CISCO CP-7965G IP PHONE

Accessories

Specifications

Directories	The Cisco Unified IP Conference Station 7937G identifies incoming messages and categorizes them for users on the screen. This feature allows users to quickly and effectively return calls using direct dial-back capability. The corporate directory integrates with the Lightweight Directory Access Protocol Version 3 (LDAPv3) standard directory.
Settings	The Settings feature key allows the user to adjust display contrast, select background images (if available), and select from a large number of unique ringer sounds through the User Preference menu. Network Configuration preferences also can be set up (usually by the system administrator). Configuration can be either automatically or manually set up for Dynamic Host Control Protocol (DHCP), Trivial File Transfer Protocol (TFTP), Cisco Unified Communications Manager, and backup Cisco Unified Communications Manager instances.
Services	The Cisco Unified IP Conference Station 7937G allows users to quickly access diverse information such as weather, stocks, quote of the day, or any Web-based information. The Cisco Unified IP Conference Station 7937G uses XML to provide a portal to an ever-growing world of applications, features, and information.
Hold, Mute, and Redial Keys	The Mute key is a fixed key. When it is active, the LED flashes on the Cisco Unified IP Conference Station 7937G as well as on the optional microphone kit. Hold and Redial are provided as soft keys associated with the screen, and are always at the same position for easy access.
Display	The Conference Station has a large high-resolution, graphical 32 level grayscale, backlit display (255 x 128 pixels).
Speakerphone	The Cisco Unified IP Conference Station 7937G offers full duplex high-quality wideband speakerphone technology. Included are Automatic Gain Control, Comfort Noise Generation, Silence Suppression/Voice Activity Detection, Echo Suppression, and Dynamic Noise Reduction, which reduces noise by up to 9 dB from constant noise sources such as fans or HVAC systems.
Ethernet Switch	The internal Ethernet port allows for a direct connection to a 10/100BASE-T Ethernet network through an RJ-45 interface with single LAN connectivity for the Cisco Unified IP Conference Station 7937G. Co-locating a PC with the Cisco Unified IP Conference Station 7937G is not supported.
Flexible Power Options	The Cisco Unified Conference Station 7937G supports IEEE 803.af PoE Class 3, which allows powering from any of the Cisco Inline Power-capable blades and boxes. In addition, the Conference Station can be powered locally with a power supply (part number CP-PWR-CUBE- 3) when combined with the Cisco Unified IP Conference Station 7937G Power Splitter.
Signaling Protocol Support	The Cisco Unified IP Conference Station 7937G supports Skinny Client Control Protocol (SCCP).
Codec Support	G.711, G.729, and G.722 audio compression codecs are available.
Quality of Service (QoS) Options	The Cisco Unified IP Conference Station 7937G supports DHCP and 802.1Q/p standards. The Conference Station can also be configured with an 801.1Q VLAN header containing the VLAN ID overrides configured by the Admin VLAN ID.
Security	The Cisco Unified IP Conference Station 7937G supports device authentication via 802.1.x supplicant and 802.1x MD5-EAP.
Language Support	More than 30 languages will be supported within 6 months of FCS (dependent on Cisco Unified Communications Manager version).
Configuration Options	IP address assignment can be statically configured or configured through the DHCP client.
Voice Quality	Comfort-noise generation and voice activity detection (VAD) programming are performed on a system basis.
Phone-Casing Composition	Polycarbonate acrylonitrile butadiene styrene (ABS) plastic in textured dark gray color with silver bezel
Power Requirements	The Cisco Unified IP Conference Station 7937G is interoperable IEEE 802.3af PoE (Class 3 device); 48 VDC is required; it can be supplied locally at the desktop using an optional AC-to- DC power supply (part number CP-PWR-CUBE-3=). Use of the power supply also requires the Cisco Unified IP Conference Station 7937G Power Splitter and one of the corresponding AC country cords listed in Table 7.
Safety	● Underwriters Laboratories (UL) 60950
	● Canadian Standards Association (CSA) C22.2 No. 60950
	● IEN 60950-1
	● AS/NZS 60950-1
Electromagnetic Compatibility (EMC)	● Federal Communications Commission (FCC) Part 15 (CFR 47) Class B
	● ICES-003 Class B
	● EN55022 Class B
	● CISPR22 Class B
	● AS/NZ 3548 CISCPR 22 Class B
	● VCCI Class B
	● EN55024
	● EN61000-6-1
	● EN 61000-3-2
	● EN 61000-3-3

Properties

Properties	CP-7965G
Description	Cisco Unified IP Conference Station 7937G
Product Family	CP7900 Series
Product Type	IP Phones
Superior wideband acoustics	● Wideband frequency response is more than double that of narrowband, resulting in a richer and clearer sound. ● Enhances speech quality and speaker recognition. ● Provides excellent voice quality for both wideband and narrowband calls.
Expanded room coverage	Extends room coverage up to 30 feet by 40 feet with the optional Cisco Unified IP Conference Station 7937G microphone kit.
Support for third-party wireless lapel microphone kit	Allows presenters to be easily heard even if walking away from the Cisco Unified IP Conference Station 7937G microphones.
IEEE 802.3af line power	Local power supply is not required.
Support for the Cisco Power Cube 3	Uses standard Cisco Unified IP Phone Power Supply.*
Extensible Markup Language (XML) services	Support for Cisco XML services includes Cisco Unified Communications Manager and third-party directories, Cisco Web Dialer, Extension Mobility features, and Personal Assistant.
Support for Cisco Unified Communications Manager	Supports Cisco Unified Communications Manager Releases 4.1, 4.2, 4.3, 5.1, and 6.x.
Cisco Unified Communications Manager Express and Cisco Smart Business Communications System	Support Cisco Unified Communications Manager Express Release 4.3 - 12.4(15)XZ and later.
Localizations provided within 6 months of FCS	Will include localized user interface and customer documentation.
Dimensions (H x W x D)	15 3/8 x 141/2 x 2 5/8 inches. (39.05 x 36.83 x 6.67 cm)
Display	3.07 x 1.42 inches (7.8 x 3.6 cm); 255 x 128 pixels
