Integrated PoE+ and Wi-Fi 6 Security with Enterprise Protection
The FortiWiFi 70G-POE (FWF-70G-POE-A-BDL-809-36) is a converged Next-Generation Firewall designed to simplify branch office deployments. This 3-Year Enterprise Protection bundle includes FortiGuard security services to enhance protection. Powered by the Fortinet SP5 ASIC, it delivers up to 10 Gbps firewall throughput, integrated Wi-Fi 6, and a total available PoE power budget of 60W to support powered devices.
This all-in-one appliance reduces hardware complexity by combining networking, security, wireless, and power delivery into a single compact device. It ensures robust protection against sophisticated cyber threats while providing high-speed connectivity for users and IoT devices.
Key Benefits
- 3-Year Enterprise Protection: Includes a 3-year FortiGuard Enterprise Protection bundle to enhance NGFW security.
- Integrated PoE+ Ports: Features 4x GE RJ45 PoE/+ ports with a 60W total PoE budget to power compatible devices.
- Powered by SP5 ASIC: Delivers up to 10 Gbps firewall throughput and up to 7.1 Gbps IPsec VPN throughput.
- Integrated Wi-Fi 6: Built-in dual-band 802.11ax access point provides secure, high-speed wireless coverage.
- Unified Management: Consolidates security, Wi-Fi, switching, and PoE power management into a single FortiOS console.
- Secure SD-WAN: Integrated SD-WAN capabilities help optimize application performance and secure direct internet access.
Ideal Use Cases
- Retail Branches: Powers compatible endpoints while securing Wi-Fi and SD-WAN connectivity with enterprise-grade NGFW capabilities.
- Small Offices: All-in-one solution reducing the need for separate wireless and power delivery components.
- Distributed Sites: Combines firewalling, SD-WAN, and Wi-Fi 6 to support secure connectivity for users and devices.
Technical Specifications Summary
- Firewall Throughput: 10 Gbps (1518/512/64 byte UDP packets)
- IPS Throughput (Enterprise Traffic Mix): 2.5 Gbps
- NGFW Throughput (Enterprise Traffic Mix): 1.5 Gbps
- Threat Protection Throughput (Enterprise Traffic Mix): 1.3 Gbps
- IPsec VPN Throughput (512 byte): 7.1 Gbps
- Firewall Latency (64 byte UDP packets): 2.46 us
- Concurrent Sessions (TCP): 1.4 Million
- New Sessions/Second (TCP): 100,000
- Total Available PoE Power Budget: 60 W
- Dimensions (H x W x L): 40.5 x 216 x 160 mm
- Operating Temperature: 0C to 40C (32F to 104F)
Upgrade Your Network Security
Streamline your branch with the FortiWiFi 70G-POE and 3-Year Enterprise Protection bundle.
