Model: ZD42042-T01E00EZ
  • Thermal Transfer Printer, ZD420, Label/Receipt Print, Maximum Mono Print Speed: 5.98 in/s, Maximum Print Width: 4.09"
List Price: US$942.93
You Save: $353.93 (38% OFF)
Condition: Brand New Sealed
Availability: Out of Stock
Shipping: FREE SHIPPING for all U.S orders over $100. Please call us at 201-559-1474, fill out the contact form, or chat with a live agent for other shipping methods.
Tax: $0.00 Tax Outside New Jersey


The Zebra ZD420 Thermal Transfer Desktop Printer delivers features and functionality that take deployment and management simplicity to a new level. It offers fast and high-quality printing that keeps your business moving, along with application flexibility. It features an intuitive user interface that allows your workers to see, at a glance, what is needed to keep your printer up, running, and available. This printer comes included with a stand for ease of use.


Options and Accessories
Media Handling Dispenser/Peeler: label peel and present with label
present sensor (field installable)
Cutter (field installable)
Communications Field installable RS -232 auto-sensing Serial, DB-9; Ethernet – 10/100 internal; factory installed wireless dual radio: 802.11ac Wi-Fi and Bluetooth 4.1
Healthcare Model Healthcare model with IE C 60601-1 compliant power supply and healthcare wipeable plastics
Carrying Case  Carrying case with shoulder strap and handles makes it easy to bring your desktop printer and battery to the point of application
Keyboard Display Unit  Zebra Keyboard Display Unit (ZKDU) unit for standalone printing solutions


Specifications ZD420
Memory 512 MB Flash; 256 MB SDRAM
Maximum Print Width 4.09 in./104 mm for 203 dpi and 300 dpi
Maximum Print Speed 6 in./152 mm per second (203 dpi)
4 in./102 mm per second (300 dpi)
Media Sensors Full width, moveable reflective/black mark sensor;
multi-position transmissive/ gap sensor
Label Length Maximum: 39.0 in./991 mm
Media Width 4.65 in./118 mm
Media Roll Size 5.00 in./127 mm outer diameter Core inner
diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm)
standard, 1.5 in. (38.1 mm), 2.0 in., (50.8 mm) and
3.0 in. (76.2 mm) using optional adapters
Media Thickness 0.003 in. (0.08 mm) min.; 0.0075 in. (0.1905 mm) max.
Media Types Roll-fed or fan-fold, die cut or continuous with or
without black mark, tag stock, continuous receipt
paper, and wristbands
Fonts and Graphics 16 resident expandable ZPL II bitmap fonts
Two resident scalable ZPL fonts
Five resident expandable EPL2 fonts
Native open-type font support
Unicode compliant for multi-language, on
demand thermal printing
China units include SimSun simplified
Chinese font
64 MB user available non-volatile memory,
8 MB user available SDRAM
Barcode Symbologies
Barcode Ratios 2:1 and 3:1
Linear Barcodes Code 11, Code 39, Code 93, Code 128, IS BT-128, UPC-A, UPC-E, EAN -8, EAN -13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI , Codabar and Planet Code
2-Dimensional Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
Firmware ZPL II; EPL 2; XML; ZBI
Operating Temperature 40º to 105ºF (4.4º to 41ºC)
Storage Temperature -40º to 140ºF (-40º to 60ºC)
Operating Humidity 10% to 90% non-condensing R.H.
Storage Humidity 5% to 95% non-condensing R.H.
Regulatory IEC 60950-1, EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus CE Marking, VCCI, C-Tick, S-Mark, CCC, CU, BSMI, KCC, SABS, IN-Metro, BIS, NOM


Properties Zebra ZD420 ZD42042-T01E00EZ
Description Label printer, Thermal Transfer, Roll (4.65 in), 203 dpi, Up to 359.1 inch/min, USB, 2.0, USB host
Product Family ZD Series
Product Type Label Printer
Standard Features • Thermal Transfer print method
• ZPL and EPL programming languages
• 5 status icon, 3 button user interface
• USB 2.0, USB Host
• Bluetooth low energy
• OpenACCESS ™ for easy media loading
• Dual-wall frame construction
• ENER GY STAR qualified
• Real Time Clock
• ZebraDesigner Essentials – easy label design tool free at  www.zebra.com/zebradesigner
• Two-year standard warranty
Communications USB 2.0, USB Host
Printing Thermal Transfer print method
Resolution 203 dpi/8 dots per mm
Optional 300 dpi/12 dots per mm
Resolution can be factory installed or
changed on site via accessory kits.
Resolution can be changed from 300 dpi to
203 dpi, as well as from 203 dpi to 300 dpi.
Dimensions (W x H x D) 8.0 x 7.0 x 10.0 in. (202 mm x 177 mm x 254 mm)
Weight 5.0 lbs./2.3 kg
Power Auto-detectable (PFC Compliant) 100-240VAC,
50-60Hz; ENERGY STAR certified; Energy Efficiency
Level VI certified; optional 2750 mAh battery;
Healthcare models include IEC60601-1 certified
power supply
