AXIS P7316 Video Encoder (02037-004)
- Full-featured, 16-channel video encoder, Support for HD analog cameras up to 4K, PTZ control, 2-way audio and configurable I/O, Zipstream with support for H.264/H.265, Signed firmware and secure boot
$1,707.00
AXIS P7316 Video Encoder
16-channel video encoder supporting HD analog and standard-definition cameras. Offers max 4K resolution at 15 fps on 4 channels and 25/30 fps in lower resolutions. Features Axis Zipstream for efficient bandwidth use, video motion detection, and active tampering alarm. Two-way audio support, PTZ control, and a single microSD/microSDHC/microSDXC card slot for edge storage. Includes power supply for DC input operation. Signed firmware and secure boot ensure robust cybersecurity.
| Product Name | AXIS P7316 Video Encoder |
| Description | Full-featured, 16-channel video encoder with support for HD analog cameras up to 4K resolution, ideal for high-quality, multi-channel video surveillance. |
| Channels | Supports 16 channels with max 4K resolution at 15 fps on 4 channels simultaneously. |
| Video Streams | H.264, H.265, and Motion JPEG supported on all channels. |
| Frame Rate | 15 fps at 4K resolution; 25/30 fps in lower resolutions. |
| Bandwidth Efficiency | Axis Zipstream technology for efficient bandwidth and storage management. |
| Video Analytics | Integrated video motion detection and active tampering alarm. |
| Audio Support | Two-way audio for communication and monitoring. |
| Input/Output | Supports configurable I/O ports for alarm and event handling. |
| PTZ Control | Supports PTZ functionality for remote camera control. |
| Storage Options | Single microSD/microSDHC/microSDXC card slot for edge storage. |
| Security Features | Signed firmware and secure boot to protect against unauthorized access. |
| Resolution | Up to 4K (3840 x 2160) at 15 fps on 4 channels; 1080p on other channels. |
| Codec Support | H.264, H.265, and Motion JPEG on all channels. |
| Audio | Two-way audio for communication and monitoring. |
| Networking | 4x IP addresses; SFP slot for optional fiber connectivity and network redundancy. |
| Storage Support | Single microSD/microSDHC/microSDXC card slot for edge storage. |
| Connectivity | RS485/422 serial port for PTZ control. |
| Power Options | Powered via included power supply connected to the DC input. |
| Environmental Standards | Operational temperature range from 0°C to 50°C (32°F to 122°F). |
| Compliance | CE, FCC, and RoHS compliant. |
| Dimensions | Customizable rack-mount design. |
