Cisco C2960X-HYBRID-STK Stacking Module - Extended Hybrid for Next-Generation Switching Accessibility

Cisco C2960X-HYBRID-STK Stacking Module - Extended Hybrid is designed with performance features of 2960-S and 2960-X Series Switches. This has one SFP+ port and one copper FlexStack-Plus port and is the next-generation of the world’s most widely deployed access switch.

Key Benefits of Cisco C2960X-HYBRID-STK Stacking Module - Extended Hybrid

Scalable, smart, simple and secure, Cisco C2960X-HYBRID-STK Stacking Module - Extended Hybrid provides Layer 3 routing capability and application-aware intelligence. Its fiber port allows users to extend stacking over long distances.

[specifications]

Type	FlexStack-Plus hot-swappable stacking module
Designed For	Catalyst 2960-X Series Catalyst 2960-XR Series
Bidirectional stack bandwidth	C2960-X: 80Gbps C2960-XR: 80Gbps
Hot-swappable stack module	C2960-X: Yes C2960-XR: Yes
Max stack members	C2960-X: 8 C2960-XR: 8
Supports FlexStack	C2960-X: No C2960-XR: Yes
Supports FlexStack-Plus	C2960-X: Yes C2960-XR: Yes
Net Weight	1.6 Kg
Package Weight	2.24 Kg







[/specifications]

Use Cisco C2960X-Stack Stacking Module for Enterprise-class Access

Cisco C2960X-Stack Stacking Module switches are fixed-configuration, stackable Gigabit Ethernet switches. These are ideal for enterprise-class access for campus and branch applications.

Key Benefits of Cisco C2960X-Stack Stacking Module

Cisco C2960X-Stack Stacking Module Switches are built to simplify operations and reduce total cost of ownership. These switches enable scalable, secure and energy-efficient business operations, thanks to intelligent and a range of advanced Cisco IOS software features.

[specifications] [/specifications]The Cisco Network Stacking Module enables users to have a single management plane and control plane. It is compatible with the Cisco Catalyst 9200 series switch models.

[specifications] [/specifications]

Cisco C2960X-FIBER-STK Stacking Module Works Across Multiple Settings

Cisco C2960X-FIBER-STK Stacking Module allows stacking over SFP+ ports. It provides stacking bandwidth of up to 40 Gbps for much longer distance. Use it to stack switches across wiring closets on different floors of a building or across different buildings in a campus.

Key Benefits of Cisco C2960X-FIBER-STK Stacking Module

Cisco C2960X-FIBER-STK Stacking Module can spread across multiple wiring closets on multiple floors of a building or in multiple buildings of the campus. Users can stack it with the FlexStack extended fiber modules and stack it with up to eight switches. The stacking bandwidth is 40 Gbps.

[specifications]

Form Factor	External
Included Qty	1
Type	Bandwidth
Value	160 Gbps
Type	Network stacking module
Form Factor	Plug-in module
Connectivity Technology	Wired
Data Transfer Rate	160 Gbps
Ports Qty	2
Features	Cisco StackWise-160 technology
Interface Provided	Qty          1 Type        Stack port
Header	Compatibility                 PC Manufacturer                Cisco Systems Packaged Quantity       1 Product Line                 Cisco Model                           StackWise stacking upgrade kit Brand                           Cisco
Cable	Connectivity Details Type        Stacking cable Connectivity Details Length        1.6 ft
Weight	3.88oz







[/specifications]

Cisco C3650-Stack-Kit Stacking Module for Converged Wired Plus Wireless Access

Cisco C3650-Stack-Kit Stacking Module is a next-generation enterprise-class standalone and stackable access-layer switch. It provides converged wired as well as wireless single platform with improved bandwidth across network.

Key Benefits of Cisco C3650-Stack-Kit Stacking Module

Cisco C3650-Stack-Kit Stacking Module is compatible with Cisco Catalyst 3650-24 and 3650-48 and has a 160 Gbps bandwidth. It is powered by the Cisco StackWise -160 technology to deliver superior performance as a standalone and stackable network switch. Standalone switch comes with a 1.6 ft. cable for easy stacking while modular switch improves wireless productivity and reduces TCO.

Cisco C3650-Stack-Kit Stacking Module can perform all the mobility agent tasks, besides mobility coordination. It also provides a rich set of security features for wired plus wireless users.

[specifications] [/specifications]A single FlexStack connection between two members is a full duplex 10Gbps connecton. Each Cisco Catalyst 2960-S member supports two FlexStack connections. Each FlexStack member can simultaneously send and receive Ethernet traffic over both stack links at line rate, effectively giving 20Gbps of stack bandwidth per member.
