high-performance CGNAT and IPv6 migration options for 4G, 5G, and IoT environments.
- Firewall latency (64 byte UDP): 3.45 µs
- Firewall throughput (packets per second): 201 Mpps
- SSL inspection throughput (IPS, avg HTTPS): 10 Gbps
- Application control throughput (HTTP 64K): 44 Gbps
- Gateway-to-gateway IPsec VPN tunnels: 20,000
- Dimensions and weight: 3.5 x 17.44 x 17.63 in (88.9 x 443 x 447.4 mm), 21.94 lbs (9.95 kg)
- Operating environment: 0°C to 40°C (32°F to 104°F), 66.7 dBA, up to 10,000 ft (3048 m)
