Cisco Aironet 2.4-GHz access point antennas are compatible with all Cisco RP-TNC-equipped access points. Coupling the appropriate antenna and access point allows for efficient coverage in any facility, as well as better reliability at higher data rates.
| Properties |
Cisco AIR-ANT24020V-R 2.4-GHz Omnidirectional Antenna |
| Description |
Indoor diversity omnidirectional antenna operating in the 2.4–2.5 GHz range for Cisco Aironet devices |
| Compatibility |
2.4-GHz Cisco Aironet devices with RP-TNC connectors |
| Product Type |
Diversity Omnidirectional Antenna |
| Specifications |
AIR-ANT24020V-R |
| Frequency Range |
2400–2500 MHz |
| VSWR |
1.5:1 |
| Peak Gain |
2.2 dBi |
| Polarization |
Linear |
| Azimuth Plane |
Omnidirectional |
| Elevation Beamwidth |
97° |
| Dimensions (L x W x D) |
6.9 in x 3 in x <1 in (17.5 cm x 7.6 cm x <2.5 cm) |
| Cable |
3 ft. (91.4 cm) plenum-rated, UV-stable |
| Connector |
RP-TNC |
| Operating Environment |
Indoor use only |
| Temperature Range |
32°F to 131°F (0°C to 55°C) |
| Included Accessories |
Mounting hardware kit: 2 recessed ceiling T-rail spacers, 2 channel ceiling rail adapters, 2 Phillips screws |
| Suggested Cable |
High-quality, low-loss coaxial cable (short length recommended to minimize signal loss) |
