MIKROTIK CRS318-1FI-15FR-2S-OUT SWITCH
| Model: | CRS318-1FI-15FR-2S-OUT |
| Detail: |
|
| List Price: | |
| Price: | $145.00 |
| You Save: | $4.00 (3% OFF) |
| Condition: | Brand New Sealed |
| Availability: | Out of Stock |
| Shipping: | FREE SHIPPING for all U.S orders over $100. Please call us at 201-559-1474, fill out the contact form, or chat with a live agent for other shipping methods. |
| Tax: | $0.00 Tax Outside NJ and TX |
| Quantity: |
Description
MikroTik CRS318-1FI-15FR-2S-OUT Switch
The CRS318-1FI-15FR-2S-OUT eliminates the need for costly GPON base stations and optical splitters. As part of the GPEN concept, it is designed to provide the speed and flexibility of fiber networking while leveraging the benefits of Ethernet. This switch provides a cost-efficient and uncomplicated option for Internet Service Providers (ISPs) to furnish Internet access to individual apartment units. It is equipped with two SFP ports for fiber connectivity. Please note that the power supply is not included and must be acquired separately.
Quick Specs:
- 16x 10/100 Ethernet Ports
- 2x SFP ports uplink
- PoE in: Passive PoE
- PoE out ports : Ether15
Please see the related tabs for the CRS318-1FI-15FR-2S-OUT datasheet and compatible accessories.
Accessories
| Accessories |
| DC to Terminal block adapter |
| K-66 fastening set |
| Hose clamp 2 |
Specifications
| Specifications | CRS318-1FI-15FR-2S-OUT |
| Memory | 256 MB |
| Flash Storage size | 16 MB |
| CPU | 98DX224S 800 MHz |
| CPU core count | 1 |
| Switch chip model | 98DX224S |
| OS | RouterOS / SwitchOS |
| Non-blocking throughput | 3.6 Gbps |
| Switching capacity | 7.2 Gbps |
| Forwarding rate | 5.4 Mpps |
| MTBF | Approximately 200.000 hours at 25C |
| Temperature | -40°C to 70°C tested |
| Certification & Approvals | |
| Certification | CE, EAC, ROHS |
| IP | IP54 |
Properties
| Properties | MikroTik CRS318-1FI-15FR-2S-OUT |
| Description | An outdoor 18 port switch with 15 reverse PoE ports and SFP. Cut costs, not speed - choose GPEN over GPON! |
| Product Family | CRS Series |
| Product Type | Ethernet Switch |
| Ports | |
| 10/100 Ethernet ports | 16 |
| SFP | 2 |
| Extras | CPU temperature monitor Voltage Monitor |
| Dimensions | 304 x 212 x 71 mm |
| PoE-in | Ports 1 - 14 and 16 |
| PoE-out | On Ether15 |
| Number of DC inputs | 16 (PoE-IN, DC jack) |
| DC jack input Voltage | 18-57 V |
| Max power consumption | 29 W |
| Max power consumption without attachments | 10 W |
| Cooling type | Passive |
| PoE in | Passive PoE |
| PoE in input Voltage | 18-57 V (recommended 36-57V) |
| PoE-out ports | Ether15 |
| PoE out | Passive PoE |
| Max out per port output (input 18-30 V) | 0.75 A |
| Max out per port output (input 30-57 V) | 0.5 A |
| Max total out (A) | 0.75 A |
