JUNIPER CHAS-ACX4000-S SPARE CHASSIS

Accessories

Accessories
PKG-1U-ACXS	Package Spare for ACX 1RU Chassis
RACK-MNT-1RU-19-S	ACX Series 1 RU 19" Mounting Bracket"
RACK-MNT-1RU-23-S	ACX Series 1 RU 23" Mounting Bracket"
CBL-PWR-C15M-HITEMP-US	Power Cord, AC, C15M

Specifications

Specifications	CHAS-ACX4000-S
System Throughput	Up to 60 Gbps
Operating temperature	-40° to 149° F (-40° to 65° C)
Humidity	95% RH noncondensing
Platform Features
Layer 2	IEEE 802.3 bridging IEEE 802.1q IEEE 802.1ad (Q-in-Q) VLAN id manipulation for outer/inner: swap/pop/push Rapid Spanning Tree Protocol (RSTP)/VLAN Spanning Tree Protocol (VSTP)/Multiple Spanning Tree Protocol (MSTP) Link Aggregation Control Protocol (LACP) Enhanced load balancing based on L2-L4 header info Link Layer Discovery Protocol (LLDP) Layer 2 bridge protocol data unit (BPDU) tunneling/MAC rewrite
Layer 3	IPv4 IPv6 RPF Equal-cost multipath (ECMP) Enhanced load balancing based on L2-L4 header info OSPF IS-IS BGP Indirect/composite next hop
MPLS and Seamless MPLS	RSVP LDP Path Computation Element Protocol (PCEP) RSVP-TE BGP-LU LDP-RSVP RSVP fast reroute (FRR)
Services	IEEE 802.3 bridge domain PWE (T-LDP) L2VPN (BGP) Layer 3 VPN Integrated routing and bridging (IRB) Stateless filters L2-L4 Circuit emulation SAToP/CESoPSN/ATM o MPLS
Class of Service (CoS)	8 queues per port with schedulers and shaping Classification based on 802.1p, DiffServ code point(DSCP), IP-precedence, Exp bit Single-rate policer ingress/egress Two-rate three-color policer ingress/egress Per-Port Egress Shaping
OAM and SLA Management	Bidirectional Forwarding Detection (BFD) Connectivity fault management (CFM) Y.1731 RFC2544 TWAMP
Multicast	Protocol Independent Multicast (PIM) Internet Group Management Protocol (IGMP) IGMP snooping
Timing and Sync	BITS/1pps/10MHz 1588v2 BC 1588v2 over IP 1588v2 over Ethernet Synchronous Ethernet Hybrid mode
Security	L2 storm control
Configuration, Management and Automation	CLI NETCONF NMP v2/v3 SLAX/Python on-box scripting tools ZTD YANG
Safety Approvals	CAN/CSA-C22.2 No. 60950-1 UL 60950-1 EN 60950-1 IEC 60950-1CB Scheme EN 60825-1
EMC	AS/NZS CISPR22 Class A EN55022 Class A VCCI Class A FCC Part 15 Class A IECS-003 Issue 4 BSMI CNS 13438 and NCC C6357 Taiwan Radiated Emissions KN 22, Class A CISPR 32/EN55032: 2012 European Radiated Emissions Class A EN-61000-4-6 Low Frequency Common Immunity EN-61000-4-11 Voltage Dips and Sags CISPR 24/EN55024 Information Technology Equipment Immunity Characteristics
ETSI (European Telecommunications Standardization Institute)	EN 300 386 V1.6.1 Telecommunication Network Equipment, Electromagnetic Compatibility Requirements ETSI EN 300 019-2-1 (2000) Storage, Class T1.2 ETSI EN 300 019-2-2 (1999) Transportation, Class T2.3 ETSI EN 300 019-2-4 (2003) Stationary Use at Non-Weather Protected Locations, Class 4.1 ETSI 300753 (1997) Acoustic Noise Emitted by Telecommunications Equipment
NEBS	SR-3580 NEBS Criteria Levels (Level 3 Compliance) GR-63-CORE: NEBS, Physical Protection GR-1089-CORE: EMC and Electrical Safety for Network Telecommunications Equipment (Issue 6 compliant) GR-3108-CORE: Generic Requirements for Network Equipment in the Outside Plant (OSP)
Telecomm Compliance	T1 and XDSL Interfaces FCC Part 68 (T1 Only) Industry Canada CS-03 JATE Green Book E1 Interface TBR 12/13 ACA TS016 G.703 RTTE Directive 1995/5/EC Device management: NETCONF, CLI, SNMP v1/v2/v3 End-to-end provisioning of E-Line, emulated LAN (ELAN), Layer 3 VPN (L3VPN), OAM, class of service (CoS) Device and service-level fault management Device and service-level performance management
Metro Ethernet Forum (MEF)	MEF CE2.0 compliant

Properties

Properties	Juniper CHAS-ACX4000-S
Description	Converged Access Gateway, Spare Chassis , 2 x Open slot, No power supplies, No fan tray
Product Family	ACX4000 Series
Product Type	Spare Chassis
Open slots	2
Built-In Interface Options
TDM (T1/E1)	Up to 32 (with MICs)
OC3 (STM1)/OC12 (STM4)	Up to 8/2 (with MICs)
GbE (combo)	8 (PoE++ support on 2 ports)
GbE (SFP)	Up to 14 (with MICs)
10GbE (SFP+)	2
Console port	RJ-45 connector
Management Ethernet port	RJ-45 connector
Dimension (WxHxD)	17.5 x 4.35 x 9.25 in (44.5 x 11 x 23.5 cm)
Weight (lb/kg)	23.8 lb (10.82 kg) (Fully configured with two power supply units, two MICs)
Power	No power supplies
Rack Unit	1 U
