SonicWall TZ500W 01-SSC-1363 Desktop Firewall, Wireless-AC, Gen 5 Firewall Replacement with AGSS 1-Year, INTL
Overview
The SonicWall TZ500 series is a Gen 6 desktop firewall line for growing branch offices and SMBs; the TZ500W adds integrated 802.11ac wireless. The 01-SSC-1363 is the TZ500W Wireless-AC Gen 5 Firewall Replacement with AGSS bundle in the international (INTL) variant. It combines the appliance with 1 year (12 months) of the Advanced Gateway Security Suite (AGSS). SonicWall's product lifecycle table lists End of Support for the TZ500W on October 1, 2026.
Technical Details
The SonicWall TZ500W 01-SSC-1363 is a desktop next-generation firewall running SonicOS, with 8×1GbE RJ45. Threat Prevention throughput is 0.7 Gbps with Gateway AV, Anti-Spyware, IPS and Application Control enabled (1.4 Gbps firewall inspection), and it holds up to 150,000 concurrent SPI connections. The Wireless-AC model adds an integrated 802.11ac radio. This part number bundles the appliance with Gen 5 Firewall Replacement with AGSS for 1 year (12 months). It is suited to small office, branch and retail deployments for internet-edge protection and site-to-site VPN.
Best For
The TZ500W suits a small office, branch or retail site that needs 0.7 Gbps of Threat Prevention throughput and up to 150,000 concurrent SPI connections. It suits owners replacing a Gen 5 SonicWall firewall who want AGSS for 1 year activated with the hardware. Size against the Threat Prevention figure, not the firewall inspection throughput.
Not suitable if:
- your inspected traffic exceeds 0.7 Gbps, the published Threat Prevention throughput
- you need SonicWall technical support or firmware updates, since this model reached SonicWall End of Support on October 1, 2026
- you need Power over Ethernet from the firewall, since this model has none
- you require rack mounting without an additional kit, since this is a desktop appliance and requires a separate rack mount kit for rack installation
01-SSC-1363 Specifications
| Ports & Uplinks | |
|---|---|
| Fixed Interfaces | 8×1GbE RJ45 |
| Max Port Speed | 1 GbE |
| Management & Console Ports | 1×Console, 2×USB |
| Performance & Scale | |
| Firewall Throughput | 1.4 Gbps (RFC 2544) |
| Threat Prevention Throughput | 0.7 Gbps (Gateway AV, Anti-Spyware, IPS and Application Control enabled) |
| TLS/SSL Inspection Throughput | 0.225 Gbps (DPI SSL) |
| IPsec VPN Throughput | 1 Gbps (1280-byte UDP) |
| Maximum Concurrent Sessions | 150,000 (SPI) |
| New Sessions per Second | 8,000 |
| Maximum DPI Connections | 125,000 (DPI) |
| Maximum IPsec VPN Tunnels | 25 (site-to-site) |
| Power & Thermal | |
| Power Supply | 36 W external; 100-240 VAC input (50-60 Hz), 1 A |
| Redundant Power Supply | Not published |
| Maximum Power Consumption | 17.7 W |
| Physical & Environmental | |
| Form Factor | Desktop |
| Dimensions (H x W x D) | 1.38 × 5.91 × 8.86 in (3.5 × 15 × 22.5 cm) |
| Weight | 2.31 lb (1.05 kg) |
| Operating Temperature | 32 to 105 °F (0 to 40 °C) |
| Software | |
| Operating System | SonicOS |
| High Availability | Active/Standby; stateful synchronization requires the optional Stateful HA Upgrade license |
| Central Management Platform | Capture Security Center, GMS |
| Routing Protocols & IPv6 | BGP (requires Expanded License), OSPF, RIPv1/v2, static routes, policy-based routing |
FAQ
Does the SonicWall TZ500W 01-SSC-1363 include a security subscription?
Yes. The 01-SSC-1363 includes 1 year (12 months) of the Advanced Gateway Security Suite (AGSS). SonicWall's Comprehensive Gateway Security Suite datasheet describes AGSS as Capture Advanced Threat Protection plus Gateway Anti-Virus, Intrusion Prevention, Application Control, Content Filtering and 24x7 support. SonicWall's End of Support for the TZ500W on October 1, 2026 means it no longer provides technical support or firmware updates for this model.
How much traffic can the SonicWall TZ500W 01-SSC-1363 handle?
SonicWall publishes no user count, so size the TZ500W on its figures. Firewall inspection throughput is 1.4 Gbps, but Threat Prevention throughput is 0.7 Gbps with Gateway AV, Anti-Spyware, IPS and Application Control enabled; size against that. It holds 150,000 concurrent SPI connections and 125,000 DPI connections, and opens 8,000 new connections per second.
What interfaces does the SonicWall TZ500W 01-SSC-1363 have?
The TZ500W provides 8×1GbE RJ45. Management and console connectivity is 1×Console, 2×USB.
Does the SonicWall TZ500W 01-SSC-1363 support high availability?
The TZ500W supports Active/Standby high availability; stateful synchronization for the TZ500 series requires SonicWall's separate Stateful HA Upgrade license.
Does the SonicWall TZ500W 01-SSC-1363 have built-in Wi-Fi?
Yes. The TZ500W is the Wireless-AC model, with an integrated 802.11a/b/g/n/ac radio. SonicWall's datasheet notes that integrated TZ wireless supports either the 2.4 GHz or the 5 GHz band, and points to its access points for dual-band coverage.
What is the TZ500W Gen 5 Firewall Replacement with AGSS bundle?
SonicWall lists the 01-SSC-1363 as a Gen 5 firewall replacement bundle: the TZ500W appliance with AGSS for 1 year, intended for owners replacing a Gen 5 SonicWall firewall. Network Devices Inc. confirms eligibility before ordering.
Is the 01-SSC-1363 end of life?
Yes. SonicWall's product lifecycle table lists the TZ500W with a Last Order Day of April 15, 2022, Active Retirement Mode from April 16, 2022, Limited Retirement Mode from April 16, 2024, a last one-year support order on September 30, 2025 and End of Support on October 1, 2026. SonicWall names the TZ570W as the replacement.
Does the 01-SSC-1363 include SonicWall support?
The bundle lists 24x7 support, but SonicWall's End of Support for the TZ500W took effect on October 1, 2026: SonicWall no longer provides technical support, firmware updates or hardware replacement for it, although it may still offer security service subscriptions. Network Devices Inc. confirms what SonicWall will activate before the order is placed.
How is the SonicWall TZ500W 01-SSC-1363 managed?
The TZ500W is managed through Capture Security Center and GMS, and locally through the SonicOS web interface and CLI. Firewall policy, VPN and high availability are configured on the appliance; the security services on it are licensed separately unless this part number bundles them.
What condition is the 01-SSC-1363 sold in, and what warranty applies?
Network Devices Inc. supplies the 01-SSC-1363 new and factory sealed. It is covered by a one-year Network Devices Inc. warranty and a 30-day return window. Orders ship from our New Jersey and Texas warehouses.
