Cisco AIR-AP2802I-B-K9 Access Point Technical Specifications
Software | Cisco Unified Wireless Network Software Release 8.2.111.0 or later |
Supported Wireless LAN Controllers | Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco Flex 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco Virtual Wireless Controller Cisco Catalyst 3850 Series Switches, Cisco Catalyst 3650 Series SwitchesCisco Mobility Express |
802.11n Version 2.0 (and related) Capabilities | 4x4 MIMO with three spatial streams Maximal ratio combining (MRC) 802.11n and 802.11a/g beamforming 20- and 40-MHz channels PHY data rates up to 450 Mbps (40 MHz with 5 GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)802.11 dynamic frequency selection (DFS) Cyclic shift diversity (CSD) support |
802.11ac Wave 1 Capabilities | 4x4 MIMO with three spatial streams MRC802.11ac beamforming 20-, 40-, and 80-MHz channels PHY data rates up to 1.3 Gbps (80 MHz in 5 GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)802.11 DFSCSD support |
802.11ac Wave 2 Capabilities | 802.11ac Wave 2 capabilities 4x4 MU-MIMO with three spatial streams MRC802.11ac beamforming 20-, 40-, 80, 160-MHz channels PHY data rates up to 5.2 Gbps Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) 802.11 DFSCSD support |
Integrated Antenna | Integrated Antenna Flexible radio (either 2.4 GHz or 5 GHz) 2.4 GHz, gain 4 dBi, internal antenna, omnidirectional in azimuth 5 GHz, gain 6 dBi, internal directional antenna, elevation plane beamwidth 90 Dedicated 5-GHz radio 5 GHz, gain 5 dBi, internal antenna, omnidirectional in azimuth |
Interfaces | 2802I/E
Management console port (RJ-45)USB 2.0 (enabled via future software) |
Indicators | Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors |
Dimensions (W x L x H) | Access point (without mounting brackets): 2802I: 8.66" x 8.68" x 2.17" |
Weight | 3.53 lb (1.6 kg) |
Input Power Requirements | 802.3at PoE+, Cisco Universal PoE (Cisco UPOE) 802.3 at power injector (AIR-PWRINJ6) |
Power Draw |
26W at the PSE with all features enabled except for the USB 2.0 port. 30W at the PSE with the USB 2.0 port enabled |
Environmental |
Nonoperating (storage) temperature: -22 to 158F (-30 to 70C) Nonoperating (storage) altitude test: 25C, 15,000 ft. Operating temperature: 32 to 104F (0 to 40C) Operating humidity: 10% to 90% (noncondensing) Operating altitude test: 40C, 9843 ft |
System Memory | 1024 MB DRAM256 MB flash |
Cisco AIR-AP2802I-B-K9 Access Point is one of the Cisco Aironet 2800 Series Access Points. It provides internal antenna and B regulatory domain. This 2800 series access point features new 802.11ac Wave 2 standard.
Cisco AIR-AP2802I-B-K9 Access Point is the right choice for large enterprise organizations that rely on Wi-Fi for customer engagement. This 2800 series access point is intelligent enough to make decisions based on end-device activities and usage.
Manufacturer Part Number | AIR-AP2802I-B-K9 |
Frequency Band and 20-MHz Operating Channels | B (B regulatory domain): - 2.412 to 2.462 GHz; 11 channels - 5.180 to 5.320 GHz; 8 channels - 5.500 to 5.720 GHz; 12 channels - 5.745 to 5.825 GHz; 5 channels |
Antenna | Internal Antenna |
Features | - 4x4 MU-MIMO with three spatial streams - MRC - 802.11ac Beamforming - 20-, 40-, 80, 160-MHz channels - PHY data rates up to 5.2 Gbps - Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) - 802.11 DFS - CSD support |
Interfaces | - 2 x 100/1000BASE-T autosensing (RJ-45) - Management console port (RJ-45) - USB 2.0 (enabled via future software) |
System Memory | - 1024 MB DRAM - 256 MB flash |
Dimensions (W x L x H) | 8.66 x 8.68 x 2.17 in. |
Net Weight | 3.53 lb (1.6 kg) |
Image below shows Ports and Connectors of the 2802I Model.
Type | Wireless access point |
Form Factor | External |
Connectivity Technology | Wireless |
Data Transfer Rate | 1.3 Gbps |
Data Link Protocol | IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Compliant Standards | IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at |
Features | 2T2R MIMO technology, Auto-sensing per device, Beamforming technology, CleanAir technology, ClientLink technology, Cyclic shift diversity (CSD), DFS support, Dynamic path selection (DPS), MAC address authentication, MAC address filtering, Maximum Ratio Combining (MRC), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Radio resource management (RRM), Reset button, VPN passthrough |
Network Transport Protocol | IPSec, L2TP |
Wireless Protocol | 802.11a/b/g/n/ac Wave 2 |
Power Over Ethernet (PoE) | UPOE |
Wi-Fi Bands | 2.4 GHz, 5 GHz |
Qty | 4 |
WAN DMZ | WAN |
Type | Management |
Connector Type | SFP (mini-GBIC) |
Compliant Standards | ANSI / IEEE 587 C62.41, ARIB STD-T66, ARIB STD-T71, AS/NZS 4268.2003, EN 300 328, EN 301 489-1, EN 301 893, EN 60068-2-5, EN 60950, EN 60950 Second Edition, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, FCC OET Bulletin 65c, FCC Part 15.107, FCC Part 15.109, FCC Part 15.247, FCC Part 15.407, IEC 60529 IP67, IEC 60950 Second Edition, MIL-STD-810, NEMA 250-2008, NEMA Type 4X, RSS-102, RSS-210, UL 60950 Second Edition |
Authentication Method | Extensible Authentication Protocol (EAP), X.509 certificates |
Encryption Algorithm | AES, LEAP, PEAP, TLS, TTLS, WPA, WPA2 |
Antenna Form Factor | External detachable |
Min Operating Temperature | -40 F |
Max Operating Temperature | 131 F |
Compatibility | PC |
Country Kits | United States |
Manufacturer | Cisco Systems |
Packaged Quantity | 1 |
Product Line | Cisco Aironet |
Model | 1562E |
Brand | Cisco |
Type | Spatial streams |
Value | 2 |
Width | 6.7 in |
Depth | 3.9 in |
Height | 9 in |
Weight | 5.51 lbs |
Ruggedized Design | Outdoor |
Cisco AIR-AP1562E-B-K9 Access Point can be a perfect choice for enterprise-class and service-class network operators.
Cisco AIR-AP1562E-B-K9 Access Point is high-performing outdoor access point that provides high throughput over a large area with pervasive coverage.
Description | 802.11ac Wave 2 Low-Profile Outdoor AP, External Antenna, B Regulatory Domain |
Features | 2 x 2 MIMO with two spatial streamsMulti- and single-user MIMOMaximal ratio combining (MRC)802.11ac beamforming (transmit beamforming)20-, 40-, and 80-MHz channelsPHY data rates up to 1.3 Gbps (80 MHz in 5 GHz)Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)802.11 dynamic frequency selection (DFS)Cyclic-shift-diversity (CSD) support |
Interfaces | WAN port 10/100/1000BASE-TEthernet,autosensing (RJ-45), PoE inSFP port (fiber or electrical)Management console port (RJ-45)Multicolor LEDDC power inputReset button |
Dimensions (L x W x H) | 9.0 x 6.8 x 3.9 in. (22.9 x 17.1 x 9.8 cm) |
Weight | 5.6 lb (2.5 kg) |
Authentication and security | Advanced Encryption Standard (AES) for Wi-Fi Protected Access 2 (WPA2) 802.1X, RADIUS authentication, authorization, and accounting (AAA) 802.11r 802.11i |
Software | Cisco Unified Wireless Network Software with AireOS Wireless Controllers Release 8.5 or later Cisco Mobility Express |
Supported WLAN Controllers | Cisco 2500 Series Wireless Controllers, Cisco 3500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco Flex 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco 9800 series Wireless Controllers, Cisco Mobility Express |
Maximum clients | Maximum number of associated wireless clients: 200 per Wi-Fi radio, in total 400 clients per access point |
802.11ac | 2x2 single-user/multiuser MIMO with two spatial streams Maximal ratio combining (MRC) 20-, 40- and 80-MHz channels PHY data rates up to 866.7 Mbps (80 MHz on 5 GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Rx) 802.11 Dynamic Frequency Selection (DFS) Cyclic shift diversity (CSD) support |
Ethernet ports | Authentication with 802.1X or MAC filtered Dynamic VLAN or per port Traffic locally switched or tunneled back to wireless LAN controller |
Bluetooth (future availability) | Integrated Bluetooth 4.1 (including BLE) radio Maximum transmit power: 4 dBm Antenna gain: 2 dBi |
Maximum number of non-overlapping channels | A (A regulatory domain): 2.412 to 2.462 GHz; 11 channels 5.180 to 5.320 GHz; 8 channels 5.500 to 5.700 GHz; 8 channels (excludes 5.600 to 5.640 GHz) 5.745 to 5.825 GHz; 5 channels B (B regulatory domain): 2.412 to 2.462 GHz; 11 channels 5.180 to 5.320 GHz; 8 channels 5.500 to 5.720 GHz; 12 channels 5.745 to 5.825 GHz; 5 channels C (C regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.745 to 5.825 GHz; 5 channels D (D regulatory domain): 2.412 to 2.462 GHz; 11 channels 5.180 to 5.320 GHz; 8 channels 5.745 to 5.825 GHz; 5 channels E (E regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.180 to 5.320 GHz; 8 channels 5.500 to 5.700 GHz; 8 channels (excludes 5.600 to 5.640 GHz) F (F regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.745 to 5.805 GHz; 4 channels G (G regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.745 to 5.865 GHz; 7 channels H (H regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.180 to 5.320 GHz; 8 channels 5.745 to 5.825 GHz; 5 channels I (I regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.180 to 5.320 GHz; 8 channels K (K regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.180 to 5.320 GHz; 8 channels 5.500 to 5.620 GHz; 7 channels 5.745 to 5.805 GHz; 4 channels N (N regulatory domain): 2.412 to 2.462 GHz; 11 channels 5.180 to 5.320 GHz; 8 channels 5.745 to 5.825 GHz; 5 channels Q (Q regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.180 to 5.320 GHz; 8 channels 5.500 to 5.700 GHz; 11 channels R (R regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.180 to 5.320 GHz; 8 channels 5.660 to 5.700 GHz; 3 channels 5.745 to 5.805 GHz; 4 channels S (S regulatory domain): 2.412 to 2.472 GHz; 13 channels 5.180 to 5.320 GHz; 8 channels 5.500 to 5.700 GHz; 11 channels 5.745 to 5.825 GHz; 5 channels T (T regulatory domain): 2.412 to 2.462 GHz; 11 channels 5.280 to 5.320 GHz; 3 channels 5.500 to 5.700 GHz; 8 channels (excludes 5.600 to 5.640 GHz) 5.745 to 5.825 GHz; 5 channels Z (Z regulatory domain): 2.412 to 2.462 GHz; 11 channels 5.180 to 5.320 GHz; 8 channels 5.500 to 5.700 GHz; 8 channels (excludes 5.600 to 5.640 GHz) 5.745 to 5.825 GHz; 5 channels |
Available transmit power settings | 2.4 GHz 20 dBm (100 mW) 17 dBm (50 mW) 14 dBm (25 mW) 11 dBm (12.5 mW) 8 dBm (6.25 mW) 5 dBm (3.13 mW) 2 dBm (1.56 mW) -1 dBm (0.78 mW) 5 GHz 20 dBm (100 mW) 17 dBm (50 mW) 14 dBm (25 mW) 11 dBm (12.5 mW) 8 dBm (6.25 mW) 5 dBm (3.13 mW) 2 dBm (1.56 mW) -1 dBm (0.78mW) |
Integrated antennas | 2.4 GHz, gain 2 dBi 5 GHz, gain 4 dBi |
Interfaces | 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) Management console port (RJ-45) |
Indicators | Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors |
Dimensions (W x L x H) | Access point (without mounting bracket): 6 x 6 x 1.3 in (150.8 x 150.8 x 33 mm) |
Weight | Access point without mounting bracket or any other accessories: 14 oz (400 g) |
Environmental | Operating Temperature: 32 to 104 F (0 to 40 C) Humidity: 10% to 90% (noncondensing) Max. altitude: 9843 ft (3000 m) @ 40 C Nonoperating (storage and transportation) Temperature: -22 to 158 F (-30 to 70 C) Humidity: 10% to 90% (noncondensing) Max. altitude: 15,000 ft (4500 m) @ 25 C |
System | 1 GB DRAM 256 MB flash 710 MHz quad core |
Input power requirements | Power injector: AIR-PWRINJ5= or AIR-PWRINJ6= |
Powering options | 802.3af/at Ethernet switch Optional Cisco power injectors (AIR-PWRINJ5=, AIR-PWRINJ6=) |
Power draw | 8.3W (maximum, on PoE) |
Physical security | Torx security screw, included with the access point |
Mounting | Included with the access point: mounting bracket AIR-AP-BRACKET8 |
Accessories | Mounting bracket: AIR-AP-BRACKET8= (available as spare) Physical security kit: AIR-SEC-50= (sold separately), with 50 pcs. Security screws used to secure access point onto wall-mounting bracket, 50 pcs. RJ-45 caps and 2 pcs. unlock keys used to block physical access to Ethernet ports |
The Cisco Aironet 1815i delivers industry-leading wireless performance with support for the latest Wi-Fi standard, IEEE's 802.11ac Wave 2. It also meets the growing requirements of wireless networks by delivering a better user experience. The 1815i extends support to a generation of Wi-Fi clients, such as smartphones, tablets, and high-performance laptops that have integrated 802.11ac Wave 1 or Wave 2 support.
Feature | Benefit |
MU-MIMO | Multiuser (MU) multiple-input multiple-output (MU-MIMO) allows transmission of data to multiple 802.11ac Wave 2-capable clients simultaneously to improve the client experience. Prior to MU-MIMO, 802.11n and 802.11ac Wave 1 access points could transmit data to only one client at a time, typically referred to as single-user MIMO (SU-MIMO). 802.11ac Wave 2 with 2x2:2 MIMO technology uses two spatial streams when operating in SU-MIMO or MU-MIMO mode, offering 867-Mbps rates for more capacity and reliability than competing access points. |
Cisco Mobility Express solution | Flexible deployment through the Mobility Express Solution is ideal for small to medium-sized deployments. Easy setup allows the 1815i to be deployed on networks without a physical controller. |
Integrated Bluetooth 4.1 | Integrated Bluetooth low-energy (BLE) 4.1 radio for location and asset tracking (future availability). |
Description | 802.11ac Wave 2 Access Point, 4x4:4, internal- Ant, B Regulatory Domain |
Software | Cisco Unified Wireless Network Software Release with AireOS wireless controllers: 8.1 MR1 or later for the Cisco Aironet 1850 Series Access Points |
Regulatory Domain | B (B regulatory domain): - 2.412 to 2.462 GHz; 3 channels - 5.180 to 5.320 GHz; 8 channels - 5.500 to 5.720 GHz; 12 channels - 5.745 to 5.825 GHz; 5 channels |
Deployment modes | Centralized local, Standalone, Sniffer, Cisco FlexConnect, Monitor, OfficeExtend, Mesh |
Supported wireless LAN controllers | Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco Flex 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco 5760 Series Wireless Controllers, Cisco Catalyst 3650/3850 Series switch with integrated controller Cisco Mobility Express |
802.11n version 2.0 (and related) capabilities | 4x4 MIMO with four spatial streams Maximal ratio combining (MRC) 20- and 40-MHz channels PHY data rates up to 600 Mbps (40 MHz with 5 GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) 802.11 dynamic frequency selection (DFS) Cyclic shift diversity (CSD) support |
802.11ac Wave 1 and 2 capabilities | 4x4 MIMO with four spatial streams, single-user MIMO 4x4 MIMO with three spatial streams, multiuser MIMO MRC 802.11ac beamforming (transmit beamforming) 20-, 40-, and 80-MHz channels PHY data rates up to 1.7 Gbps (80 MHz in 5 GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) 802.11 DFS CSD support Rogue device detection |
Integrated antenna | 2.4 GHz, gain 3 dBi, internal omni, horizontal beamwidth 360 5 GHz, gain 5 dBi, internal omni, horizontal beamwidth 360 |
Interfaces | 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) 1 x 10/100/1000BASE-T autosensing (RJ-45), AUX (used for Link Aggregation) Management console port (RJ-45) USB 2.0 (enabled via future software) |
Indicators | Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors |
Dimensions (W x L x H) |
Access point (without mounting bracket): 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
Weight | 3.12 lb (1.41 kg) |
Environmental | Cisco Aironet 1850i Nonoperating (storage) temperature: -22 to 158 F (-30 to 70 C) Nonoperating (storage) altitude test: 25 C, 15,000 ft. Operating temperature: 32 to 104 F (0 to 40 C) Operating humidity: 10% to 90% (noncondensing) Operating altitude test: 40 C, 9843 ft. |
System memory | 1 GB DRAM 256 MB flash |
Input power requirements | AP1850: 44 to 57 VDC Power supply and power injector: 100 to 240 VAC; 50 to 60 Hz |
Power draw | 20.9W Note: When deployed using a Power over Ethernet (PoE) specification, the power drawn from the power sourcing equipment will be higher by some amount, depending on the length of the interconnecting cable. |
Powering options | 802.3at Enhanced PoE Cisco power injector, AIR-PWRINJ4= Cisco local power supply, AIR-PWR-C= Cisco power injector, AIR-PWRINJ5= (Note:this injector supports 802.3af only) 802.3af Note: If 802.3af PoE is the source of power, (1) the 1852e 2.4-GHz radio will shift to 2x3 from 3x4, (2) The USB port and AUX Ethernet port are disabled on both the 1852i and 1852e. |
Cisco Aironet 1852I, with IEEE's 802.11ac 4x4 Wave 2 support, offers a data rate of up to 1.7Gbps on a 5-GHz radio, enabling a total aggregated dual-radio data rate of up to 2Gbps. Ideal for small and medium-sized networks, the Aironet 1852I delivers industry-leading performance for highly secure and reliable wireless connections and provides a superior mobility end-user experience.
Description | 802.11ac Wave 2 Access Point, 4x4:4, Internal-Ant, B Regulatory Domain |
Features | - 4x4 MIMO with four spatial streams, single-user MIMO - 4x4 MIMO with three spatial streams, multiuser MIMO - MRC - 802.11ac beamforming (transmit beamforming) - 20-, 40-, and 80-MHz channels - PHY data rates up to 1.7 Gbps (80 MHz in 5 GHz) - Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) - 802.11 DFS - CSD support |
Regulatory Domain | B (B regulatory domain): - 2.412 to 2.462 GHz; 3 channels - 5.180 to 5.320 GHz; 8 channels - 5.500 to 5.720 GHz; 12 channels - 5.745 to 5.825 GHz; 5 channels |
Antenna | Internal Antenna |
Interfaces | - 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) - 1 x 10/100/1000BASE-T autosensing (RJ-45), AUX (used for Link Aggregation) - Management console port (RJ-45) - USB 2.0 (enabled via future software) |
Dimensions (W x L x H) | 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
Weight | 3.12 lb (1.41 kg) |
Software | Cisco Unified Wireless Network Software Release with AireOS wireless controllers: 8.1 MR1 or later for the Cisco Aironet 1850 Series Access Points |
Regulatory Domain | B (B regulatory domain): - 2.412 to 2.462 GHz; 3 channels - 5.180 to 5.320 GHz; 8 channels - 5.500 to 5.720 GHz; 12 channels - 5.745 to 5.825 GHz; 5 channels |
Deployment modes | Centralized local, Standalone, Sniffer, Cisco FlexConnect, Monitor, OfficeExtend, Mesh |
Supported wireless LAN controllers | Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco Flex 7500 Series Wireless Controllers, Cisco 8500 Serie |
