FORTINET FAP-223E-A ACCESS POINT

Part No:	FAP-223E-A
Detail:	Indoor Wireless AP - Dual radio (802.11 b/g/n and 802.11 a/n/ac Wave 2, 2x2 MU-MIMO), external antennas included, 1 x 10/100/1000 RJ45 port, BT / BLE. Ceiling/wall mount kit included.For power order: 802.3af PoE injector GPI-115 or AC adapter SP-FAP200-PA. Region Code A
List Price:	~~US$240.00~~
Price:	$133.00
You Save:	$107.00 (45% OFF)
Condition:	Brand New Sealed
Availability:	IN STOCK
Shipping:	FREE SHIPPING for all U.S orders over $100. Please call us at 201-559-1474, fill out the contact form, or chat with a live agent for other shipping methods.
Tax:	$0.00 Tax Outside NJ, TX, FL and PA
Quantity:	+ -

Description
Properties
Specifications
Accessories
Shipping

Description

Fortinet FAP-223E-A Access Point

The FortiAP 223E represents a type of 802.11ac Wave 2 access point designed for medium-density usage. This access point, classified as Enterprise-grade, is well-suited for environments with moderate user density, such as offices or classrooms, and offers a Performance Throughput of up to 867 Mbps. The FortiAP-223E is equipped with Beamforming Technology, which directs wireless signals towards connected devices, thereby ensuring a robust and reliable connection across the designated area.

Quick Specs:

11ac Wave 2
1x 10/100/1000 Base-T RJ45
Kensington Lock
Number of Antennas: 4 External + 1 Internal BLE

Please see the related tabs for the FAP-223E-A datasheet and compatible accessories.

Accessories

Mounting Options	Ceiling, T-Rail, and Wall
Included Accessories	Mount kit for Ceiling, T-Rail and Wall, 4 dipole antennas
Power Supply	SP-FAP200-PA-XX, GPI-115, or GPI-130

Specifications

Advanced 802.11 Features	802.11ac Wave 2 MUMIMO Transmit Beam Forming (TxBF)Low-Density Parity Check (LDPC) Encoding Maximum Likelihood Demodulation (MLD) Maximum Ratio Combining (MRC)A-MPDU and A-MSDU Packet Aggregation MIMO Power Save Short Guard Interval
Dimensions in.	6.3 x 6.3 x 1.85
Power Consumption (Max)	12.36 W
Operating Temperature	-4°–113°F (-20°–45°C
IEEE Standards	802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11w, 802.11ac, 802.1Q, 802.1X, 802.3af, 802.3az
Certifications	Wi-Fi Alliance Certified
Certifications	DFS:FCC, IC, CE, Japan, Taiwan, Korea

Properties

Properties	FAP-223E-A
Description	Indoor Wireless AP - Dual radio (802.11 b/g/n and 802.11 a/n/ac Wave 2, 2x2 MU-MIMO), external antennas included, 1 x 10/100/1000 RJ45 port, BT / BLE. Ceiling/wall mount kit included. For power order 802.3af PoE injector GPI-115 or AC adapter SP-FAP200-PA.
Product Family	Fortinet Indoor Wireless AP
Product Type	Access Points
Hardware Type	Indoor AP
Number of Radios	2 + 1 BLE
Number of Antennas	4 External + 1 Internal BLE
Antenna Type and Peak Gain	Dipole: 4 dBi for 2.4 GHz, 5 dBi for 5 GHz
Frequency Bands (GHz)*	2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850
Radio 1 Capabilities	2.4 GHz b/g/n (2x2:2 stream) 20/40 MHz (256 QAM)
Radio 2 Capabilities	5 GHz a/n/ac (2x2:2 stream) 20/40/80 MHz (256 QAM)
Radio 3 Capabilities	-
Maximum Data Rate	Radio 1: up to 400 Mbps Radio 2: up to 867 Mbps
Bluetooth Low Energy Radio	Bluetooth scanning and iBeacon advertisement @ 4 dBm max TX power
Interfaces	1x 10/100/1000 Base-T RJ45
Power over Ethernet (PoE)	IEEE 802.3af
Simultaneous SSIDs	Up to 16 (14 if background scanning enabled)
EAP Type(s)	EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST
User/Device Authentication	WPA™, WPA2™, and WPA3™ with 802.1x or preshared key, WEP, Web Captive Portal, MAC blocklist & allowlist
Maximum Tx Power	2.4 GHz: 23 dBm / 200 mW (2 chains combined)* 5 GHz: 24 dBm / 251 mW (2 chains combined)*
Per Radio Client Capacity	Up to 512
Cellular Co-existence	Yes
