CISCO C9300L-48T-4X-A SWITCH

Model: C9300L-48T-4X-A
Detail:
  • Managed, Rack-mountable, Fixed (4 x 10G/1G SFP+ uplinks), 48 x 1G ports, nonPoE
List Price: US$8,847.98
Price:
$6,375.00
You Save: $2,472.98 (28% OFF)
Condition: Brand New Sealed
Availability: SPECIAL ORDER
Shipping: FREE SHIPPING for all U.S orders over $100. Please call us at 201-559-1474, fill out the contact form, or chat with a live agent for other shipping methods.
Tax: $0.00 Tax Outside NJ and TX
Quantity:
+
-

Description

Cisco C9300L-48T-4X-A Switch

The Cisco C9300L-48T-4X-A is an affordable member of the Catalyst 9300 series. It supports Ipv4/Ipv6 for network management and data traffic. It runs the Cisco IOS XE operating system, which offers programmability and automation. It has QoS capabilities and built-in security features.

Key Specs:

  • Network Advantage License
  • 4x10G/1G SFP+ uplinks
  • nonPoE
  • Stackable

Please see the C9300L-48T-4X-A datasheet and compatible accessories from the tabs above.

Accessories

Stacking Support Stackwise-320‚
Stacking bandwidth support 320 Gbps‚
Stacking hardware‚ C9300L-STACK-KIT‚
Number of
members
8
Supported stack members Other C9300 SKUs with same license level
Stacking accessories
STACK-T3-50CM‚ Data stack 50cm cable (default cable with C9300L Stack Kit)‚
STACK-T3-1M‚ Data stack 1m cable (cable option with C9300L Stack Kit)‚
STACK T3-3M‚ Data stack 3m cable (cable option with C9300L Stack Kit)‚
C9300L-STACK-KIT‚ Stack kit for C9300L SKUs only: Two data stack adapters and one‚
C9300L-STACK-KIT2 Stack kit for C9300LM and C9300L SKUs: Two data stack adapters and one data stack
cable
STACK-T3A-50CM‚ Data stack 50cm cable (cable option with C9300L Stack Kit2)
STACK-T3A-1M Data stack 1m cable (cable option with C9300L Stack Kit2)
STACK-T3A-3M Data stack 3m cable (cable option with C9300L Stack Kit2)

Specifications

Specifications C9300L-48T-4X-A
Console Ports RJ-45-to-DB9 cable for PC connections‚
DRAM 8 GB‚
Flash Memory 16 GB‚
Switching capacity 176 Gbps‚
Forwarding rate‚ 130.95 Mpps‚
MAC addresses 32000
Operating Temperature
Up to 5,000 ft (1500 m)
-5°C to +45°C
Operating Temperature
Up to 10,000 ft (3000 m)
-5°C to +40°C
Safety UL 60950-1
CAN/CSA-C222.2 No. 60950-1 EN 60950-1
IEC 60950-1
AS/NZS 60950.1
IEEE 802.3
Electromagnetic compatibility
certifications
47 CFR Part 15
EN 300 386 V1.6.1 EN 55032 Class A CISPR 32 Class A
EN61000-3-2
EN61000-3-3
ICES-003 Class A
TCVN 7189 Class A V-3 Class A
CISPR 35
EN 300 386
EN 55035
TCVN 7317
V-2/2015.04
V-3/2015.04
CNS13438
KN32
KN35
QCVN 118:2018/BTTTT
VCCI-CISPR 32 Class A‚
EMC
compliance
FCC Part 15 (CFR 47) Class A ICES-003 Class A
EN 55032 Class A
CISPR 32 Class A
AS/NZS 3548 Class A
BSMI Class A
(AC input models only)
VCCI Class A
EN 55024, EN300386,
EN 61000-3-2, EN 61000-3-3
EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6
Environmental Reduction of Hazardous Substances (ROHS) 5

Properties

Properties C9300L-48T-4X-A
Description Catalyst 9300 48-port 1G copper with fixed 4x10G/1G SFP+ uplinks, data only Network Advantage‚
Product Family Catalyst 9300
Product Type Ethernet Switch
Number of Ports 48
Downlinks total 10/100/1000
or PoE+ copper ports
48 port Data
Uplink configuration 4x 10G/1G fixed uplinks
Cisco IOS Software Network Advantage
Default primary AC
power supply
PWR-C1-350WAC-P
Available PoE power with
additional secondary
power supply
No PoE‚
Fans -
Chassis + FEP +
‚ Fan Dimensions (HxWxD) Inches
1.73 X 17.5 X 17.7‚
