Cisco WS-C2960X-48TD-L Switch
- 24 x 10/100/1000 Ports - Gigabit Ethernet Switch
- 2 x 1G SFP Uplinks
- LAN Lite
- Layer 2
- Managed
Cisco WS-C2960X-48TD-L Switch Overview
Cisco Catalyst WS-C2960X-24TS-LL Switches are Twenty four (24) Ethernet 10/100/1000 Gigabit ports and two (2) 1G SFP uplink Standalone mode with no FlexStack plus supporting and no NetFlow lite features Dual Core CPU with 256MB Memory (DRAM) and 64MB flash memory External RPS support redundant power Energy-efficient solution reduce power consumption LAN Lite Cisco IOS software feature set (no upgrade option) Cisco Catalyst 2960X-24TS-LL LAN Lite Layer 2 switch is comprised of 24 Ethernet 10/100/1000 ports and 2 * 1G SFP uplink interfaces. Advanced energy management solution with intelligent services reduces the power cost of business development. Cisco IOS software features enhance forwarding process and USB/Ethernet management interface simplify the operations. LAN lite image functions basic needs for layer 2 switching and does not support stacking. *Note: For stacking purpose, C2960X-STACK module is necessary.
| Properties | WS-C2960X-48TD-L |
| Description | 48 x 10/100/1000 Ports - Gigabit Ethernet Switch, 2 x 1G SFP Uplinks, LAN Lite, Layer 2, Managed |
| Product Family | Catalyst 2960-X |
| Product Type | Ethernet Switch |
| Number of Ports | 48 |
| Uplink Interfaces | 2 SFP+ |
| Available PoE power | No |
| Cisco IOS Software | LAN Base |
| FlexStack-Plus and FlexStack-Extended capability |
Optional |
| Dimensions in. | 1.75 x 11 x 17.5 |
| Specifications | WS-C2960X-48TD-L |
| Console Ports | USB (Type B), Ethernet (RJ-45) USB (Type A) for external flash storage |
| CPU | APM86392 600 MHz dual core |
| DRAM | 512 MB |
| Flash Memory | 128 MB |
| Forwarding Bandwidth | 108 Gbps |
| Switching Bandwidth | 216 Gbps |
| MAC addresses | 16000 |
| Maximum Active VLANs | 1023 |
| Operating Temperature Up to 5,000 ft (1500 m) |
-5 to 45 degree C |
| Operating Temperature Up to 10,000 ft (3000 m) |
-5 to 40 degree C |
| Safety | UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition IEC 60950-1 Second Edition AS/NZS 60950-1 |
| EMC: emissions | 47CFR Part 15 (CFR 47) Class A AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class A CNS13438 Class A |
| EMC: immunity | EN55024 CISPR24 EN300386 KN24 |
| Environmental | Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU |
| Telco | Common Language Equipment Identifier (CLEI) code |
| U.S. Government certifications | USGv6 and IPv6 Ready Logo |
| Ethernet interfaces | 10BASE-T ports: RJ-45 connectors, 2-pair Category 3, 4, or 5 unshielded twisted pair (UTP) cabling 100BASE-TX ports: RJ-45 connectors, 2-pair Category 5 UTP cabling 1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP cabling 1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Category 5 UTP cabling |
| Telnet - SSH | Yes |
| TACACS, TACACS+, Radius | Yes |
| Part Number | Description |
| C2960X-STACK | FlexStack-Plus hot-swappable stacking module |
| C2960X-FIBER-STK | FlexStack-Extended Fiber stacking module |
| C2960X-HYBRID-STK | FlexStack-Extended Hybrid module, with one copper and one fiber port |
| CAB-STK-E-0.5M | Stacking cable with a 0.5 m length |
| CAB-STK-E-1M | Stacking cable with a 1.0 m length |
| CAB-STK-E-3M | Stacking cable with a 3.0 m length |
| CAB-CONSOLE-RJ45 | Console cable 6 feet with RJ-45 |
| CAB-CONSOLE-USB | Console cable 6 feet with USB Type A and mini-B connectors |
| PWR-CLP | Power cable restraining clip |
| RCKMNT-1RU-2KX | Spare rack-mount kit for Cisco Catalyst 2960-X and 2960-XR Series for 19-inch racks |
| RCKMNT-REC-2KX | 1 RU recessed rack-mount kit for Cisco Catalyst 2960-X and 2960-XR Series |
