Juniper EX-SFP-10GE-USR Transceiver
- SFP+ 10 Gigabit Ethernet Ultra Short Reach; 850 nm; 10m on OM1, 20m on OM2, 100m on OM3 Multi-Mode Fiber
$980.00
$470.40
Instant Savings
$509.60
Juniper Networks EX-SFP-10GE-USR 10GBASE-USR SFP+ Transceiver Module (MMF, 850nm, 100m, LC, DOM)
| Specifications | EX-SFP-10GE-USR |
| Description | EX-SFP-10GE-USR is a SFP+ 10 Gigabit Ethernet Ultra Short Reach; 850 nm; 10m on OM1, 20m on OM2, 100m on OM3 Multi-Mode Fiber |
| Product Family | Juniper Transceivers |
| Product Type | Optical Transceiver |
| Transceiver Type | SFP+ |
| Signaling rate, each lane | 10 Gigabit Ethernet |
| Connectors | Duplex LC |
| Fiber mode | MMF |
| Wavelength range | 850m |
| Transmit power | –7.3 to -1.3 |
| Receive power | –11.1 to -1.0 |
| Max Power consumption (W) | 1 W |
| Operating Temperature | 0° C to 70° C |
| DOM | Yes |
| Fiber mode | Fiber diameter (µm) | Modal bandwidth (MHz*km) | Transmission distance |
|---|---|---|---|
| MMF | 50/125 | 500 (OM2) | 20m |
| 1500 (OM3) | 100m | ||
| 62.5/125 | 200 (OM1) | 10m |
