Dell PowerEdge R470 1U Rack Server for Efficient Data Center Workloads

The Dell PowerEdge R470 is a 1U single-socket rack server designed for balanced performance, power efficiency, and dense infrastructure deployment. Built with Intel Xeon 6 processor options, DDR5 memory support, Gen5 NVMe storage configurations, and Dell OpenManage management tools, it is suited for scalable enterprise environments that require compact compute capacity.

Key Benefits and Features

• Single-socket 1U design helps maximize rack utilization in dense data centers.
• Supports Intel Xeon 6 E-core or P-core processor options for workload flexibility.
• DDR5 RDIMM support enables high memory capacity and fast memory speeds.
• Gen5 NVMe drive bay options support high-throughput storage configurations.
• Integrated security features include Secure Boot, Silicon Root of Trust, and TPM 2.0.

Ideal Use Cases

• Cloud scale web and application microservices
• Data services and infrastructure workloads
• Virtualization environments
• Scale-out database deployments
• Enterprise rack server refresh projects

Technical Specifications

• Brand: Dell
• Model: PowerEdge R470
• Form Factor: 1U rack server
• Processor Support: One Intel Xeon 6 E-core processor up to 144 cores or one Intel Xeon 6 P-core processor up to 86 cores with R1S option
• Memory: 16 DDR5 DIMM slots, RDIMM support, up to 6400 MT/s
• Maximum Memory: Up to 1 TB with Intel Xeon 6 E-core processor or up to 4 TB with Intel Xeon 6 P-core processor option
• Drive Bay Options: Front EDSFF E3.S Gen5 NVMe, 2.5 inch SATA/NVMe, or 3.5 inch SATA configurations (3.5-inch requires rear drive configuration)
• Embedded Management: iDRAC, iDRAC Direct, iDRAC RESTful API with Redfish, RACADM CLI, and iDRAC Service Module
• PCIe Expansion: Up to 4 Gen5 PCIe slots with x16 connectors
• Cooling: Air cooling with up to 4 sets of hot swappable dual fan modules

Upgrade Your Rack Infrastructure with Dell PowerEdge R470

Choose the Dell PowerEdge R470 when your data center needs compact rack compute, modern DDR5 memory support, Gen5 NVMe storage options, and integrated Dell systems management in a single-socket 1U platform.

Brand	Dell
Model	PowerEdge R470
SKU	R470
Product Type	Rack Server
Series	PowerEdge
Form Factor	1U rack server
Processor	One Intel® Xeon 6 E-core processor or one Intel® Xeon 6 P-core processor with R1S option
Memory	16 DDR5 DIMM slots, supports RDIMM up to 4TB, speeds up to 6400 MT/s
Drive Bays	Front bays and rear bays with SATA and NVMe options
Power Supplies	800W, 1100W, 1500W, and 1400W hot swap redundant options
Cooling	Air cooling
Dimensions	Height: 42.8 mm (1.69 inches) Width: 482 mm (19.0 inches) Depth: 816.92 mm (32.16 inches) with bezel Depth: 815.14 mm (32.09 inches) without bezel

Processor	One Intel® Xeon 6 E-core processor with up to 144 cores per processor or one Intel® Xeon 6 P-core processor with up to 86 cores with R1S option
Memory Support	Intel® Xeon® 6 E-core processor supports 1 TB max; Intel® Xeon® 6 P-core processor with R1S option supports 4 TB max
Memory Type	Registered ECC DDR5 DIMMs only
Storage Controllers	Internal Controllers (RAID): PERC H3651 DC-MHS, front PERC H9651 DC-MHS, PERC H365i adapter, PERC H965i adapter External Controllers: HBA465e, H965e(RAID)
Internal Boot	Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS): HWRAID 1, 2 x M.2 NVMe SSDs, M.2 interposer with up to 2 x M.2 NVMe SSDs or USB
Front Drive Bays	Up to 8 x EDSFF E3.S Gen5 NVMe max 491.52 TB Up to 16 x EDSFF E3.S Gen5 NVMe max 983.04 TB Up to 8 x 2.5-inch SATA/NVMe max 491.52 TB Up to 10 x 2.5-inch SATA/NVMe (with 4 x 2.5-inch universal) max 614.4 TB Up to 4 x 3.5-inch SATA max 128 TB (only supported with rear 2 x E3.S drives, not supported as standalone front-only configuration)
Rear Drive Bays	Up to 2 x EDSFF E3.S Gen5 NVMe max 122.88 TB
Power Supplies	800W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant 1100W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant 1500W Titanium 100-240 VAC or 240 HVDC, hot swap redundant 1500W 277 Vac and HVDC Titanium, hot swap redundant 1400W -48V DC Titanium, hot swap redundant
Fans	Up to 4 sets (dual fan module) hot swappable fans
Dimensions	Height: 42.8 mm (1.69 inches) Width: 482 mm (19.0 inches) Depth: 816.92 mm (32.16 inches) with bezel Depth: 815.14 mm (32.09 inches) without bezel Depth (Front I/O Configuration): 829.44 mm (32.09 inches) without bezel (Note: Front I/O configuration will not have a bezel)
Embedded Management	iDRAC iDRAC Direct iDRAC RESTful API with Redfish RACADM CLI iDRAC Service Module
Security Features	Cryptographically signed firmware Data at Rest Encryption (SEDs with local or external key mgmt) Secure Boot Secured Component Verification (Hardware integrity check) Secure Erase Silicon Root of Trust System Lockdown (requires iDRAC10 Enterprise or Datacenter) TPM 2.0 FIPS, CC-TCG certified Chassis Intrusion Detection Optional security bezel
OCP Network Options	Up to two OCP NIC card 3.0: Two slots on the front or two slots on the rear (optional)
Embedded NIC	1 Gb dedicated BMC Ethernet port
GPU Options	Up to 4 x 75 W SW
DPU Options	NVIDIA BlueField-3 2 x 200 GbE B3220
Front Ports	1 x USB 2.0 Type-C port 1 x USB 2.0 Type A port (optional) 1 x Mini-DisplayPort (optional) 1 x DB9 Serial (with front I/O configuration) 1 x Dedicated BMC Ethernet port (with front I/O configuration)
Rear Ports	1 x Dedicated BMC Ethernet port 2 x USB 3.1 Type A ports 1 x VGA
Internal Ports	1 x USB 3.1 Type A port
PCIe Expansion	Up to 4 Gen5 PCIe slots (x16 connectors) Slot 1: 1 x8 Gen5 Low Profile OR 1 x16 Gen5 full height, half length on rear riser Slot 4: 1 x16 Gen5 full height, half length on rear riser Slot 31: 1 x16 Gen5 full height, half length on rear riser Slot 32: 1 x16 Gen5 full height, half length on rear riser
Operating Systems	Canonical Ubuntu Server LTS Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi Windows Server Windows Server Datacenter
