Unmatched Scanning Precision in Extreme Environments
The Zebra DS3608-HD is engineered for mission-critical operations where accuracy and durability are non-negotiable. Designed for manufacturing, electronics, and medical equipment production, it delivers first-time capture of ultra-dense barcodes while withstanding the harshest industrial conditions. Powered by Zebra’s PRZM Intelligent Imaging, it ensures consistent performance even on damaged, dirty, or low-quality codes.
Key Benefits & Features
- High-Density Barcode Capture: Specially optimized to read tiny and dense 1D and 2D barcodes, including 3 mil codes that are difficult to see with the naked eye.
- Ultra-Rugged Construction: The most indestructible design in its class, surviving 10 ft. (3 m) drops to concrete and 7,500 tumbles.
- Dual IP65/IP68 Sealing: Dustproof, spray-proof, and waterproof. This scanner can handle the force of jetting water and full submersion.
- PRZM Intelligent Imaging: Zebra exclusive technology that redefines imager performance, allowing for rapid-fire capture of barcodes under shrinkwrap or on high-gloss surfaces.
- Multi-Code Data Formatting: Increase throughput by capturing up to 20 barcodes with a single press of the scan trigger.
- Industrial Ethernet Support: Seamlessly connects to Industrial Ethernet networks without the need for third-party conversion equipment.
Ideal Use Cases
- Electronics and semiconductor manufacturing lines for track and trace
- Medical device production and component-level tracking
- Warehouse receiving and shipping in extreme temperature environments
- Industrial automation requiring direct connection to PLC systems
- Sub-assembly and quality control processes with high-density labels
Technical Specifications
- Scan Capability: 1D and 2D high-density barcodes and standard codes
- Imager Sensor: 1,280 x 960 pixels
- Drop Resistance: 10 ft. / 3 m to concrete
- Sealing: IP65 and IP68 (Scanner); IP65 (Cradle)
- Interfaces: USB, RS232, Keyboard Wedge, Industrial Ethernet (EtherNet/IP, Profinet, Modbus)
- Scan Range: Up to 26 inches (66 cm) for 20 mil Code 128
- Operating Temperature: -30 deg C to 50 deg C (-22 deg F to 122 deg F)
- Tumble Rating: 7,500 3.3 ft. (1 m) tumbles
- Print Contrast: 15% minimum reflective difference
- Aimer: 655 nm laser
Maximize Accuracy and Uptime Today
Upgrade your operations with the Zebra DS3608-HD and ensure flawless scanning performance in any environment. Order today to eliminate errors and boost productivity.
