AXIS S2224 Mk II Rack Appliance 12 TB (02810-004)

AXIS S2224 Mk II Rack Appliance 12 TB (02810-004)

Name: AXIS S2224 Mk II Rack Appliance 12 TB (02810-004)
Brand: Axis
Price: 5590.0 USD
Availability: InStock

Part Number: 02810-004

Technical Details

All-in-one rack-mounted appliance with integrated PoE switch, 24 Axis Camera Station licenses tied to hardware, Intel® i3 CPU, RAID-supported storage, and secure Windows 11 IoT OS.

$5,590.00

Ask an Expert

sales@networkdevicesinc.com

1-201-559-1474

Availability: In Stock

Condition: Brand New Sealed

Free Shipping on Orders $100+Arrives in 1-6 business days within the U.S.

International DeliveryWorldwide shipping in 7–15 business days

30 Days Return

12 Months Warranty Support

sales@networkdevicesinc.com

1-201-559-1474

The AXIS S2224 Mk II Rack Appliance is a fully integrated all-in-one NVR built for professional-scale video surveillance. With 24 dedicated AXIS Camera Station licenses, PoE switch power distribution, 12 TB surveillance-grade storage, and RAID options, it delivers reliable retention and high-performance multi-stream handling. Designed for enterprise environments, this 1U chassis integrates cleanly into rack cabinets and supports scalable multi-site deployments.

With Windows 11 IoT Enterprise LTSC, a TPM-secured OS, secure boot, and signed firmware, this platform provides enterprise-class cybersecurity transparency and device integrity. The hardware configuration is optimized for simultaneous multi-monitor setups, remote and local client streaming, and large-scale continuous recording operations.

Professional-grade secure NVR with integrated PoE power and expansion capability

Integrated 24-port PoE switch enables direct camera powering without external switches.
Supports up to 384 Mbps total recording throughput for high-resolution systems.
RAID-supported storage functionality ensures service continuity and data safety.
FIPS 140-2 Level 2 TPM and secure boot prevent unauthorized firmware or OS manipulation.
Validated for multi-monitor and 8K/4K live view performance.
Qualified for up to 24 video channels and 48 doors simultaneously.

Ideal Use Cases

Large multi-camera enterprise surveillance deployments
Government or critical-infrastructure security environments
Retail chains and warehouse monitoring systems
Schools, hospitals, universities, and facility campuses
Video-intensive monitoring with multi-monitor operator stations

Technical Specifications Summary

CPU: Intel® Core™ i3
RAM: 16 GB DDR5
Storage: 12 TB surveillance HDD (2×6 TB), 4 drive bays total
RAID: 0, 1, 10 supported
PoE Switch: 24 ports, 260 W total budget
Operating Temperature: 0–40 °C (32–104 °F)
Dimensions: 476 × 440 × 45 mm (18.7 × 17.3 × 1.8 in)
Weight: 11 kg (24.3 lb)
Security: TPM 2.0, secure boot, signed firmware

Upgrade Your Operations

Deploy enterprise-class recording performance with industry-leading cybersecurity and PoE integration.

Properties

Model	AXIS S2224 Mk II Rack Appliance (02810-004)
Product Type	1U rack network video recorder (NVR) with integrated PoE switch
Processor	Intel® Core™ i3
Memory	16 GB DDR5 (2×8 GB)
Operating System	Microsoft® Windows® 11 IoT Enterprise LTSC 2024
Storage Capacity	12 TB out-of-the-box (2×6 TB), Surveillance-Class HDD
HDD Bays	Surveillance Class HDD Total HDD slot: 4 Free HDD slot: 2
RAID Support	Levels 0, 1, 10
Switch Ports	24× PoE RJ45 (1 Gbps), IEEE 802.3at Class 4
PoE Budget	260 W total power budget
Power Input	100–240 V AC, 6.5–2.5 A, 50/60 Hz
Operating Temperature	0 to 40 °C (32 to 104 °F)
Storage Temperature	-40 to 65 °C (-40 to 149 °F)
Humidity	10–90% RH (non-condensing)
Dimensions	476 × 440 × 45 mm (18.7 × 17.3 × 1.8 in), 1U rack
Weight	11 kg (24.3 lb)
Certifications	UL/cUL, BIS, CE, KC, VCCI, RCM, BSMI, FCC, NOM
Cybersecurity Hardware	TPM 2.0 – FIPS 140-2 Level 2 certified

Specifications

Licensing	24 AXIS Camera Station Pro Core Device NVR licenses included and tied to the hardware
Scalability	Qualified for up to 24 video channels and 48 doors (up to 1,000 doors with access control only) with up to 384 Mbps recording
System Expansion	Can expand using AXIS S30 Recorder Series
Network Ports – Rear Switch	24× PoE RJ45 1 Gbps, 1× SFP 1 Gbps, 1× RJ45 1 Gbps
Network Ports – Server	1× RJ45 1 Gbps
Peripheral Connections	Front: 2× USB 3.2, 1× universal audio jack; Rear: 2× USB 2.0, 2× HDMI 2.1
Graphics	Intel® UHD Graphics
Video Streaming – Windows Client	Up to one 8K @ 20 fps, or 4K @ 30 fps, with split-view limitations as specified in datasheet
Video Streaming – Web Client	Up to one 8K @ 30 fps or 4K @ 30 fps, with split-view configurations
Power Consumption	Typical: 110 W; Maximum: 130 W (excluding PoE load)
Operating System Drive	256 GB SSD (with OS recovery enabled)
Security Features	FIPS-certified TPM, secure boot, signed switch firmware, SBOM transparency
Supply Chain Compliance	TAA compliant

Accessories

Included Accessories	Rack rails, power cord
Optional Accessories	Axis 4 TB and 6 TB surveillance-grade HDDs, Axis desktop terminals, Axis Ethernet surge protector
