APC SMX2000RMLV2UNC - Smart-UPS X 2000VA Rack/Tower Convertible

Overview

The APC Smart-UPS X SMX2000RMLV2UNC delivers 1920VA / 1800W of reliable backup power in a 2U rack/tower convertible form factor. Designed with extended runtime capability, sine wave output, and line-interactive topology, it ensures clean and stable power for critical servers, storage, and network hardware. A pre-installed Network Management Card (NMC) enables advanced remote management, while the multifunction LCD console provides clear local status and control. Built for demanding IT environments, this UPS combines efficiency, flexibility, and scalability for superior protection.

Key Features & Benefits

• Extended Runtime Capability: Supports external battery packs to scale backup duration for mission-critical operations.
• Sine Wave Output: Provides consistent, high-quality power ideal for sensitive IT and network hardware.
• Pre-Installed Network Management Card: Enables remote monitoring, environmental integration, and advanced control out-of-the-box.
• Rack/Tower Convertible Design: Flexible deployment in 2U rackmount or tower orientation with included hardware.
• Multi-Function LCD Panel: Simplifies local UPS management with intuitive monitoring and controls.

Technical Deep Dive

The SMX2000RMLV2UNC operates with line-interactive topology and AVR, automatically correcting input voltage within the 70–153V range. This reduces battery cycling and extends battery lifespan while maintaining continuous uptime for connected equipment.

Equipped with a pure sine wave output, the UPS ensures compatibility with modern servers and active PFC power supplies. With a power capacity of 1920VA / 1800W, it delivers robust performance for mid-sized IT infrastructure, providing reliable runtime during outages and power instability.

A key differentiator is the inclusion of a pre-installed Network Management Card 3 (NMC), which provides remote visibility and environmental monitoring. This feature enhances centralized management for distributed IT environments, reducing downtime and simplifying UPS fleet oversight. Combined with the multifunction LCD panel, users benefit from both advanced remote management and intuitive local control.

Ideal Applications

• Enterprise servers, storage, and virtualization platforms
• Network closets and branch office IT infrastructure
• Healthcare and financial services requiring extended runtime protection
• Retail and education environments needing scalable backup solutions

Frequently Asked Questions (FAQs)

Q1: How is the SMX2000RMLV2UNC installed?
A: It is a 2U rack/tower convertible UPS that ships with mounting rails, brackets, and support hardware for flexible deployment in standard racks or tower setups.

Q2: What performance can I expect?
A: The UPS delivers 1920VA / 1800W of sine wave output. Runtime depends on load, but extended backup time can be achieved using external battery packs. Consult APC runtime charts for detailed values.

Q3: How can the UPS be managed?
A: It includes a pre-installed Network Management Card for remote monitoring and environmental integration, plus an LCD panel for local status and control.

Brand	APC
Model	SMX2000RMLV2UNC
Product Type	Smart-UPS X Rack/Tower Convertible with Network Card
Form Factor	Rackmount 2U / Tower Convertible
Color	Black
Dimensions (H x W x D)	3.35 x 17.01 x 26.26 in (8.5 x 43.2 x 66.7 cm)
Weight	84.77 lb (38.45 kg)
Mounting Type	Rack-mounted / Tower Convertible

Input Voltage	120 V (100 V / 110 V / 127 V compatible)
Input Frequency	50/60 Hz ±3 Hz auto-sensing
Plug Type	NEMA 5-20P
Output Voltage	120 V (100 V / 110 V / 127 V compatible)
Power Capacity	1920 VA / 1800 W
Output Connections	3 x NEMA 5-15R, 3 x NEMA 5-20R, 1 x NEMA L5-20R
Topology	Line Interactive
Waveform	Sine wave
Transfer Time	4 ms typical, 8 ms maximum
Battery Type	Lead-Acid
Recharge Time	3 hours typical
Battery Life	3–5 years
Replacement Battery	APCRBC117
Surge Protection	540 J
Operating Temperature	0…40°C
Operating Humidity	0…95%
Warranty	3 years repair or replace (excluding battery) and 2 years for battery

CD with Software	Included in the box
Documentation CD	Included in the box
Installation Guide	Included in the box
Network Management Card	Included in the box
Rack Mounting Hardware	Included in the box
Rack Mounting Brackets	Included in the box
Rack Mounting Support Rails	Included in the box
RS-232 Cable	Included in the box
USB Cable	Included in the box
