APC AP8858 - NetShelter Metered Rack PDU 0U 16A 208V/230V

[accessories]

Installation Guide	Included in the box
Rack Mounting Brackets	Included in the box
Serial Configuration Cable	Included in the box
Safety Guide	Included in the box

[/accesories]

Overview

The APC NetShelter AP8858 is a metered rack PDU designed to provide secure, high-density power distribution for modern IT environments. With active metering, alarm thresholds, and real-time monitoring, it helps data center operators ensure load balance, avoid overloads, and optimize energy consumption.

Key Features & Benefits

• Active Metering: Real-time power monitoring improves load management.
• High Outlet Density: 18 IEC C13 and 2 IEC C19 outlets support a wide range of equipment.
• User-Defined Alarms: Alerts for potential circuit overloads reduce downtime risk.
• Remote Access: Secure Web, SNMP, and Telnet interfaces simplify management.
• Temperature/Humidity Port: Environmental monitoring enhances uptime assurance.

Technical Deep Dive

The AP8858 delivers up to 3.3kW at 208V or 3.7kW at 230V through its IEC C20 input, ensuring reliable distribution across dense racks. Its line-rated current of 16A supports medium to large server deployments without risk of breaker trips under normal conditions.

Unlike basic PDUs, the AP8858 integrates active metering technology that continuously measures energy usage. This empowers IT managers to make informed load-balancing decisions and avoid hotspots that lead to inefficiency. The locking IEC receptacles further secure connections, preventing accidental disconnections in critical uptime environments.

With ultra-low profile circuit breakers and remote management capabilities, the AP8858 aligns with APC’s centralized management platforms such as InfraStruxure Central, ensuring seamless integration into enterprise monitoring ecosystems.

Ideal Applications

• Enterprise data centers and colocation facilities
• Server racks with mixed load types
• Network closets requiring active monitoring
• High-density IT deployments with critical uptime needs

Frequently Asked Questions (FAQs)

Q1: How is the AP8858 installed?
A: It is a 0U vertical rack-mounted PDU with included brackets for side mounting.

Q2: What performance does it provide?
A: It delivers up to 3.3kW at 208V or 3.7kW at 230V, with 18 C13 and 2 C19 outlets.

Q3: How can it be managed?
A: The unit supports secure Web, SNMP, and Telnet access, with compatibility for APC centralized management tools.

Brand	APC by Schneider Electric
Model	AP8858
Product Type	NetShelter Metered Rack PDU
Form Factor	0U Vertical
Dimensions (H x W x D)	35.5" x 2.2" x 1.7" (902 x 56 x 44 mm)
Weight	6.46 lb (2.93 kg)
Color	Black
Number of Rack Units	0U
Mounting Mode	Rack-mounted (Vertical, Side Mountable)
Cooling	Not specified

PDU Type	Metered
Input Voltage	200 V / 208 V / 230 V
Output Voltage	100 V / 200 V / 208 V / 230 V
Input Plug Type	IEC 60320 C20
Input Frequency	50/60 Hz
Line Rated Current	16 A (Max 20 A)
Load Capacity	3300 VA
Outlets	18 × IEC C13, 2 × IEC C19
Communication Ports	Web, SNMP, Telnet
Operating Temperature	23–140 °F (-5–60 °C)
Storage Temperature	-13–149 °F (-25–65 °C)
Operating Humidity	5–95% non-condensing
Storage Humidity	5–95% non-condensing
Operating Altitude	0–10,000 ft
Storage Altitude	0–50,000 ft
Compliance	METI Denan, VDE, CSA C22.2 No. 60950, IEC 60950, UL 60950-1, RoHS, REACh
Warranty	2 years repair or replace
