AXIS TU6004-E 30 Meter Cable (02252-001)

The AXIS TU6004-E 30 Meter Cable is a robust and flexible cable designed for both indoor and outdoor applications. With an IP66, IP67, and IP6K9K-rated casing, it ensures protection against dust, water, and extreme environmental conditions. This high-bandwidth cable minimizes latency, making it ideal for seamless data transmission between AXIS sensor units and main units. The 40 mm (1.6 in) bending radius allows for easy installation, and its SMA and FAKRA connectors provide secure and stable connectivity.

Key Features:

• 30 Meter Length: Designed for extended connectivity between AXIS devices.
• Indoor & Outdoor Rated: IP66, IP67, and IP6K9K-rated casing for durability.
• High-Speed Data Transmission: Supports high-frequency signals up to 3 GHz.
• Flexible Installation: 40 mm (1.6 in) bending radius for easy routing.
• Secure Connectors: Equipped with SMA and FAKRA connectors.
• Compatible with AXIS Devices: Works with AXIS F91 main units, F21 sensor units, F4105-LRE Dome Sensor, and F7225-RE Pinhole Sensor.

Technical Specifications:

• Length: 30 meters (98 ft)
• Diameter: 5 ±0.1 mm (0.2 in)
• Bending Radius: 40 mm (1.6 in)
• Impedance: 50 Ohms
• Frequency Range: 0–3 GHz
• Connectors: SMA and FAKRA
• Operating Temperature: -40°C to 75°C (-40°F to 167°F)
• Weight: 1140 g (2.51 lb)
• Compliance: UL CL2 Sunlight Resistant E335585-T, UN ECE R118
