MikroTik QRT 5 (RB911G-5HPnD-QRT-US) Outdoor Wireless Router

RB911G-5HPnD-QRT-US (MikroTik QRT 5) Outdoor 5 GHz Flat Panel CPE/AP

The MikroTik QRT 5 is built for outdoor deployments where a compact, high-gain integrated antenna and stable RouterOS performance matter. With a dual-chain 5 GHz radio and a Gigabit Ethernet port, it is well suited for point-to-point links, last-mile CPE, and backhaul scenarios where you want fast installation and consistent connectivity.

The RB911G-5HPnD-QRT-US variant is factory locked to specific frequency ranges to meet regional requirements. RouterOS comes preinstalled and licensed, so the device is ready to configure and deploy immediately.

Key Features

• Rugged outdoor flat panel design with IP54 protection
• Dual-chain 5 GHz 802.11a/n radio for flexible AP/CPE/backhaul roles
• Integrated 24 dBi antenna for long-range directional links
• Gigabit Ethernet uplink to maximize wireless backhaul throughput
• Passive PoE power for simple single-cable outdoor installations
• Monitoring features including voltage and PCB temperature sensors

Technical Specifications Summary

• Wireless: 5 GHz 802.11a/n (Wi-Fi 4), dual-chain (2x2), up to 300 Mbit/s
• Antenna gain: 24 dBi integrated flat panel (5 GHz)
• US frequency lock: 5170–5250 MHz and 5725–5835 MHz (factory locked)
• Ethernet: 1× 10/100/1000 Gigabit Ethernet port
• Power: Passive PoE-in, 8–28 V; maximum power consumption 12 W
• CPU/RAM/Storage: AR9342 (1 core, 600 MHz), 64 MB RAM, 128 MB NAND
• Environmental: IP54 enclosure; tested ambient temperature -40°C to 70°C
• Physical: 309 × 320 × 50 mm
• RF performance (selected): 30 dBm / -96 dBm at 6Mbit/s; 27 dBm / -78 dBm at 54Mbit/s; 26 dBm / -75 dBm at MCS7
• Certifications: CE, EAC, RoHS

Model	MikroTik QRT 5
Manufacturer Part Number	RB911G-5HPnD-QRT-US
Product Code	RB911G-5HPnD-QRT
Device Type	Outdoor 5 GHz AP/Backbone/CPE (flat panel antenna with integrated RouterBOARD)
Wireless Standards	802.11a/n (Wi-Fi 4)
Wireless Configuration	Dual-chain (2x2)
Max 5 GHz Data Rate	300 Mbit/s
Antenna	Integrated flat panel, 24 dBi (5 GHz)
Ethernet	1× 10/100/1000 Gigabit Ethernet
Power Input	Passive PoE-in, 8–28 V
Max Power Consumption	12 W
Enclosure Rating	IP54
US Model Frequency Lock	Factory locked for 5170–5250 MHz and 5725–5835 MHz
Operating Temperature	Tested ambient temperature: -40°C to 70°C
Dimensions	309 × 320 × 50 mm
Certifications	CE, EAC, RoHS

Architecture	MIPSBE
CPU	AR9342
CPU Core Count	1
CPU Nominal Frequency	600 MHz
RAM	64 MB
Storage	128 MB
Storage Type	NAND
Operating System	RouterOS (preinstalled)
RouterOS License	Level 4
Cooling	Passive
Wireless Chip Model	AR9342
PCB Temperature Monitor	Yes
Voltage Monitor	Yes
Beeper	Yes
MTBF	Approximately 200,000 hours at 25°C
Wireless TX/RX (6Mbit/s)	30 dBm / -96 dBm
Wireless TX/RX (54Mbit/s)	27 dBm / -78 dBm
Wireless TX/RX (MCS0)	30 dBm / -96 dBm
Wireless TX/RX (MCS7)	26 dBm / -75 dBm
EU Compliance (where applicable)	Radio Equipment Directive (RED) 2014/53/EU; RoHS Directive 2011/65/EU (incl. EU 2015/863)

Included

QRT antenna mount, U bolts, U mast clamp, K-QRT screw kit, 24 V 0.8 A power adapter, Gigabit PoE injector
