[shortdesc]

48 High-Speed Ports, 10/25G Support, 1G Support, Modular Design, Hot-Swappable, Enterprise-Grade Security

[/shortdesc]

[properties]

Properties	C9400-LC-48H
Description	Cisco Catalyst 9400 Series 48-Port UPOE+ 10/100/1000 (RJ-45)
Product Family	Catalyst 9400
Product Type	Line Card
Number of ports	48
Port speed	10/100/1000M
Port type	RJ-45 UPOE+ IEEE 802.3bt, IEEE, 802.3at, IEEE, 802.3af, Cisco pre-standard
Min/max ports for C9404R	48/96
Min/max ports for C9407R	48/240
Min/max ports for C9410R	48/384
Physical dimensions	Occupies one slot in Cisco Catalyst 9400 Series switches Dimensions (H x W x D): 1.6 x 14.92 x 14.57 in. (4.06 x 37.90 x 37.00 cm)
Max rated power (W)	65

[/properties][specifications]

Specifications	C9400-LC-48H
Standards	Gigabit Ethernet: IEEE 802.3z, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3bt, IEEE 802.3at, IEEE 802.3af, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3an, IEEE 802.3an
Features	● 48 ports nonblocking. ● 10/100/1000 module (RJ-45). ● Supported on Cisco IOS XE Software Release 16.12.1 or later. ● Cisco UPOE+ is enabled, capable of up to 90W on all ports in the line card. ● Energy Efficient Ethernet 802.3az. ● IEEE 802.3bt/af/at and Cisco pre-standard PoE. ● IEEE 802.1AE (MACsec-256) capability in hardware. ● Layer 2 to Layer 4 Jumbo Frame support up to 9216 bytes. ● Ideal for campus and branch applications requiring enhanced performance for large file transfers and network backups.
Bandwidth per slot by chassis
C9400 Supervisor Engine-1 (C9400-SUP-1)	Bandwidth per slot Chassis C9404R: 80 Gbps Chassis C9407R: 80 Gbps Chassis C9410R: 80 Gbps Oversubscription: 1:1
C9400 Supervisor Engine-1XL (C9400-SUP-1XL)	Bandwidth per slot Chassis C9404R: 240 Gbps Chassis C9407R: 120 Gbps Chassis C9410R: 80 Gbps Oversubscription: 1:1
C9400 Supervisor Engine-1XL-Y (C9400-SUP-1XL-Y)	Bandwidth per slot Chassis C9404R: 240 Gbps Chassis C9407R: 120 Gbps Chassis C9410R: 80 Gbps Oversubscription: 1:1
C9400 Supervisor Engine-2XL (C9400X-SUP-2XL)	Bandwidth per slot Chassis C9404R: 480 Gbps Chassis C9407R: 480 Gbps Chassis C9410R: 480 Gbps Oversubscription: 1:1
C9400 Supervisor Engine-2 (C9400X-SUP-2)	Bandwidth per slot Chassis C9404R: 240 Gbps Chassis C9407R: 240 Gbps Chassis C9410R: 240 Gbps Oversubscription: 1:1
Operating temperature	◦ 23° to 113°F (-5 to +45°C), up to 6,000 feet (1800 m) ◦ 23° to 104°F (-5 to +40°C), up to 10,000 feet (3000 m)
Relative humidity	10 to 95%, noncondensing
Rated MTBF (hours)	874,14
Safety conditions	Fiber optic lasers: Class 1 laser products
Safety certifications	● UL 60950-1 ● CAN/CSA-C222.2 No. 60950-1 ● EN 60950-1 ● IEC 60950-1 ● AS/NZS 60950.1 ● IEEE 802.3
Electromagnetic emissions certifications	● 47 CFR Part 15 ● CISPR22 Class A ● EN 300 386 V1.6.1 ● EN 55022 Class A ● EN 55032 Class A ● CISPR 32 Class A ● EN61000-3-2 ● EN61000-3-3 ● ICES-003 Class A ● TCVN 7189 Class A ● V-3 Class A ● CISPR24 ● EN 300 386 ● EN55024 ● TCVN 7317
ROHS compliance	ROHS5

[/specifications]

Cisco Catalyst C9400-LC-48H Line Card

The Cisco Catalyst C9400-LC-48H Line Card is a high-performance module designed for the Cisco Catalyst 9400 Series modular switches, providing advanced connectivity and power delivery for enterprise networks. This line card features 48 ports that support both Multigigabit Ethernet and UPOE+ (Universal Power Over Ethernet Plus), offering robust and scalable connectivity for a wide range of devices, including wireless access points, IP phones, and more. The C9400-LC-48H is engineered to meet the evolving needs of modern enterprise environments, delivering flexibility, energy efficiency, and the power needed to support growing network demands.

Key Features:

48 x Multigigabit Ethernet Ports with UPOE+ Support: Delivers high-speed connectivity and up to 60W of power per port, supporting various high-demand devices.
Advanced Power Delivery: Supports Universal Power Over Ethernet Plus (UPOE+), providing sufficient power for devices such as IP cameras, phones, and high-performance access points.
Scalable Architecture: Seamlessly integrates with the Cisco Catalyst 9400 Series chassis, allowing for easy network expansion and future growth.
Enterprise-Grade Security: Includes advanced security features to protect your network from threats and unauthorized access.
Energy Efficient: Designed to reduce power consumption while maintaining high performance, contributing to lower operational costs.

Technical Overview:

Recommended for: Large enterprise networks requiring scalable, high-performance connectivity with advanced power options.
Ports: 48 x Multigigabit Ethernet ports with UPOE+ support (up to 60W per port).
Compatibility: Fully compatible with Cisco Catalyst 9400 Series modular switches.
Management: Managed through Cisco DNA Center and other Cisco network management tools.
Security: Integrated with advanced security features, including network segmentation and access control.

You can check the related tab for the C9400-LC-48H datasheet.
