MikroTik SXTR&EP06-A SXT LTE6 kit-US 9 dBi 60 degrees LTE Antenna

MikroTik SXTR&EP06-A SXT LTE6 kit-US 9 dBi 60 degrees LTE Antenna

Name: MikroTik SXTR&EP06-A SXT LTE6 kit-US 9 dBi 60 degrees LTE Antenna
Brand: Mikrotik
SKU: SXTR&EP06-A-NEW
Price: 150.00 USD
Availability: InStock

Part Number: SXTR-EP06-A

Technical Details

Access Point Antenna MikroTik SXTR&EP06-A SXT LTE6 kit-US 9 dBi 60 degrees LTE Antenna

$150.00

Ask an Expert

sales@networkdevicesinc.com

1-201-559-1474

Availability: In Stock

Condition: Brand New Sealed

Free Shipping on Orders $100+Arrives in 1-6 business days within the U.S.

International DeliveryWorldwide shipping in 7–15 business days

30 Days Return

12 Months Warranty Support

sales@networkdevicesinc.com

1-201-559-1474

MikroTik SXTR&EP06-A Access Point Antenna

The SXTR&EP06-A kit is designed for deployment in remote areas with cellular coverage. It is housed in a durable and weatherproof housing, and the device features two Micro-SIM slots for redundancy, offering increased flexibility in mobile network coverage. Furthermore, the LTE Category 6 modem supports carrier aggregation, enabling the SXT to exploit multiple LTE bands concurrently, which is particularly advantageous in densely populated mobile user environments. Additionally, the device has two Ethernet ports and PoE functionality, with PoE-in on Ether1 and PoE-out on Ether2.

Quick Specs:

2x 10/100 Ethernet Ports
PoE-out: Passive PoE up to 57V
PoE-out ports: Ether2
QCA9531, 1 core, 650 MHz CPU

Please see the related tabs for the SXTR&EP06-A datasheet and compatible accessories.

Properties

Properties	SXTR&EP06-A
Description	Mikrotik SXT LTE6 kit-US with with 9dBi 60 degrees LTE directional antenna, 650MHz CPU, 64MB RAM, 2xLAN (one with PoE-OUT), LTE CAT6 modem for USA bands 2/4/5/7/12/13/25/26/29/30/66, Dual-SIM, RouterO
Product Type	Access Point Antenna

Specifications

Specifications	SXTR&EP06-A
Architecture	MIPSBE
CPU	QCA9531
CPU core count	1
CPU nominal frequency	650 MHz
Switch chip model	QCA9531
RouterOS license	3
Operating System	RouterOS
Size of RAM	64 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-40°C to 60°C
Suggested price	$169.00
Powering
Number of DC inputs	1 (PoE-IN)
Max power consumption	21 W
Max power consumption without attachments	5 W
Cooling type	Passive
PoE in	802.3af/at
PoE in input Voltage	12-57 V
PoE-out
PoE-out ports	Ether2
PoE out	Passive PoE up to 57V
Max out per port output (input 18-30 V)	600 mA
Max out per port output (input 30-57 V)	400 mA
Max total out (A)	600 mA
Total output current	600mA
Mobile
3G Category	R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
3G bands	2 (1900MHz) / 5 (850MHz) / 4 (1700MHz)
LTE Category	6 (300Mbit/s Downlink, 50Mbit/s Uplink)
MIMO DL	2x2
LTE FDD bands	2 (1900MHz) / 4 (1700MHz) / 5 (850MHz) / 7 (2600MHz) / 12 (700MHz) / 13 (700 MHz) / 25 (1900MHz) / 26 (850MHz) / 30 (2300 MHz) / 66 (1700MHz) / 29 (700 MHz)
TAC	1611100
Ethernet
10/100 Ethernet ports	2
Peripherals
Number of SIM slots	2 Modem (Micro SIM)
MiniPCI-e slots	1
Other
Mode button	Yes
