Fortinet FG-40F-BDL-950-12 Firewall

Name: Fortinet FG-40F-BDL-950-12 Firewall
Brand: Fortinet
Price: 788.0 USD
Availability: InStock

Part Number: FG-40F-BDL-950-12

Technical Details

Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP), 1Yr Bundle

$927.00

$788.00

15% OFF

You Save: $139.00

Net 30 or as low as $/month

Apply Now

Ask an Expert

sales@networkdevicesinc.com

1-201-559-1474

Availability: Special Order

Condition: Brand New Sealed

License: Included

Free Shipping on Orders $100+Arrives in 1-6 business days within the U.S.

International DeliveryWorldwide shipping in 7–15 business days

30 Days Return

12 Months Warranty Support

sales@networkdevicesinc.com

1-201-559-1474

Fortinet FG-40F-BDL-950-12 Firewall

The Fortinet FG-40F-BDL-950-12 offers an ideal balance of security and performance for small to mid-sized businesses. Featuring a compact rack-mount design, it integrates advanced SD-WAN functionality and deep threat protection. This model includes 22 x GE RJ45 ports, 4 x GE SFP ports, and 2 x 10 GE SFP+ FortiLink ports for flexible network integration. The 1-year subscription to FortiCare support and FortiGuard Unified Threat Protection (UTP) helps protect against evolving threats.

Key Features:

Up to 20 Gbps firewall throughput
22 x GE RJ45, 4 x GE SFP, and 2 x 10 GE SFP+ FortiLink connectivity
1 RU rack-mount form factor with dual redundant power supplies
Includes 1-year FortiCare and FortiGuard Unified Threat Protection (UTP)

Please see the related tabs for the FG-40F-BDL-950-12 datasheet and compatible accessories.

Properties

Product Name	Fortinet FG-40F-BDL-950-12 Firewall
Description	Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP), 1-year bundle
Brand	Fortinet
Product Family	FortiGate 40F Series
Product Type	Firewall
Interfaces	22 x GE RJ45 ports, 4 x GE SFP ports, 2 x 10 GE SFP+ FortiLink ports
Port Details	2 x WAN, 1 x DMZ, 1 x Management, 2 x HA, 16 x switch ports with 4 shared SFP media pairs
USB Port	1
Console	1 x RJ45
Wireless Interface	None
Power Supplies	Dual redundant power supplies
Bundle	24x7 FortiCare and FortiGuard Unified Threat Protection (UTP)
Bundle Duration	1 Year

Specifications

Firewall Throughput (1518 / 512 / 64 byte, UDP)	20 / 18 / 10 Gbps
Firewall Latency (64 byte UDP packets)	4.97 μs
Firewall Throughput (Packets Per Second)	15 Mpps
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	56,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte packets)	11.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	16,000
SSL-VPN Throughput	1 Gbps
Concurrent SSL-VPN Users (Recommended Maximum)	500
SSL Inspection Throughput	1 Gbps
Application Control Throughput	2.2 Gbps
IPS Throughput	2.6 Gbps
NGFW Throughput	1.6 Gbps
Threat Protection Throughput	1 Gbps
CAPWAP Throughput	15 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of FortiSwitches Supported	32
Maximum Number of FortiAPs (Total / Tunnel Mode)	128 / 64
Maximum Number of FortiTokens	5000
High Availability Configurations	Active/Active, Active/Passive, Clustering
Dimensions	1.73 x 17 x 10 in
Form Factor	Rack Mount, 1 RU
Power Required	100-240V AC, 50/60 Hz
Maximum Current	100V / 1A, 240V / 0.5A
Power Consumption (Average / Maximum)	35.1 W / 38.7 W
Operating Temperature	32°F to 104°F (0°C to 40°C)
Regulatory Compliance	FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI
Certifications	USGv6/IPv6

Accessories

FN-TRAN-GC	1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+ slots
FN-TRAN-SX	1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots
FN-TRAN-LX	1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots
FN-TRAN-SFP+GC	10 GE SFP+ RJ45 transceiver module for systems with SFP+ slots
FN-TRAN-SFP+SR	10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
FN-TRAN-SFP+LR	10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
FN-TRAN-SFP+ER	10 GE SFP+ transceiver module, extended range for all systems with SFP+ and SFP/SFP+ slots
FN-TRAN-SFP+BD27	10 GE SFP+ transceiver module, 30KM long range single BiDi for systems with SFP+ and SFP/SFP+ slots
FN-TRAN-SFP+BD33	10 GE SFP+ transceiver module, 30KM long range single BiDi for systems with SFP+ and SFP/SFP+ slots
