[shortdesc]

650Mhz CPU, 64MB RAM, 1xEthernet, onboard 5Ghz dual chain wireless with AC, RouterOS L3

[/shortdesc]

[properties]

Properties	MikroTik RB911-5HACD-US
Description	650Mhz CPU, 64MB RAM, 1xEthernet, onboard 5Ghz dual chain wireless with AC, RouterOS L3
Product Type	Routerboard
Ports
10/100 Ethernet ports	1
Dimensions	113 x 89 mm
Number of DC inputs	1 (PoE-IN)
Max power consumption	7 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	10-30 V

[/properties][specifications]

Specifications	RB911-5HACD-US
Memory	64 MB
Flash Storage size	16 MB
CPU	QCA9531 650 MHz
CPU core count	1
OS	RouterOS level 3 license
MTBF	Approximately 100.000 hours at 25C
Temperature	-40°C to 70°C tested
IPsec hardware acceleration	Yes
Wireless Capabilities
Wireless 5 GHz Max data rate	867 Mbit/s
Wireless 5 GHz number of chains	2
Wireless 5 GHz standards	802.11a/n/ac
Wireless 5 GHz chip model	QCA9892
Wireless 5 GHz generation	Wi-Fi 5
Operating frequency	5170 - 5250 MHz 5725 - 5835 MHz
Wireless specifications
6MBit/s	Transmit (dBm): 29 Receive Sensitivity: -95
54MBit/s	Transmit (dBm): 26 Receive Sensitivity: -81
MCS0	Transmit (dBm): 29 Receive Sensitivity: -95
MCS7	Transmit (dBm): 25 Receive Sensitivity: -77
MCS0-9	Transmit (dBm): 22 Receive Sensitivity: -72
Certification & Approvals
Certification	CE, FCC, IC, EAC, ROHS
IP	IP00

[/specifications]

[accesories]

[/accesories]

The 911 Lite5 ac is upgrade for our low-cost 911 Lite5 dual model. Its a small CPE type RouterBOARD wireless router with an integrated 5Ghz dual-chain wireless card, now with added 802.11ac support. Its equipped with powerful 650MHz CPU and 64MB, great for building custom 5Ghz CPE or Backhaul units. Unit is equipped with 10/100Mbps Ethernet port. We have two versions available. RB911-5HacD-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock cannot be removed
