Intel Nuc12 RNUC12WSHI50000 Core i5-1240P/Intel Iris Xe Graphics Barebone
The Intel Nuc12 RNUC12WSHI50000 is a high-performance barebone system powered by the Intel Core i5-1240P processor, which can turbo up to 4.40 GHz. This model, specifically designed for users who prefer to customize their systems, does not come with an operating system, internal storage, or RAM memory. However, it offers flexibility with slots for up to 2 SSD M.2 and SATA 2.5'' discs, and two RAM slots for up to 64 GB DDR4-3200 1.2V SO-DIMM memory.
$470.00
Intel NUC12 (RNUC12WSHi50000)
The Intel Nuc12 RNUC12WSHI50000 is a barebone system known for its high performance, featuring the Intel Core i5-1240P processor with a turbo speed of up to 4.40 GHz. This particular model is tailored for users who prefer to have the flexibility to customize their systems, as it does not come pre-installed with an operating system, internal storage, or RAM memory. However, it provides adaptability with slots for up to 2 SSD M.2 and SATA 2.5'' discs, as well as two RAM slots capable of supporting up to 64 GB DDR4-3200 1.2V SO-DIMM memory.
Quick Specs:
- Intel Core i5-1240P CPU (12 core, up to 4.40GHz)
- 2x ThunderBolt port
- 64 MB DDR4 RAM
- 2x HDMI 2.1 TMDS Compatible, 2x DP 1.4a via Type C
Please see the related tabs for the RNUC12WSHI50000 datasheet and compatible accessories.
| Properties | Intel NUC 12 Pro Kit - NUC12WSHi5 |
| Description | The NUC 12 Pro NUC12WSHi5 is a powerhouse for evolving businesses, driven by a dynamic 12th Gen Intel® Core™ i5 processor. With hybrid core architecture and expansive configuration options, it ensures top-tier performance, supporting up to 64GB of DDR4 memory, 16TB storage, and vPro on select SKUs. |
| Product Family | Intel NUC |
| Product Type | Mini PC |
| Graphics | Intel Iris® Xe Graphics |
| Graphics Output | 2x HDMI 2.1 TMDS Compatible, 2x DP 1.4a via Type C |
| Numbers of Displays Supported | 4 |
| Numbers of Thunderbolt Ports | 2x Thunderbolt 4 |
| Numbers of USB Ports | 4 |
| USB Configuration | Front: 2x USB 3.2 Rear: 2x USB 4 (type C), 1x USB 3.2, 1x USB 2.0 Internal: 1x USB 3.2 on m.2 22x42 (pins), 2x USB 2.0 (headers) |
| Total number of SATA Ports | 1 |
| Serial Port via Internal Header | No |
| Audio (back channel + front channel) | Front panel: 3.5mm headphone/mic jack |
| Integrated LAN | Intel® Ethernet Controller i225-V |
| Wireless Included | Intel® Wi-Fi 6E AX211 (Gig+) |
| Bluetooth Version | 5.3 |
| M.2 Card Slot (wireless) | 22x30 (E) |
| Additional Headers | Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power connector |
| DC Input Voltage Supported | 12-20 VDC |
| Chassis Dimensions | 117 x 112 x 54 mm |
| Board Form Factor | UCFF (4" x 4") |
| Processor | Intel® Core™ i5-1240P Processor (12M Cache, up to 4.40 GHz) |
| Total Cores | 12 |
| Total Threads | 16 |
| Max Turbo Frequency | 4.40 GHz |
| Max Memory Size (dependent on memory type) | 64 GB |
| Number of Memory Slots | 2 |
| Memory Types | DDR4-3200 1.2V SODIMMs |
| Max Numbers of Memory Channels | 2 |
| ECC Memory Supported | No |
| Number of Internal Drives Supported | 3 |
| M.2 Card Slot (storage) | 22x80 NVMe (M); 22x42 SATA (B) |
| PCI Express Revision | Gen 4 (m.2 22x80 slot); Gen 3 (otherwise) |
| PCI Express Configurations | PCIe x4 Gen 4: M.2 22x80 (key M) PCIe x1 Gen 3: M.2 22x42 (key B) PCIe x1: M.2 22x30 (key E) |
| Supported Operating Systems | Windows 11 Home, Windows 11 Pro, Windows 10 Home, Windows 10 IoT Enterprise, Windows 10 Pro, Red Hat Linux, Ubuntu |
| Advanced Technologies | Intel HD Audio Technology Intel Virtualization Technology for Directed I/O (VT-d) Intel Virtualization Technology (VT-x) |
| Intel® Platform Trust Technology (Intel® PTT) | Yes |
| Intel® ME Firmware Version | 16.1 |
| Intel® AES New Instructions | Yes |
| Included Accessories | VESA bracket |
